TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±16
394
Wire Harness Repair Manual (RM1022E)
Repair Wire (Non±waterproof Type)
TypePULSE LOCK
Female (Power)Female (Signal)
P/N82998±1220082998±12210
TypeSFPC
MaleFemale
Sleeve : Medium (Blue)
P/N82998±24180
TypeSL
MaleFemale
Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±12130

F±17
TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
Wire Harness Repair Manual (RM1022E)
395
Repair Wire (Non±waterproof Type)
TypeSP
Female (Power)Female (Signal)
Sleeve : Medium (Blue) or Large (Yellow)Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±1252082998±12530
TypeTLC
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
P/N82998±1222082998±12230
TypeTNS
MaleFemale
Sleeve : Medium (Blue)Sleeve : Medium (Blue)
P/N82998±1224082998±12250

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±18
396
Wire Harness Repair Manual (RM1022E)
Repair Wire (Non±waterproof Type)
TypeTODC
MaleFemale
Sleeve : Medium (Blue) or
Large (Yellow)Sleeve : Medium (Blue) or Large (Yellow)
P/N82998±1208082998±12090

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE
F±18
414
Wire Harness Repair Manual (RM1022E)
Press Sleeve
ColorYELLOWBLUE
P/N82999±1203082999±12020
ColorRED
P/N82999±12010
