2024 MAZDA CX90 key

Key Removed from
Vehicle Warning Sound
Vehicles with advanced keyless
function
If the key is taken out of the vehicle
while the vehicle power is switched to
ACC or ON, and all the doors are
closed, a sound is activated 6 times
outside of the vehicle and a sound is
activated 1 time in the vehicle.
Vehicles without advanced keyless
function
If the key is taken out of the vehicle
while the vehicle power is switched to
ACC or ON, and all the doors are
closed, a sound is activated 1 time in
the vehicle.

Make sure that you leave the vehicle
while carrying the key, or switch the
vehicle power OFF.
Key Left-in-Vehicle Warning Sound
If all the doors and luggage
compartment are locked using another
key while the key is left in the cabin,
the beep which soun ds outside of the
vehicle will be heard for about 10
seconds to notify the driver that the
key is in the cabin. In this case, take
out the key by opening the door.
A key taken out of the vehicle using
this method may not operate because
its functions have been temporarily
stopped. To restore the key's functions,
perform the applicable procedure
(page 8-8).
What to Do in Case of Emergency
Warning Sound is Activated
8-57
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Key Left-In-Luggage
Compartment Warning Sound (Vehicles With
Advanced Keyless Function)
If the key is left in the luggage
compartment with all the doors locked
and the liftgate closed, a beep will be
heard outside for about 10 seconds to
notify the driver that the key is in the
luggage compartment. In this case,
take out the key by pressing the electric
liftgate opener and opening the
liftgate.
The key taken out of the luggage
compartment may not operate
because its functions have been
temporarily stopped. To restore the
key's functions, perform the applicable
procedure (page 8-8).
Door Lock InoperableWarning Sound
Operation Using Touch Sensor
A warning beep is activated to notify
the driver that the doors are not locked
when all of the following conditions
are met:
The vehicle power is switched OFF.All the doors are not fully closed.The lock is operated 3 times within 5
seconds.
Check the vehicle power and whether
the doors are open or closed, and then
operate the lock again.
Operation Using Door-lock Switch on
the Liftgate
When the door-lock switch on the
liftgate is pressed under any of the
following conditions, a warning sound
is activated.
The vehicle power is switched to a
position other than OFF.
Any door is open.
Make sure that none of the above
conditions are present, and then press
the door-lock switch again.
What to Do in Case of Emergency
Warning Sound is Activated
8-58
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

9Inspection and Servicing/Cleaning
Inspection and Servicing............ 9-2Inspection and Servicing.........9-2
Scheduled Maintenance............ 9-4 Scheduled Maintenance......... 9-4
Daily Inspection........................9-7 Daily Inspection.....................9-7
Warnings and Cautions for Daily
Inspection............................. 9-8
Engine Compartment
Inspection................................ 9-9 Checking the Inspection
Locations and Inspection
Items.................................... 9-9
Inspecting Engine Oil........... 9-13
Inspecting the Coolant......... 9-14
Inspecting the Brake Fluid..... 9-16
Replenishing Windshield Washer
Fluid................................... 9-17
Inspecting Lead-acid
Battery................................ 9-18
Replacing the Fuses.............. 9-21
Inspecting Body
Lubrication.......................... 9-22
Vehicle Exterior Inspection....... 9-23 Checking the Inspection
Locations and Inspection
Items.................................. 9-23
Replacing Windshield Wiper
Blade Rubbers..................... 9-23
Inspecting the Tires.............. 9-27Rotating the Tires................. 9-28
Replacing a Tire or a
Wheel................................. 9-29
Replacing Light Bulbs........... 9-30
Vehicle Interior Inspection....... 9-31 Checking the Inspection
Locations and Inspection
Items.................................. 9-31
Air Conditioner
Maintenance....................... 9-32
Key Inspection........................ 9-33 Warnings and Cautions about Key
Battery Replacement............ 9-33
Replacing the Key Battery..... 9-33
Exterior Maintenance.............. 9-35 Exterior Maintenance........... 9-35
Wheel Maintenance.............9-36
Interior Maintenance............... 9-37 Interior Maintenance........... 9-37
Instrument Panel Top (Soft pad)
Maintenance....................... 9-37
Upholstery and Synthetic Leather
Maintenance....................... 9-38
Leather Upholstery
Maintenance....................... 9-38
Maintenance of the Dust-proof
Sheet of the Active Driving
Display................................9-39
Seat Belt Maintenance......... 9-40
9-1
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warnings and Cautionsabout Key BatteryReplacement
CAUTION
Make sure the battery is installed
correctly. Battery leakage could occur
if it is not installed correctly.
 When replacing the battery, be
careful not to touch any of the
internal circuitry and electrical
terminals, bend the electrical
terminals, or get dirt in the
transmitter as the transmitter could
be damaged.
 There is the danger of explosion if
the battery is not correctly replaced.
 Dispose of used batteries according
to the following instructions.
 Insulate the plus and minus
terminals of the battery using
cellophane or equivalent tape.
 Never disassemble.
 Never throw the battery into fire or
water.
 Never deform or crush.
 Replace only with the same type
battery (CR2032 or equivalent).
Replacing the Key Battery
Replace with a new battery before the
key becomes unusable.
The following conditions indicate that
the battery power is low:
The KEY indicator light (green)
flashes in the instrument cluster.
The system does not operate and the
operation indicator light on the
transmitter does not flash when the
buttons are pressed.
The system's operational range is
reduced.
Incorrect battery replacement
operation may damage the key.
Replacing the battery at an Authorized
Mazda Dealer is recommended.
If replacing the battery by yourself,
heed the following instructions.
1. Remove the lower cover while pressing the knob in the direction
of the arrow.
2. Press in the tab to unlock the uppercover.
Inspection and Servicing/Cleaning
Key Inspection
9-33
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

3. Insert a tape-wrapped flatheadscrewdriver into the gap and slide
it.
4. Twist the flathead screwdriver andremove the upper cover.
5. Remove the cap using thetape-wrapped flathead screwdriver.
6. Remove the battery using the
tape-wrapped flathead screwdriver.
7. Insert a new battery into the key sothat the positive pole is facing up.
8. Install the cap.
9. Install the upper cover.
10.Attach the lower cover so that itstabs are inserted into the slots of
the key.
Inspection and Servicing/Cleaning
Key Inspection
9-34
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Cell Phones.......................... 10-26Cell Phones Warning.......... 10-26
Uniform Tire Quality Grading System
(UTQGS).............................. 10-27 Uniform Tire Quality Grading
System (UTQGS)................ 10-27
Tread Wear........................ 10-27
Traction-AA, A, B, C........... 10-28
Temperature-A, B, C.......... 10-28
UNIFORM TIRE QUALITY
GRADING......................... 10-29
Tire Information (U.S.A.)........ 10-30 Tire Labeling...................... 10-30
Information on Passenger Vehicle
Tires.................................. 10-30
Information on Temporary
Tires.................................. 10-33
Location of the Tire Label
(Placard)........................... 10-34
Recommended Tire Inflation
Pressure............................ 10-34
Checking Tire Pressure........10-35
Glossary of Terms............... 10-36
Tire Maintenance............... 10-37
Tire Inflation Pressure......... 10-37
Tire Rotation...................... 10-38
Replacing a Tire................. 10-38
Safety Practices.................. 10-39
Vehicle Loading................. 10-40
Steps for Determining the Correct
Load Limit......................... 10-45
Declaration of Conformity..... 10-46 Keyless Entry System/Immobilizer
System.............................. 10-46
HomeLink Wireless Control
System.............................. 10-47Charging........................... 10-48
Tire Pressure Monitoring
System.............................. 10-49
Front Radar Sensor System ...........
........................................ 10-50
Front Side Radar Sensor System/
Rear Side Radar Sensor
System.............................. 10-51
Audio System.................... 10-52
Radio System..................... 10-54
Data Communication
System.............................. 10-55
Wireless Charger (Qi)......... 10-58
Identification Numbers.......... 10-59 Ve h i c l e I d e n t i fi c a t i o n
Number............................ 10-59
Motor Vehicle Safety Standard
Label.................................10-59
Chassis Number................ 10-60
Vehicle Emission Control
Information Label.............. 10-60
Tire Pressure Label..............10-61
Engine Number..................10-61
Vehicle Specification............. 10-62 Engine...............................10-62
Charge System................... 10-63
High Voltage Battery...........10-64
Electrical System................ 10-65
Lubricant Quality............... 10-66
Capacities......................... 10-67
Dimensions....................... 10-68
Weights.............................10-69
Light Bulbs.........................10-70
Tires.................................. 10-71
10-2
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Keyless Entry System/Immobilizer System
Specifications/Customer Information and Reporting Safety Defects
Declaration of Conformity
10-46
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Index
AC power outlet (120 V/1,500
W)....................................... 7-50
AC power outlet (120 V/150
W)....................................... 7-47
Ambient lights...................... 7-45
Armrest Box......................... 7-35
Bottle holder........................ 7-32
Center console..................... 7-34
Cup holders......................... 7-30
Door courtesy lights..............7-44
Glove compartment..............7-33
How to use the assist grips.... 7-58
Illuminated entry system........7-41
Luggage compartment.......... 7-38
Luggage compartment lghts... 7-44
Map lights............................7-43
Overhead console................ 7-36
Overhead lights.................... 7-42
Rear coat hooks................... 7-37
Sunvisor............................... 7-39
USB power outlet................. 7-52
Vanity mirrors....................... 7-40
Wireless charger (Qi)............ 7-54
i-ACTIVSENSE Blind Spot Monitoring
(BSM)................................ 5-146
Cameras............................ 5-137
Cruising & Tra ffi c Support
(CTS)................................. 5-175
Distance & Speed Alert
(DSA)................................ 5-153
Driver Attention Alert
(DAA)................................ 5-155
Driver monitoring camera....5-139
Driver Monitoring (DM)...... 5-157
Emergency Lane Keeping
(ELK).................................. 5-191
Forward Sensing Camera
(FSC)................................. 5-127
Front Cross Tra ffi c Alert
(FCTA)............................... 5-160High Beam Control System
(HBC)................................ 5-140
i-ACTIVSENSE OFF switch.... 5-126
i-ACTIVSENSE status symbol
(Warning/risk avoidance support
system).............................. 5-124
Lane Departure Warning System
(LDWS).............................. 5-144
Lane-keep Assist System
(LAS)..................................5-188
Mazda Radar Cruise Control
(MRCC)............................. 5-165
Radar sensors..................... 5-131
Rear Cross Tra ffi c Alert
(RCTA)............................... 5-163
Secondary Collision
Reduction.......................... 5-223
Smart Brake Support (SBS)...5-197
Tra ffi c Sign Recognition
System (TSR)...................... 5-150
360° View Monitor............. 5-206
K
Key.............................................4-5 Canceling the key temporary
suspension function................ 8-8
Replacing the key battery...... 9-33
Starting the Engine with a dead
battery key............................. 8-9
Unlocking using the auxiliary
key........................................ 8-8
L
Liftgate..................................... 4-18Liftgate cannot open............. 8-30
Power liftgate....................... 4-21
Light Washer fluid does not spray... 8-35
Lights Hazard warning lights........... 5-82
11-4
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
