2023 TOYOTA COROLLA CROSS towing capacity

1484-1. Before driving
750 (5  150) = 650 lbs.)
(5) Determine the combined
weight of luggage and cargo
being loaded on the vehicle.
That weight may not safely
exceed the available cargo and
luggage load capacity calcu-
lated in Step 4.
(6) If your vehicle will be towing
a trailer, load from your trailer
will be transferred to your vehi-
cle. Consult this manual to
determine how this reduces the
available cargo and luggage
load capacity of your vehicle.
( P.150)
Cargo capacity
Total load capacity (vehicle
capacity weight) ( P.428)
When 2 people with the com-
bined weight of A lb. (kg) are rid-
ing in your vehicle, which has a
total load capacity (vehicle
capacity weight) of B lb. (kg),
the available amount of cargo
and luggage load capacity will be C lb. (kg) as follows:
B
*2 lb. (kg) - A*1 lb. (kg) = C*3 lb.
(kg)
*1: A =Weight of people
*2: B =Total load capacity
*3: C =Available cargo and luggage load
In this condition, if 3 more passen-
gers with the combined weight of D
lb. (kg) get on, the available cargo
and luggage load will be reduced E
lb. (kg) as follows:
C lb. (kg) - D*4 lb. (kg) = E*5 lb.
(kg)
*4: D =Additional weight of people
*5: E =Available cargo and luggage load
As shown in the example above,
if the number of occupants
increases, the cargo and lug-
gage load will be reduced by an
amount that equals the
increased weight due to the
additional occupants. In other
words, if an increase in the num-
ber of occupants causes an
excess of the total load capacity
(combined weight of occupants
plus cargo and luggage load),
you must reduce the cargo and
luggage on your vehicle.
Calculation formula for
your vehicle
WARNING
■Things that must not be car-
ried in the luggage compart-
ment
The following things may cause a
fire if loaded in the luggage com-
partment:

1504-1. Before driving
■Total load capacity and seating
capacity
These details are also described on
the tire and loading information
label. ( P.363)
NOTICE
■When loading cargo (vehi-
cles with a moon roof)
Be careful not to scratch the sur-
face of the moon roof.
Vehicle load limits
Vehicle load limits include
total load capacity, seating
capacity, towing capacity
and cargo capacity.
 Total load capacity (vehicle
capacity weight):  P.428
Total load capacity means the
combined weight of occupants,
cargo and luggage.
Seating capacity:  P.428
Seating capacity means the max-
imum number of occupants
whose estimated average weight
is 150 lb. (68 k g) per person.
TWR (Trailer Weight Rat-
ing):  P.156, 428
TWR means the maximum gross
trailer weight (trailer weight plus
its cargo weight) that your vehicle
is able to tow.
Cargo capacity
Cargo capacity may increase or
decrease depending on the
weight and the number of occu-
pants.

485Alphabetical Index
Registering ID codes ............ 358
Warning light ........................ 395
Tires Checking .............................. 351
If you have a flat tire ............. 405
Inflation pressure.................. 363
Information ........................... 438
Replacing ............................. 405
Rotating tires ........................ 353
Size ...................................... 434
Snow tires ............................ 279
Spare tire.............................. 405
Tire pressure warning system........................................... 353
Warning light ........................ 395
Tools ........................................ 406
Top tether strap ........................ 61
Total load capacity ................. 428
To w i n g Dinghy towing....................... 161
Emergency towing................ 385
Towing eyelet ....................... 387
Trailer towing ........................ 151
Toyota Safety Sense 3.0 Automatic High Beam .......... 181
Dynamic radar cruise control 220
Emergency Driving Stop System........................................... 235
LDA (Lane Departure Alert) .. 213
LTA (Lane Tracing Assist) ..... 208
PCS (Pre-Collision System) . 198
RSA (Road Sign Assist) ....... 218
TRAC (Traction Control) ........ 274
Traction Control (TRAC) ........ 274
Trailer towing .......................... 151
Transmission Continuously variable transmis-sion..................................... 168
If the shift lever cannot be shifted from P................................. 169
M mode ................................ 170
Trip meters .......................... 77, 80 Turn signal lights
Replacing light bulbs ............374
Turn signal lever ...................171
Wattage ................................435
U
USB charging port ..................309
V
Vanity lights ............................318
Vanity mirrors .........................318
Vehicle data recording ...............6
Vehicle identification number429
Vehicle information display85, 92
Vehicle Stability Control (VSC)...............................................274
VSC (Vehicle Stability Control) ...............................................274
W
Warning buzzers ABS ......................................393
Airbags .................................392
Approach warning ................226
Brake hold ............................398
Brake Override System ........393
Brake system ........................391
Charging system ..................392
Downshifting .........................170
Drive-Start Control ................393
Electric power steering .........393
Engine ..................................392
High coolant temperature .....391
Intuitive parking assist OFF indi- cator ...................................396
Key reminder ........................163
LDA (Lane Departure Alert) 213, 396
Low engine oil pressure .......392
