2023 TOYOTA COROLLA Owners Manual

4339-1. For owners
9
For owners
WARNING
●Modifications du panneau de
porte avant (par exemple,
perçage d'un trou dans le pan-
neau)
●Réparations ou modifications
des ailes avant, du pare-chocs
avant ou des flancs de l'habita-
cle
●Installation d'un protège-calan-
dre (pare-buffle, pare-kangou-
rou, etc.), de chasse-neige, de
treuils ou d'un porte-bagages de
toit
●Modifications du système de
suspension du véhicule
●Installation d'appareils électro-
niques tels que les émet-
teurs/récepteurs radios mobiles
et les lecteurs CD
●Modifications de votre véhicule
pour une personne atteinte d'un
handicap physique

4349-1. For owners

435
Index
.What to do if... (Trouble-shooting) ................... 436
Alphabetical Index....... 439

436What to do if... (Troubleshooting)
1-1.What to do if... (Troubleshooting)What to do if... (Troubleshooting)
If you lose your keys or
mechanical keys, new genu-
ine keys or mechanical keys
can be made by your Toyota
dealer. ( P.381)
 If you lose your keys or elec-
tronic keys, the risk of vehicle
theft increases significantly.
Contact your Toyota dealer
immediately. ( P.381)
 Is the key battery weak or
depleted? ( P.333)
 Vehicles with a smart key sys-
tem: Is the engine switch in
ON?
When locking the doors, turn the
engine switch off. ( P.157)
 Vehicles with a smart key sys-
tem: Is the electronic key left
inside the vehicle?
When locking the doors, make sure
that you have the electronic key on
your person.
 The function may not operate
properly due to the condition
of the radio wave. ( P.109,
121)
 Is the child-protector lock set?
The rear door cannot be opened
from inside the vehicle when the
lock is set. Open the rear door from
outside and then unlock the
child-protector lock. ( P. 1 1 6 )
 Is the shift lever in P?
( P.154)
 Is the steering wheel
unlocked? ( P.154)
 Is the battery discharged?
( P.383)
 Did you press the engine
switch while firmly depress-
ing the brake pedal?
( P.155)
If you have a problem,
check the following before
contacting your Toyota
dealer.
The doors cannot be
locked, unlocked, opened
or closed
You lose your keys
The doors cannot be
locked or unlocked
The rear door cannot be
opened
If you think something is
wrong
The engine does not start
(vehicles without a smart
key system)
The engine does not start
( v e h i c l e s w i t h a s m a r t k e y
system)

437What to do if... (Troubleshooting)
Is the shift lever in P?
( P.155)
 Is the electronic key any-
where detectable inside the
vehicle? ( P.120)
 Is the electronic key battery
weak or depleted?
In this case, the engine can be
started in a temporary way.
( P.382)
 Is the battery discharged?
( P.383)
 Is the engine switch in ON?
If you cannot release the shift lever
by depressing the brake pedal with
the engine switch in ON. ( P.161)
 It is locked to prevent theft of
the vehicle if the key is pulled
from the engine switch.
( P.154)
 Is the window lock switch
pressed?
The power window except for the
one at the driver’s seat cannot be
operated if the window lock switch
is pressed. ( P.136)
 The auto power off function
will be operated if the vehicle
is left in ACC or ON (the
engine is not running) for a
period of time. ( P.159)
 The seat belt reminder light is
flashing
Are the driver and the passenger
wearing the seat belts? ( P.359)
 The parking brake indicator is
on
Is the parking br ake released?
(  P.168)
Depending on the situation,
other types of warning buzzer
may also sound. ( P.356, 366)
 Did anyone inside the vehicle
open a door during setting the
alarm?
Do one of the following to deac-
tivate or stop the alarms:
The shift lever cannot be
shifted from P even if you
depress the brake pedal
The steering wheel can-
not be turned after the
engine is stopped (vehi-
cles without a smart key
system)
The windows do not open
or close by operating the
power window switches
The engine switch is
turned off aut omatically
( v e h i c l e s w i t h a s m a r t k e y
system)
A warning buzzer sounds
during driving
An alarm is activated and
the horn sounds (vehicles
with an alarm)

438What to do if... (Troubleshooting)
Unlock the doors.
 Turn the engine switch to
ACC or ON, or start the
engine. (The alarm will be
deactivated or stopped after a
few seconds.)
 Is the electronic key left inside
the vehicle?
Check the message on the
multi-information display. ( P.366)
 When a warning light turns on
or a warning message is dis-
played, refer to P.356, 366.
 Stop the vehicle in a safe
place and replace the flat tire
with the spare tire. ( P.370)
 Try the procedure for when
the vehicle becomes stuck in
mud, dirt, or snow. ( P.389)
A warning buzzer sounds
when leaving the vehicle
( v e h i c l e s w i t h a s m a r t k e y
system)
A warning light turns on
or a warning message is
displayed
When a problem has
occurred
If you have a flat tire
The vehicle becomes
stuck

439Alphabetical Index
Alphabetical Index
A
A/CAir conditioning filter ............. 331
Automatic air conditioning sys-tem ..................................... 263
Manual air conditioning system ........................................... 258
ABS (Anti-lock Brake System) ............................................... 248Warning light ........................ 358
ACA (Active Cornering Assist) ............................................... 249
Active Cornering Assist (ACA) ............................................... 249
AHB (Automatic High Beam) . 175
Air conditioning filter ............. 331
Air conditioning system Air conditioning filter ............. 331
Automatic air conditioning sys-tem ..................................... 263
Manual air conditioning system ........................................... 258
Airbags Airbag operating conditions.... 33
Airbag precautions for your child............................................. 36
Correct driving posture ........... 25
Curtain shield airbag operating conditions ............................. 34
Curtain shield airbag precautions ............................................. 36
Front passenger occupant clas- sification system ................... 41
General airbag precautions .... 36
Locations of airbags ............... 31
Modification and disposal of air- bags ..................................... 39
Side airbag operating conditions ............................................. 34
Side airbag precautions ......... 36 Side and curtain shield airbags
operating conditions .............34
Side and curtain shield airbags precautions ...........................36
SRS airbags ...........................31
SRS warning light .................357
Alarm Alarm ......................................78
Warning buzzer ....................356
Anchor brackets ... ..............50, 68
Antennas (smart key system)120
Anti-lock Brake System (ABS) ...............................................248Warning light.........................358
Approach warning ..................226
Armrest ......... ......................... ..285
Assist grips .............................285
Audio system-linked display .95, 100
Automatic air conditioning sys- tem .........................................263
Automatic High Beam ............175
Automatic light control system ...............................................174
Average fuel economy .......93, 98
Average vehicle speed .....95, 100
B
Back-up lights Replacing light bulbs ............345
Wattage ................................398
Battery Battery checking ...................308
If the battery is d ischarged ...383
Preparing and checking before winter ..................................253
Warning light.........................357
Blind Spot Monitor (BSM) ......232
Bottle holders .........................274
Brake Brake hold ............................171
Fluid..............................307, 396

440Alphabetical Index
Parking brake ....................... 168
Warning light ........................ 356
Brake assist ............................ 248
Break-in tips ........ ................... 144
Brightness control Instrument panel light control88, 91
Meter light control ................... 90
BSM (Blind Spot Monitor) ...... 232
C
Care Exterior ................................. 288
Interior .................................. 291
Seat belts ............................. 291
Wheels and wheel ornaments........................................... 288
Cargo capacity ....................... 152
Chains ..................................... 254
Child restraint system Fixed with a LATCH system ... 64
Fixed with a seat belt ............. 60
Front passenger occupant clas-sification system ................... 41
Points to remember ................ 48
Riding with children ................ 47
Types of child restraint system installation met hod ............... 50
Using an anchor bracket ........ 68
Child safety Airbag precautions ................. 36
Battery precautions ...... 309, 386
Child restraint system............. 50
Heated steering wheel and seat
heater precautions ............. 269
How your child should wear the seat belt................................ 28
Moon roof precau tions ......... 138
Power window lock switch.... 136
Power window precautions .. 135
Rear door child-protectors.... 116 Seat belt extender precautions
.............................................28
Seat belt precautions..............47
Trunk precautions ................. 117
Child-protectors...................... 116
Cleaning Exterior .................................288
Interior ..................................291
Seat belts .............................291
Wheels and wheel ornaments...........................................288
Clock ................... .....86, 88, 89, 91
Coat hooks ..............................285
Condenser ............. ..................307
Console box ............................275
Consumption screen ..............102
Continuously variable transmis- sion ................................160, 162If th e s hif t le ver ca n no t b e s hif te d from P .........................161, 164
M mode ................................165
Paddle shift switches ....164, 165
Cooling system .......................306 Engine overheating ..............387
Cruise control .........................227
Cup holders.............................274
Current fuel consumption..93, 98
Curtain shield airbags ..............31
Customizable featu res ...........412
D
Daytime running light system173
Defogger
Outside rear view mirrors ...260, 265
Rear window.................260, 265
Windshield ....................259, 264
Dimensions .............................392
Dinghy towing .........................153
Display Cruise control .......................228
Dynamic radar cruise control 222
