How to Use the Front
Cross Traffic Alert (FCTA)
Operating the FCTA
The FCTA operates when all of the
following conditions are met.
The vehicle speed is less than about
10 km/h (6 mph).
The selector lever is in the D
position.
The system detects a vehicle
approaching at a speed of about 5
km/h (3 mph) or faster from the
front side of your vehicle.
When the FCTA is operating, the driver
is notified of the danger by the screen
display and the warning sound
according to the situation.
When your vehicle is stopped
The screen display (white)
*1 notifies
you that a vehicle is approaching.
Instrument cluster
Active driving display
360° view monitor
*1 The instrument cluster screen display (white)
is displayed only when the instrument
cluster is set to the i-ACTIVSENSE display.
When your vehicle is moving
The screen display (amber) and
warning sound notify the driver of the
possibility that a collision may occur
with an approaching vehicle.
Instrument cluster
Active driving display
360° view monitor
NOTE
The system may operate even if a
vehicle is not approaching
depending on the conditions around
your vehicle.
Driving
Front Cross Tra ffi c Alert (FCTA)
5-161
CX-90_8KG7-EA-22L_Edition1_new
2022-11-17 16:05:04

Rear Cross Traffic Alert(RCTA)
*
The RCTA assists the driver in checking
the area to the rear of the vehicle, such
as while reversing out of a parking
space. When a vehicle approaching
from the rear on the left or right is
detected, various screen displays and
warning sounds notify the driver of the
danger.
Warnings and Cautions
for Using the Rear Cross Tra ffi c Alert (RCTA)
WARNING
Do not rely completely on the RCTA.
The RCTA is a system to assist the
driver in checking the area to the rear
of the vehicle while reversing. Due to
certain limitations with the operation
of the system, the BSM warning light
may not
flash or it might be delayed
even though a vehicle is at the rear of
your vehicle. Always make it your
responsibility as a driver to check the
rear.
Driving
Rear Cross Tra ffi c Alert (RCTA)
*Some models.5-163
CX-90_8KG7-EA-22L_Edition1_new
2022-11-17 16:05:04

How to Use the Mazda Radar Cruise Control (MRCC)
MRCC operation conditions
The MRCC can be set when all of the following conditions are met.
The brake pedal is not depressed.The vehicle speed is about 0 km/h (0 mph) to 145 km/h (90 mph).The Hill Descent Control is not operating.
Setting the MRCC
1. Press the MRCC switch to turn the system on.
When the system is on, the MRCC standby indication (white) is displayed on
the screen.
2. Accelerate to the desired speed.
3. Set the vehicle speed by pressing the RES switch up (SET+) or down (SET-).
Constant speed driving starts when the vehicle speed is set. In addition, the set
speed is displayed on the screen, and the MRCC standby indication (white)
changes to the MRCC set indication (green) .
If a vehicle ahead is detected while traveling at a constant speed, the system
switches to headway control. The vehicle ahead indication is displayed on the screen
while in headway control.
Driving
Mazda Radar Cruise Control (MRCC)
5-167
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Driving condition Instrument cluster display Active driving display indication
During travel at constant
speed
During travel under head-
way control
1. Set speed
2. Vehicle ahead indication
NOTE
While in EV mode, acceleration may be restricted and the vehicle may not be able
to be driven at the set speed.
Refer to Mazda intelligent Drive Select (Mi-Drive) on page 5-95.
If there is a structure on the road or an obstruction at a low height off the ground
in front of the vehicle, the system may recognize it as a vehicle ahead.
Acceleration and deceleration by accelerator pedal operation takes priority while
traveling at a constant speed or in headway control. When the accelerator pedal is
released, the vehicle returns to driving at a constant speed or headway control at
the set speed.
If a vehicle ahead is traveling at an extremely low speed, the system may not
detect it correctly.
While driving using the MRCC, intended engine braking is not applied even if the
selector lever is operated.
The brake lights turn on while the brakes are operating by the MRCC control.The MRCC is also turned off automatically when the vehicle power is switched
OFF.
Driving
Mazda Radar Cruise Control (MRCC)
5-168
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

CAUTION
The function which recognizes speed limit signs has limitations. Always check the
set vehicle speed that was read.
 Set the speedometer display unit to the sa me unit as the speed limit sign. Differing
units will capture speeds not intended by the driver.
NOTE
The Speed Limit Assist operates only when the navigation system's SD card is
inserted.
The Speed Limit Assist uses the Tra ffi c Sign Recognition system (TSR).
Refer to Traffic Sign Recognition System (TSR) on page 5-150.
The Speed Limit Assist cannot read sp eeds of less than 30 km/h (19 mph).Set vehicle speeds read from speed limit signs can be adjusted.
Refer to the Settings section in the Mazda Connect Owner's Manual.
The Speed Limit Assist can be turned
off.
Refer to the Settings section in the Mazda Connect Owner's Manual.
Setting the distance-between-vehicles during headway control
1. Press the CANCEL switch up (longer distance) or down (shorter distance).
Driving
Mazda Radar Cruise Control (MRCC)
5-170
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

MRCC is not operating (white)
Distance-between-vehicles guide-line
(at 80 km/h (50 mph) vehicle speed) Instrument cluster display
Active driving display indica-
tion
Long (about 50 m (164 ft))
Medium (about 40 m (131 ft))
Short (about 30 m (98 ft))
Extremely short (about 25 m (82
ft))
Driving
Mazda Radar Cruise Control (MRCC)
5-171
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

MRCC is operating (green)
Distance-between-vehicles guide-line
(at 80 km/h (50 mph) vehicle speed) Instrument cluster display
Active driving display indica-
tion
Long (about 50 m (164 ft))
Medium (about 40 m (131 ft))
Short (about 30 m (98 ft))
Extremely short (about 25 m (82
ft))
Driving
Mazda Radar Cruise Control (MRCC)
5-172
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

NOTE
The distance-between-vehicles can be set to 4 levels: Long, medium, short, and
extremely short distance.
The distance-between-vehicles differs depending on the vehicle speed, and the
slower the vehicle speed, the shorter the distance.
Close proximity warning
If your vehicle approaches a vehicle ahead while in headway control, a warning
sound and a display cautions you.
1. “Depress Brake Pedal”
NOTE
The close proximity warning may not be activated in the following cases.
The vehicle is driven at the same speed as the vehicle ahead.Directly after the MRCC is set.Immediately after the accelerator pedal is released.Another vehicle cuts into the driving lane.Do not use the MRCC under conditions in which the close proximity warnings are
frequently activated.
The MRCC is canceled temporarily
If any of the following conditions is met, the MRCC is canceled temporarily.
The brake pedal is depressed.The CANCEL switch is pressed one time.The DSC has operated.The Smart Brake Support (SBS) has operated.The front radar sensors cannot detect target objects.The parking brake is applied.Any door is opened.The driver’s seat belt is unfastened.The frequency of the braking operation by the MRCC is high.
If the MRCC is temporarily canceled, it will resume operation at the previously set
speed by pressing the RES switch.
