Steering Wheel Area Overview
ƒHigh Beam Control System (HBC) switch.......................................... page 5-142
„ Lighting control................................................................................. page 5-68
… Turn and lane-change signals............................................................. page 5-72
† Audio remote control switches........................................................... page 7-13
‡ INFO switch...................................................................................... page 5-28
ˆ Mazda Radar Cruise Control (MRC C) switches................................. page 5-167
‰ Cruising & Traffic Sup port (CTS) switches..........................................page 5-177
Š Cruise control switches................................................................... page 5-226
‹ Wiper and washer lever..................................................................... page 5-74
Name of Each Part
Steering Wheel Area Overview
1-2The equipment and installation position varies by vehicle
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the
Immobilizer System
NOTE
The hybrid system may not start and
security indicator light may illuminate
or flash if the key is placed in an area
where it is difficult for the system to
detect the signal, such as on the
dashboard or in the glove
compartment. Move the key to a
location within the signal range,
switch the vehicle power off, and
then restart the hybrid system.
Signals from a TV or radio station, or
from a transceiver or mobile
telephone could interfere with your
immobilizer system. If you are using
the proper key and the hybrid system
fails to start, check the security
indicator light.
Arming
The system is armed when the vehicle
power is switched from ON to off.
The security indicator light
in the
instrument cluster flashes every 2
seconds until the system is disarmed.
Disarming
The system is disarmed when the
vehicle power is switched ON with the
correct programmed key. The security
indicator light
illuminates for
about 3 seconds and then turns off.
If the hybrid system does not start with
the correct key, and the security
indicator light remains illuminated or
flashing , try the following:
Make sure the key is within the
operat ional range for signal
transmission. Switch the vehicle power
off, and then restart the hybrid system.
If the hybrid system does not start after
3 or more tries, contact an Authorized
Mazda Dealer.
Opening/closing
Security System
4-39
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Turn Signal lever..................... 5-72How to Use the Turn Signal
Lever................................... 5-72
Windshield Wiper/Washer
Switch................................... 5-73 Windshield Wiper/Washer
Switch.................................5-73
Warning and Cautions for Using
the Windshield Wiper/Washer
Switch.................................5-73
How to Use the Windshield
Wiper/Washer Switch.......... 5-74
How to Use the Rear Wiper/
Washer Switch..................... 5-77
Rear Window Defogger
Switch................................... 5-78 Rear Window Defogger
Switch.................................5-78
Warnings and Cautions for Using
the Rear Window Defogger
Switch.................................5-78
How to Use the Rear Window
Defogger Switch.................. 5-79
Mirror Defogger
*..................5-79
How to Use the Mirror
Defogger............................. 5-80
Windshield Wiper De-icer
*..........
.......................................... 5-80
How to Use the Windshield
Wiper De-icer......................5-81
Hazard Warning Lights............. 5-82 Hazard Warning Lights......... 5-82
How to Use the Hazard Warning
Lights.................................. 5-82
Horn..................................... 5-83How to Use the Horn........... 5-83
Antilock Brake System (ABS)..... 5-84 Antilock Brake System
(ABS).................................. 5-84
Warning and Cautions for Using
the Antilock Brake System
(ABS).................................. 5-84
Traction Control System (TCS) ..........
............................................ 5-85 Tra c t i o n C o n t r o l Sy s t e m
(TCS).................................. 5-85
Warning and Cautions for Using
the Traction Control System
(TCS).................................. 5-85
How to Use the Traction Control
System (TCS)....................... 5-86
Convenient Ways to Use the
Tra c t i o n C o n t r o l Sy s t e m
(TCS).................................. 5-87
Dynamic Stability Control
(DSC).................................... 5-88 Dynamic Stability Control
(DSC)................................. 5-88
Warning and Cautions for Using
the Dynamic Stability Control
(DSC)................................. 5-88
How to Use the Dynamic Stability
Control (DSC)..................... 5-89
Trailer Stability Control (TSC) ...........
............................................ 5-90 Trailer Stability Control
(TSC).................................. 5-90
*Some models.5-3
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Using the leaving home light
Press the unlock button on the key
while the vehicle power is switched
OFF.
When the vehicle receives a key
operation signal, the headlights,
parking lights, taillights, and the license
plate lights turn on.
The lights turn off when any of the
following conditions is met.
Thirty seconds have passed since the
lights turned on.
The light switch is set to the OFF
position.
The lock button on the key is
pressed.
NOTE
The leaving home light can be set so
that it does not to operate.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Driving
Light Switch
5-71
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the TurnSignal Lever
When the lever is operated, the turn
signal lights flash/turn
off.
Using the Turn Signal Lever
Turning left or right
Operate the lever to the 1 or 4
position.
Each turn signal light flashes and the
turn signal light
in the
instrument cluster flashes.
The lever returns to its original position
in conjunction with the steering wheel
operation. If it does not return, return
it by hand.
Changing lanes
Operate the lever to the 2 or 3
position.
While the lever is in the 2 or 3
position, each turn signal light flashes
and the turn signal light
in the
instrument cluster flashes.
If you move the lever to the 2 or 3
position and release it immediately,
the three-flash turn signal operates and
the turn signal light flashes 3 times.
NOTE
The volume of the turn signal lever
sound can be changed.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
The three-flash turn signal can be
turned off.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
Driving
Tu r n S i g n a l l e v e r
5-72
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Hazard Warning Lights
The hazard warning light switch is used
when it is necessary to park the vehicle
on a roadside due to a vehicle
breakdown or other emergency.
How to Use the HazardWarning Lights
The vehicle power is switched ON
All the turn signal lights flash, and the
turn signal light
and the hazard
warning light
in the instrument
cluster flash.
Press the switch again to turn off the
lights.
The vehicle power is switched to ACC
or OFF
All the turn signal lights flash and the
hazard warning light
in the
instrument cluster flashes.
Press the switch again to turn off the
lights.
Driving
Hazard Warning Lights
5-82
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Tire Pressure MonitoringSystem (TPMS)
The TPMS monitors the air pressure of
each tire and informs the driver of a
decrease in the tire air pressure when it
becomes lower than the specified air
pressure.
For the TPMS, the air pressure data
sent from the tire pressure sensors
installed on each wheel via radio signal
is received by the receiver unit in the
vehicle to monitor the tire pressures.
1. Tire pressure sensor
Warning and Cautions forUsing the Tire Pressure Monitoring System
(TPMS)
WARNING
Do not drive the vehicle at high
speeds if the TPMS warning light
is
turned on or flashing.
Driving the vehicle at high speeds
while the TPMS warning light is turned
on or flashing is dangerous because
the brake performance and the
steering wheel operability will be
reduced. If the vehicle is driven at high
speeds or the brakes are suddenly
applied, it could lead to an accident.
Gradually apply the brake and reduce
the vehicle speed.
Do not ignore the TPMS warning light
when it is turned on or flashing.
Continuing to driv e the vehicle while
ignoring the illumi nation/flashing of
the TPMS warning light is dangerous
because a tire may burst which could
lead to an accident. Take appropriate
measures as soon as possible.
Driving
Tire Pressure Monitoring System (TPMS)
5-100
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the Tire
Pressure Monitoring System (TPMS)
Check the tire pressure
The current tire pressure can be
checked on the center display.
Refer to the Vehicle Status Monitor
section in the Mazda Connect
Owner's Manual.
Low tire pressure warning
When a tire pressure of the specified
air pressure or lower is detected, the
TPMS warning light
turns on and a
warning indication is displayed in the
instrument cluster.
1. Message is displayed.
Action
1. Adjust the tire pressure to the appropriate pressure.
Refer to the Tires on page 10-71.
CAUTION
If the tire pressure is adjusted when
the tire is warm, the tire pressure
may lower below the specified
pressure after cooling and the
warning light may turn on. Adjust
the air pressure of the tires when
they are cold.
2. Make sure that the TPMS warning
light
is turned off.
3. If the TPMS warning light does
not turn off, drive the vehicle for 3
minutes or longer at a speed of 25
km/h (16 mph) or faster.
4. Make sure that the TPMS warning
light
is turned off.
If the TPMS warning light remains on
even after adjusting the tire pressure,
there is a possibility that the tire is flat.
CAUTION
When inspecting/adjusting the tire
pressures, do not apply excessive force
to the air valve of the tire pressure
sensor. Otherwise, the tire pressure
sensor could be damaged.
When changing tires and wheels
When changing the tires or wheels
(such as installing winter tires), it will
be necessary to register the ID signal
code of the tire pressure sensor to the
TPMS.
Have an Authorized Mazda Dealer do
the registration or register the ID signal
codes of the tire pressure sensors using
the following procedure.
NOTE
The tire pressure sensors on each
wheel have a unique ID signal code.
For the TPMS to operate correctly, the
ID signal codes of the tire pressure
sensors need to be registered to the
system.
1. Wait more than 19 minutes after changing a tire or wheel.
2. After more than 19 minutes have passed, drive the vehicle at a speed
of 25 km/h (16 mph) or faster for 3
minutes or longer. While driving,
the ID signal codes of the tire
pressure sensors are automatically
registered.
Driving
Tire Pressure Monitoring System (TPMS)
5-102
