Be careful not to pinch your hand
when closing the liftgate. It may
result in an injury if your hand is
caught.
1. Damper stay
 Do not modify or replace the liftgate
damper stay. Consult an Authorized
Mazda Dealer if a liftgate damper
stay is deformed or damaged for
reasons such as a collision or if there
is some other problem.
How to Use the Liftgate
Opening the Liftgate
1. Unlock the door.
2. Press the electric liftgate opener.
3. Lift the liftgate.
NOTE
(Vehicles with advanced keyless
function)
The liftgate can be opened even while
the doors and the liftgate are locked by
pressing the electric liftgate opener
while carrying the key.
Closing the Liftgate
1. Lower the liftgate slowly using the
liftgate recess.
2. Press down the liftgate to close.
Opening/closing
Liftgate
4-18
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Powe r L i ft g ate*
The liftgate opens and closes
automatically by operating the key
switch or various switches for the
vehicle.
The power liftgate has 3 functions.
Hands-free function
*
The liftgate can be opened and closed
by doing a kicking motion when both
hands are occupied, such as when
holding groceries or luggage.
Liftgate easy closure
The easy closure assists in closing the
liftgate.
When you close the liftgate to the
position where it is slightly ajar, it will
finish closing automatically to the
fully-closed position.
NOTE
If the liftgate is opened/closed
repeatedly in a short period of time,
the easy closure function may not
operate. Wait for about 2 seconds and
then try again.
Jam-safe function
The jam-safe function detects a person
or obstruction to prevent the person or
object from getting caught in the
liftgate.
When the jam-safe function detects
that a person or object is caught in the
liftgate while it is opening/closing
automatically, a warning sound is
activated and the liftgate moves in the
reverse direction, and then stops.
NOTE
The jam-safe function does not
operate while the easy closure is
operating (from ajar position to fully
closed position).
Warnings and Cautionsfor Using the Power Liftgate
WARNING
Always check the safety of the area
around the liftgate before operating/
closing it automatically.
Not checking the safety of the area
around the liftgate for people before
opening/closing the liftgate
automatically is dangerous. A person
could become caught between the
liftgate and an obstruction while it is
opening automatically or between the
liftgate and vehicle while it is closing
automatically, resulting in an accident
and serious injury.
Keep your eyes on the liftgate when
opening/closing the liftgate
automatically.
If there is an obstruction, the liftgate
may not fully close due to the jam-safe
function. Driving the vehicle with the
liftgate not fully closed is dangerous as
a person or an object could fall out of
the vehicle resulting in a serious
accident, injury, or death.
Do not let a child operate the
switches.
If the liftgate is opened/closed
unexpectedly by a child operating the
switches mistakenly, the child or
another occupant's head or hands
could get caught, resulting in an
accident and serious injury.
Opening/closing
Liftgate
*Some models.4-19
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Always make sure that there is no
person or obstruction around the
liftgate before closing the liftgate.
The jam-safe function detects a person
or obstruction to prevent the person or
object from getting caught. The system
may not detect certain objects
obstructing the liftgate depending on
the way they are positioned and their
shape. Be especially careful with
children. It may result in an injury if a
finger gets pinched.
CAUTION
When closing the liftgate, make sure
that there is no foreign matter
around the striker. If foreign matter is
obstructing the striker, the liftgate
may not close properly.
1. Striker
 Do not install accessories to the
liftgate other than those
specified.
Otherwise, the liftgate may not
open/close automatically resulting in
a malfunction.
 When the liftgate is switched from
automatic to manual operation, the
liftgate may open/close
unexpectedly depending on its
position, resulting in injury.
Be careful that your fingers do not
get pinched in a closing liftgate. The
liftgate finishes closing to the
fully-closed position automatically
after you close it to where it is slightly
ajar. If your fingers get pinched, it
may result in an injury.
 Do not apply excessive force to the
liftgate when closing it. Otherwise, it
could cause a system malfunction.
 Sensors are installed on both ends of
the liftgate. Be careful not to allow
the sensors to be scratched or
damaged by sharp objects.
Otherwise, the liftgate may no longer
open/close automatically. In
addition, if the sensor is damaged
while the liftgate is closing
automatically, the liftgate stops.
1. Sensor
 Do not paint the rear bumper or
install any add-on equipment to it.
Otherwise, the hands-free sensor
may not operate normally.
 If you are carrying the key around the
liftgate or there is another person
around the liftgate who is carrying a
key, do not allow the following to
occur. Otherwise, the hands-free
sensor will operate and the liftgate
may open/close unexpectedly
resulting in an accident.
Opening/closing
Liftgate
4-20
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

To prevent an unintended operation,
place the key outside of its operation
range or turn off the hands-free
function using Mazda Connect.
A person not carrying a key does
the kicking motion.
 While the liftgate is open, a person
sitting on the edge of the luggage
compartment swings his or her
legs.
 Installing/removing the body cover
or removing snow around the rear
bumper.
 Picking up something which was
dropped under the rear bumper.
 Spraying water on the rear bumper
using a high water pressure car
washer.
 Pushing a shopping cart close to
the rear bumper.
 A moving object such as an animal
or a ball approaches the rear
bumper.How to Use the Power
Liftgate
NOTE
In the following cases, the liftgate
may not open/close automatically.
The vehicle is parked on an incline.There are strong winds.There is snow on the liftgate.If the lead-acid battery is
disconnected with the liftgate open,
the liftgate cannot be opened/
closed automatically. To restore the
automatic open/close function, fully
close the liftgate manually.
If the system detects weight such as
that caused by a snow-laden liftgate
when it is opened automatically, a
warning sound is activated, the
liftgate moves in the reverse
direction, and then stops.
If the selector lever is shifted to
another position and the vehicle is
moved while the liftgate is opening/
closing automatically, a warning
sound is activated and the liftgate
closes.
The liftgate may close unexpectedly
after opening it on slopes. Always
make sure that the liftgate is
stationary.
When the following operations are
performed, the hazard warning lights
flash 2 times, a warning sound is
activated, and the liftgate
automatically opens/closes fully.
Opening/closing
Liftgate
4-21
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Opening/closing using the liftgate
open/close switch () on the key
Press the liftgate open/close switch on
the key for 1 second or longer when all
of the following conditions are met.
The vehicle power is switched OFF.The vehicle is stopped.
Opening/closing the liftgate using the
power liftgate switch
Press the power liftgate switch for 1
second or longer when all of the
following conditions are met.
The vehicle is stopped.The vehicle power is switched to a
position other than ON, or the
selector lever is in the P position with
the vehicle power switched ON
All the doors are unlocked (when
opening)
Opening the liftgate using the electric
liftgate opener
Press the electric liftgate opener when
all of the following conditions are met.
The vehicle power is switched to a
position other than ON, or the
selector lever is in the P position with
the vehicle power switched ON
All the doors are unlocked.
NOTE
The liftgate can be opened even while
the doors are locked by pressing the
electric liftgate opener while carrying
the key.
Closing the liftgate using the power
liftgate close switch
Press the power liftgate close switch
when all of the following conditions
are met.
The vehicle power is switched to a
position other than ON, or the
selector lever is in the P position with
the vehicle power switched ON
Closing using the door-lock switch on
the liftgate*
Press the door-lock switch on the
liftgate when all of the following
conditions are met.
You are carrying the key.The vehicle power is switched OFF.All the doors are closed.
Opening/closing
Liftgate
4-22*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

The liftgate is not automatically
opening/closing.
The doors, liftgate, and the fuel-filler
lid/charging port lid are locked, the
hazard warning lights operate 1 time.
Then, the liftgate fully closes
automatically.
Opening/closing using the hands-free
function*
Do the kicking motion with all of the
following conditions met while the
vehicle is stopped.
You are carrying the key.The hands-free function is on.The vehicle power is switched to a
position other than ON, or the
selector lever is in P with the vehicle
power switched ON.
A : About 30―50 cm (12―19.7 in)
B : About 10 cm (3.9 in)

When the kicking motion is done
correctly, the hazard warning lights
flash 2 times, a beep sound is
activated, and the liftgate opens/
closes automatically. Be careful not to
contact the liftgate.
Move your foot away from under the
bumper within about 1 second after
moving it under the bumper.
If the kicking motion is done while the
liftgate is opening/closing
automatically, the liftgate will stop. If
the kicking motion is done again, the
liftgate moves in the direction opposite
to the direction it was moving before it
stopped.
CAUTION
Do not do the kicking motion while
wearing footwear which exposes the
feet, such as sandals. If your foot
contacts the hot exhaust pipe, it
could cause serious burns.
 Do not do the kicking motion while
the area where you are standing is
unstable such as a slope or icy road.
Otherwise, you could fall down,
resulting in injury.
NOTE
The hands-free sensor detects in a
range of about 30 cm on both the
left and right sides from the center of
the rear bumper.
The hands-free sensor may not
operate normally under the following
conditions.
Opening/closing
Liftgate
*Some models.4-23
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Your foot remains placed within
the detection area.
You move your foot left and right
within the detection area.
The kicking motion is too fast or
too slow.
Your foot contacts the rear bumper
when doing the kicking motion.
You are wearing shoes such as
rubber boots which do not
conduct electricity well.
There is equipment emitting strong
radio waves near the vehicle.
The detection area of the
hands-free sensor is dirty.
When the detection area of the
hands-free sensor is dirty, wipe it off
with a clean cloth. Before cleaning
the sensor, place the key outside of
its operation range or turn off the
hands-free function using Mazda
Connect.
If the operation using the hands-free
sensor is not possible even though
the operation conditions are met,
consult an Authorized Mazda Dealer.
Hands-free function ON/OFF
switching
The hands-free function can be
switched on/off.
Refer to Mazda Connect Owner's
Manual or consult an Authorized
Mazda Dealer.
To prevent an unintended operation,
turn off the function.
Stopping the liftgate
If any of the following operations is
done, the automatic opening and
closing of the liftgate stops.
The liftgate open/close switch on the
key is pressed.
The power liftgate switch is pressed.The electric liftgate opener is
pressed.
The power liftgate close switch is
pressed.
The door-lock switch on the liftgate
is pressed.
The kicking motion is done.
NOTE
The liftgate cannot be stopped when it
is half open or lower. It moves in the
close direction by the load weight of
the liftgate itself.
The automatic opening/closing of the
liftgate can be stopped using the
kicking motion even if you do not have
the key.
Moving the liftgate again
If any of the following operations is
done, the liftgate moves in the
direction opposite to the direction it
was moving before it stopped.
The liftgate open/close switch on the
key is pressed for 1 second or longer.
The power liftgate switch is pressed
for about 1 second or longer.
The electric liftgate opener is
pressed.
The power liftgate close switch is
pressed.
When the door-lock switch on the
liftgate is pressed, the liftgate
automatically fully closes.
Opening/closing
Liftgate
4-24
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Convenient Ways to Usethe Power Windows
Operation Function After Vehicle
power is Switched OFF
All the windows can be opened and
closed for approximately 40 seconds
after the vehicle power is switched to
ACC or OFF with all doors closed. If
any door is opened, the power
window will stop operating.
Remote Power Window Operation
All power windows can be opened
from outside the vehicle after the
doors are closed.
The power windows can be operated
remotely when the power window lock
button on the driver's door is in the
lock or unlocked position.
Remote power window operation is
activated under the following
conditions.
All the doors and liftgate are closed.The vehicle power is switched OFF.
NOTE
The power windows cannot be
opened from the outside of the vehicle
if the power window initialization has
not been completed.
Opening
The windows can be opened for
ventilating the cabin before getting in
the vehicle.
Press the unlock button on the key
quickly and briefly 3 times and then
immediately afterwards, press and
hold the unlock button to open the
windows.
To stop the windows from opening ,
release the button. If the operation is
performed from the beginning again,
the windows open.
Opening/closing
Windows
4-30
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
