Voice commands other than those specified, cannot be recognized. Speak in the
wording specified by the voice commands.
It is not necessary to face the microphone or approach it. Speak the voice
commands while maintaining a safe driving position.
Close the windows and the moonroof*/panorama sunroof* to reduce loud noises
from outside the vehicle and to prevent th e airflow of the air-conditioning system
from being a disturbance when using Bluetooth
® Hands-Free.Make sure that the air flow from the air conditioner is not blowing on the
microphone.
If the voice recognition is poor with th e guidance volume set to high, set the
Barge-In to OFF.
Examples of available voice commands
The specified name and number are put into the {}.
Common
BackHelp (You can listen to help guidance at each screen.){Line Number} (You can select the line number on the screen.)Next PagePrevious PageCancel
Menu
AllNavigationEntertainmentCommunication
Setting
Voice Recognition SettingsDisplay Off
Music
Play Artist (You can also use “Play Artist {Artist name}”.)Play Album (You can also us e “Play Album {Album Name}”.)Play Playlist (You can also use “Play Playlist {Playlist Name}”.)Play Song (You can also use “Play Song {Song Name}”.)Play Audiobook (You can also use “Play Audiobook {Audiobook Name}”.)Play Podcast (You can also use “Play Podcast {Podcast Name}”.)
Radio
Tu n e t o { F re q u e n c y } A MTu n e t o { F re q u e n c y } F MTune to {Frequency} HD {Sub Channel}SiriusXM Channel {Channel Number}
Other Equipment
Mazda Connect
*Some models.7-17
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Appendix
Gracenote® Database
When connecting a USB audio device or Bluetooth® audio device to this unit and
playing audio, the unit searches the database stored in the vehicle for the album art.
If there is a match in the vehicle's database compilation to the music being played,
the album art is displayed. The database information stored in this device uses
database information in the Gracenote
® music recognitions service.
SiriusXM Travel Link
®*
CAUTION
ADVISORY ONLY
The weather information is subject to service interruptions and may contain errors or
inaccuracies and consequently should not be relied upon exclusively. You are urged
to check alternate weather information sources prior to making safety related
decisions. You acknowledge and agree that you shall be solely responsible for use of
the information and all decisions taken with respect thereto. By using this weather
service, you release and waive any claims against Sirius XM Radio Inc. and Mazda
Motor Corporation and all of their respective affiliates with regard to this service.
SiriusXM
® Satellite Radio*
Products/applications shall display “Call [Appropriate Phone Number] to Enable
Services” for any unsubscribed SiriusXM Data Service(s).
This shall be shown on the same screen as the Radio ID and the service subscription
status:
Contact your SiriusXM Representative for the appropriate call center phone number.
U.S.A.: 1-877-447-0011Canada: 1-877-438-9677
SiriusXM
® All Access Subscription
Hopefully, you're already loving SiriusXM in your new Mazda. But don't stop there
— you can also listen on the app and online. All Access is the very best subscription
package – with the most channels and the most flexibility. With All Access, you get
every channel available on your vehicle, plus you can listen on the app, online, and
in your home on a variety of connected devices. — so you can enjoy SiriusXM
wherever you are. Here's what's included:
Over 150 satellite channels to enjoy in your car, coast-to-coast, 24/7.All kinds of commercial-free music, plus every major sport, world-class news and
the biggest names in talk & entertainment.
Other Equipment
Mazda Connect
*Some models.7-21
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

How to Use the WirelessCharger (Qi)
1. Start the hybrid system.The power for the Wireless Charger
(Qi) turns on and the LED indicator
turns on.
2. Place a device compliant with the
Qi Wireless Charging standard
(portable device with a maximum
power consumption of 5 W or 15
W or below) in the center of the
charging area on the tray.
1. Charging area
2. LED indicator
The LED indicator turns on in amber
or green when charging starts.
Charging starts when all the doors
and liftgate are closed.
For details on the LED indicator, refer
to the following LED indicator table.
Charging status display
The charging status of the Wireless
Charger (Qi) can be checked with the
LED indicator or the icon displayed on
the center display.
Illumina-
tion/flash pattern Icon indi-
cation Status
Does not turn on ―Indicates that charg-
ing is turned
off.
Tu r n s o n i n white
Indicates that charg-
ing is possible.
Tu r n s o n i n amber
Indicates normal
charging.
Tu r n s o n i n green
Indicates fast charg-
ing*1.
Flashes in white
Indicates that the
charging conditions
are not met.
Flashes in red
Indicates that charg-
ing is not possible
because a high tem-
perature is detected.
Indicates that charg-
ing is not possible
because foreign mat-
ter is detected.
Tu r n s o n i n red
Indicates that there
is a problem with
Wireless Charger
(Qi) and it needs to
be repaired. Consult
an Authorized Maz-
da Dealer.
*1 Some mobile devices can switchbetween normal charging and fast
charging.
Other Equipment
Wireless Charger (Qi)
7-56
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Windshield Wipers Operate at High
Speed.................................... 8-34Have the Vehicle Inspected ..........
.......................................... 8-34
Washer Fluid Does Not Spray ...........
............................................ 8-35 Inspecting Washer Fluid
Level................................... 8-35
Active Driving Display Does Not
Operate................................. 8-36 Active Driving Display Does Not
Operate.............................. 8-36
Warning/Indicator Light Turns
On........................................ 8-37 Warning Lights..................... 8-37
Brake System Warning
Light................................... 8-37
Lead-Acid Battery Charging
System Warning Light........... 8-38
Hybrid System Warning
Light................................... 8-39
Remaining High Voltage Battery
Power Warning Light............ 8-39
Charging System Warning
Light................................... 8-40
Output Restriction Warning
Light................................... 8-40
Engine Oil Warning Light...... 8-41
High Engine Coolant Temperature
Warning Light...................... 8-41
Electric Power Steering Warning
Light................................... 8-42
Shift System Warning Light ...........
.......................................... 8-42
ABS Warning Light................8-43
Master Warning Light........... 8-43Brake Control System Warning
Light................................... 8-44
Electric Parking Brake (EPB)
Indicator Light..................... 8-44
Check Engine Warning
Light................................... 8-45
Automatic Transmission Warning
Light................................... 8-45
AWD Warning Light............. 8-46
Tire Pressure Monitoring System
(TPMS) Warning Light
(Flashing)............................ 8-46
TCS/DSC Indicator Light (Turns
on)..................................... 8-47
Air Bag/Seat Belt Pretensioner
System Warning Light........... 8-47
KEY Warning Light (Red)....... 8-48
Security Indicator Light......... 8-48
High Beam Control System (HBC)
Warning Light (Amber)
*........ 8-49
i-ACTIVSENSE Warning
Light................................... 8-49
Exterior Lights Warning
Light................................... 8-50
Low Fuel Warning Light.........8-50
Check Fuel Cap Warning
Light................................... 8-51
Engine Oil Level Warning
Light................................... 8-51
Seat Belt Warning Light (Front
Seat)................................... 8-52
Seat Belt Warning Light (Rear
Seat) (Red).......................... 8-52
Rear Seat Alert Warning Light
*......
.......................................... 8-53
Low Washer Fluid Amount
Warning Light
*..................... 8-53
Door-ajar Warning Light/Liftgate-
open Warning Light/Hood-open
Warning Light...................... 8-54
8-2*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Ta k i n g A c t i o n w i t hOverheating
If the engine coolant temperature
gauge indicates overheating and the
high engine coolant temperature
warning light is displayed, the vehicle
loses power or you hear a loud
knocking or pinging noise, the engine
is probably too hot.
WARNING
Pull over to a safe location, then
switch the vehicle power off and
make sure the fan is not running
before attempting to work near the
cooling fan.
Working near the cooling fan when it is
running is dangerous. The fan could
continue running indefinitely even if
the engine has stopped and the engine
compartment temperature is high. You
could be hit by the fan and seriously
injured.
Do not remove either
cooling system cap when the engine
and radiator are hot.
When the engine and radiator are hot,
scalding coolant and steam may shoot
out under pressure and cause serious
injury.
Open the hood ONLY after steam is
no longer escaping from the engine.
Steam from an overheated engine is
dangerous. The escaping steam could
seriously burn you.

1. Drive safely to the side of the road and park off the right-of-way.
2. Shift into park (P).
3. Apply the parking brake.
4. Turn off the air conditioner.
5. Check whether coolant or steam is escaping from the engine
compartment.

If steam is coming from the engine
compartment:
Do not go near the front of the
vehicle. Stop the engine.
Wait until the steam dissipates,
then open the hood and start the
engine.

If neither coolant nor steam is
escaping:
Open the hood and idle the engine
until it cools.
CAUTION
If the cooling fan does not operate
while the engine is running, the
engine temperature will increase.
Stop the engine and call an
Authorized Mazda Dealer.
6. Make sure the cooling fan is operating, then turn off the engine
after the temperature has
decreased.
7. When cool, check the coolant level. If it is low, look for coolant leaks
from the radiator and hoses.

What to Do in Case of Emergency
Overheating
8-20
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Active Driving DisplayDoes Not Operate
If the active driving display does not
operate, switch the vehicle power off
and then restart the hybrid system. If
the active driving display does not
operate even with the hybrid system
restarted, have the vehicle inspected
at an Authorized Mazda Dealer.
What to Do in Case of Emergency
Active Driving Display Does Not Operate
8-36
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Warning Lights
If any warning/indicator light turns
on/flashes, take appropriate action for
each light. If the warning/indicator
light does not turn off, or it turns on or
flashes again, consult an Authorized
Mazda Dealer.
WARNING
If the warning light/indicator light
turns on or flashes, park the vehicle in
a safe place immediately and take
appropriate measures.
Continuing to drive the vehicle while
ignoring the illumination/flashing of
the warning light/indicator light is
dangerous because a problem may
occur to a vehicle system, the engine
may be damaged, or it could lead to
an accident.
The details for some warnings can be
viewed on the center display or
instrument cluster.
Checking Using the Center Display
1. Select “Information” on the home screen.
2. Select “Vehicle Status Monitor”.
3. Select the applicable warning to view the warning details.
Checking Using the Instrument
Cluster
Press the INFO switch on the steering
switch to display the warning
indication screen.
Refer to How to Use the Instrument
Cluster on page 5-28.
Brake System Warning Light
This warning has the following
functions:
Warning light inspection
For an operation check, make sure that
the light turns on when the vehicle
power is switched on, and turns off a
few seconds later or when the hybrid
system is started.
When the light turns on
The light turns on continuously if any
one of the following occurs:
Insufficient brake fluidBrake system (electronic brake force
distribution system) has a problem
Park the vehicle in a safe place
immediately and contact an
Authorized Mazda Dealer.
WARNING
Do not drive with the brake system
warning light illuminated. Contact an
Authorized Mazda Dealer to have the
brakes inspected as soon as possible.
Driving with the brake system warning
light illuminated is dangerous. It
indicates that your brakes may not
work at all or that they could
completely fail at any time. If this light
remains illuminated, after checking
that the parking brake is fully released,
have the brakes inspected
immediately.
What to Do in Case of Emergency
Warning/Indicator Light Turns On
8-37
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Engine Oil Warning Light
The light turns on when the engine oil
pressure decreases.
CAUTION
Do not drive the vehicle with the
engine oil warning light turned on.
Driving the vehicle with decreased
engine oil pressure may cause engine
damage.
If the engine oil warning light turns on
while driving, stop the vehicle in a safe
place and stop the hybrid system.
After that, contact an Authorized
Mazda Dealer.
High Engine Coolant
Temperature Warning Light
The light turns on if the engine coolant
temperature has increased excessively.
Check the contents of the message
displayed and take the necessary
action.
CAUTION
Do not drive the vehicle with the high
engine coolant temperature warning
light turned on. Driving the vehicle
with the engine not cooled down may
cause engine damage.
What to Do in Case of Emergency
Warning/Indicator Light Turns On
8-41
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
