2023 JEEP WRANGLER Owners Manual

GETTING TO KNOW YOUR VEHICLE95
DOOR FRAME DOOR FRAME REMOVAL
NOTE:In four door models, the rear door frames must be
removed first, followed by the front door frames.

1. Using the provided #40 Torx head driver and
ratchet, loosen the Torx screws located on the
underside of each door frame (two per door).

Door Frame Screw Locations

2. Once all the way loosened, remove the screws by pulling downward.
NOTE:Screws will not fall out once completely loose, as they are
held in place by an internal mechanism.

Remove Screws From Below Frame

3. Lift the frame upward, removing it from the vehicle.

Step Three

WARNING!
Do not drive your vehicle on public roads with the door
frame(s) removed as you will lose the protection that
they can provide. This procedure is furnished for use
during off-road operation only.
CAUTION!
Failure to follow these cautions may cause interior
water damage, stains or mildew:
Opening a door or lowering a window while the top is
wet may allow water to drip into the vehicle's interior.
 Careless handling and storage of the removable door
frame(s) may damage the seals, causing water to
leak into the vehicle's interior.
 The door frame(s) must be positioned properly to
ensure sealing. Improper installation can cause
water to leak into the vehicle's interior.
2

23_JL_OM_EN_USC_t.book Page 95

96GETTING TO KNOW YOUR VEHICLE
4. Store screws in a secure location.
5. Repeat procedure on the front door frame (four door
models).
DOOR FRAME INSTALLATION FOUR
D
OOR MODELS — IF EQUIPPED

1. Install the front door rail first.

2. Carefully place the front door rail in the rubber seal at
the top of the windshield, and line up the holes for the
Torx head screws (two for each door).
3. Swing the frame bracket around the side of the rail, and insert the screws from underneath. Tighten with
#40 Torx head driver until they are snug, being
careful not to cross-thread the screws or overtighten.
Refer to the following table for the appropriate torque
specifications for the door rail screws.

Step Three

4. Set the rear door frame pin into the hole on top of the body side, just behind the rear door opening.

Step Four

5. Carefully position the top of the door frame onto the rear of the front door rail, making sure rubber seals lie
flat. Ensure the seals are installed correctly to avoid
water leaks.

Position Of Frame Above Door

WARNING!
Do not drive your vehicle on public roads with the
door frame(s) removed as you will lose the protection
that they can provide. This procedure is furnished for
use during off-road operation only.
 Do not drive your vehicle on public roads with the
doors removed as you will lose the protection that
they can provide. This procedure is furnished for use
during off-road operation only.
Target Torque
Specification For Torx Fasteners Maximum Minimum
79.6 in-lb (9 N·m) 87.6 in-lb
(9.9 N·m) 71.7 in-lb
(8.1 N·m)
CAUTION!
Do not overtighten the screws. You can strip the screws
if they are overtightened.
1 — Front Door Rail
2 — Rear Door Frame

23_JL_OM_EN_USC_t.book Page 96

GETTING TO KNOW YOUR VEHICLE97
(Continued)
6. Swing the frame bracket around the side of the rail,
and insert the screws from underneath. Tighten with
#40 Torx head driver until they are snug, being
careful not to cross-thread the screws or overtighten.
Refer to the previous table for the appropriate torque
specifications for the door rail screws.

Insert Screws From Below Frame

DOOR FRAME INSTALLATION TWO DOOR
M
ODELS — IF EQUIPPED

1. Carefully place the front door rail in the rubber seal
at the top of the windshield, and line up the holes for
the Torx head screws (two for each door).

2. Swing the frame bracket around the side of the rail, and insert the screws from underneath. Tighten with
#40 Torx head driver until they are snug, being
careful not to cross-thread the screws or overtighten.
Refer to the following table for the appropriate torque
specifications for the door rail screws.

Step Two

FOLDING WINDSHIELD
The fold-down windshield on your vehicle is a structural
element that can provide some protection in some
accidents. The windshield also provides some protection
against weather, road debris and intrusion of small
branches and other objects.
Do not drive your vehicle on-road with the windshield
down, as you lose the protection this structural element
can provide.
If required for certain off-road uses, the windshield can be
folded down. However, the protection afforded by the
windshield is then lost. If you fold down the windshield,
drive slowly and cautiously. It is recommended that the
speed of the vehicle be limited to 10 mph (16 km/h), with
low range operation preferred if you are driving off-road
with the windshield folded down.
Raise the windshield as soon as the task that required its
removal is completed and before you return to on-road
driving. Both you and your passengers should wear seat
belts at all times, on-road and off-road, regardless of
whether the windshield is raised or folded down.
Target Torque
Specification For Torx Fasteners Maximum Minimum
79.6 in-lb (9 N·m) 87.6 in-lb
(9.9 N·m) 71.7 in-lb
(8.1 N·m)
CAUTION!
Do not overtighten the screws. You can strip the screws
if they are overtightened.
CAUTION!
Lowering of the windshield is NOT recommended in
vehicles equipped with a Power Sliding Top. Damage
will occur to the top as well as the header seal.
WARNING!
Carefully follow these warnings to help protect against
personal injury:
 Do not drive your vehicle on-road with the windshield
down.
 Do not drive your vehicle unless the windshield is
securely fastened, either up or down.
 Eye protection, such as goggles, should be worn at all
times when the windshield is down.
2

23_JL_OM_EN_USC_t.book Page 97

98GETTING TO KNOW YOUR VEHICLE
LOWERING THE WINDSHIELD

1. Before completing the following steps:

If your vehicle is equipped with a Soft Top, the top
MUST be lowered, and the door rails must be
removed prior to lowering the windshield.
 If your vehicle is equipped with a Hard Top, the
Freedom Panels MUST be removed prior to
lowering the windshield.
 Refer to the following instructions for more infor -
mation:
• Soft Top Lowering
Úpage 75
• Door Frame Úpage 95
• Freedom Top Panels Úpage 83 2. Manually remove the protective caps over the
windshield wiper hex bolts.

Step Two

3. Using the provided 15 mm socket, remove the two hex bolts and remove the wiper arms. 4. Move to the inside of the vehicle and lower both sun
visors.
5. Using the provided #40 Torx head driver, remove the four Torx screws located along the interior of the
windshield.

Step Five

NOTE:Store all of the mounting bolts in their original threaded
holes and tighten for safekeeping.

Be sure that you carefully follow the instructions for
raising the windshield. Make sure that the folding
windshield, windshield wipers, side bars, and all
associated hardware and fasteners are correctly and
tightly assembled before driving your vehicle. Failure
to follow these instructions may prevent your vehicle
from providing you and your passengers’ protection
in some accidents.
 If you remove the doors, store them outside the
vehicle. In the event of an accident, a loose door may
cause personal injury.
WARNING!CAUTION!
Failure to follow this step will cause damage to the
vehicle’s header seal.
1 — Hex Bolt Cover Installed
2 — Hex Bolt Cover Removed
1 — Outside Torx Screws
2 — Inside Torx Screws

23_JL_OM_EN_USC_t.book Page 98

GETTING TO KNOW YOUR VEHICLE99
6. Lower the windshield gently until it contacts the
tie-down bumpers (if equipped).

Step Six

7. Secure the windshield by passing a cinch strap through the tie-down on either side of the hood and
on the windshield frame. Tighten the strap to secure
the windshield in place.
Adaptive Cruise Control (ACC)/Forward
Collision Warning (FCW) Sensor Protective
Cover — If Equipped
Your vehicle may be equipped with a protective cover that
is to be used whenever the windshield is folded down in
order to protect the Adaptive Cruise Control (ACC)/
Forward Collision Warning (FCW) sensor. To install the
cover, follow these instructions:

1. Secure the top part of the cover so that it hinges to the header.

2. Swing the cover down and push on it so that it covers the opening.
3. Check to make sure the cover is secured properly.
NOTE:Be sure to remove the cover before returning the wind -
shield to the normal position. Store the cover in the cargo
area.
Cleaning Instructions
During windshield down applications, dust/dirt can
accumulate in the cover and block the camera lens. Use a
microfiber cloth to clean the camera lens, module, and
inside cover, being careful not to damage or scratch the
module.
RAISING THE WINDSHIELD

1. Release the strap that secured the windshield in the lowered position.

2. Raise the windshield.
3. Using the provided #40 Torx head driver, reinstall the four Torx screws located along the interior of the
windshield. Secure them until they are snug, being
careful not to cross-thread the screws or overtighten.

Interior Torx Screw Locations

4. Reinstall the windshield wiper arms using the provided 15 mm socket. First, align the tips of the
blade to the “T” mark in the glass. Then, while holding
the arm in that position, reinstall the hex nut and
tighten until snug. Be careful not to overtighten.
Repeat for the other arm.
1 — Washer Nozzle
2 — Bumper
3 — Tie-DownCAUTION!
Do Not Overtighten! Damage to the windshield could
result.
1 — Outside Torx Screws
2 — Inside Torx Screws
2

23_JL_OM_EN_USC_t.book Page 99

100GETTING TO KNOW YOUR VEHICLE
5. Reinstall the protective caps over the wiper arm hex
bolts and push gently until they snap into place.

Step Five

6. After completing the steps above:
If your vehicle is equipped with a Soft Top, reinstall
the Door Rails and raise the top.
 If your vehicle is equipped with a Hard Top, rein -
stall the Freedom Panels.
HOOD
OPENING THE HOOD
If applicable, refer to the “Hybrid Supplement” for
additional information.
Release both of the outside hood latches.

Hood Latch Locations

Raise the hood slightly, and place a hand palm-side down
in the center of the hood opening. Locate the safety latch
in the middle, and push the latch to the right to open.

Place Hand In Hood Opening

Remove the support rod from the hood, and insert it into
the radiator crossmember.

Hood Prop Rod Slot

1 — Hex Bolt Cover Installed
2 — Hex Bolt Cover Removed

23_JL_OM_EN_USC_t.book Page 100

GETTING TO KNOW YOUR VEHICLE101
NOTE:
Vehicle must be at a stop and the gear selector must
be in PARK.
 You may have to push down slightly on the hood before
pushing the safety latch.
 While lifting the hood, use both hands.
 Before lifting the hood, check that the wiper arms are
not in motion and not in the lifted position.
CLOSING THE HOOD
If applicable, refer to the “Hybrid Supplement” for
additional information.
To close the hood, remove the support rod from the slot
and replace it on the hood panel retaining clip. Lower the
hood slowly. Secure both of the hood latches.
REAR SWING GATE
The rear swing gate can be unlocked by using one of the
following methods:
Mechanical key (with mechanical lock — if equipped)
 Remote Keyless Entry key fob (if equipped)
 Power door unlock switch on the front doors (if
equipped)
 Passive Entry swing gate handle (if equipped)
To open the swing gate, pull on the handle.

Swing Gate Handle

NOTE:Close the rear flip-up window before attempting to close
the swing gate (hard top models only).
NOTE:The swing gate hinges and check strap may require
cleaning if a squeak can be heard when opening the swing
gate. Progressive accumulation of dirt or debris on the
check strap arm may cause failure of the check strap,
requiring replacement. For further information on vehicle
cleaning procedures, see
Úpage 362.
WARNING!
Be sure the hood is fully latched before driving your
vehicle. If the hood is not fully latched, it could open
when the vehicle is in motion and block your vision.
Failure to follow this warning could result in serious
injury or death.
CAUTION!
To prevent possible damage, do not slam the hood to
close it.
WARNING!
Driving with the flip-up window open can allow
poisonous exhaust gases into your vehicle. You and
your passengers could be injured by these fumes. Keep
the flip-up window closed when you are operating the
vehicle.
CAUTION!
Do not push on rear wiper blade when closing the rear
flip-up window, as damage to the blade will result.
2

23_JL_OM_EN_USC_t.book Page 101

102GETTING TO KNOW YOUR VEHICLE
CARGO AREA FEATURES
Cargo Tie-Down Hooks And Loops
The cargo tie-downs, located on the cargo area floor,
should be used to safely secure loads when the vehicle is
moving.

Cargo Tie-Down Loops (Four Door Models)
Cargo Tie-Down Loops (Two Door Models)

ROOF LUGGAGE RACK — IF EQUIPPED
NOTE:Roof rack applications are for Hard Top models ONLY.
The load carried on the roof, when equipped with a
luggage rack, must not exceed 100 lb (45 kg), this
includes the weight of the crossbars, and it should be
uniformly distributed over the cargo area.
Crossbars should always be used whenever cargo is
placed on the roof rack. Check the straps frequently to be
sure that the load remains securely attached.
NOTE:Crossbars can be purchased at an authorized dealer
through Mopar® parts.
External racks do not increase the total load carrying
capacity of the vehicle. Be sure that the total occupant
and luggage load inside the vehicle, plus the load on the
luggage rack, does not exceed the maximum vehicle load
capacity.
WARNING!
 Cargo tie-downs are not safe anchors for a child seat
tether strap. In a sudden stop or accident, a tie-down
could pull loose and allow the child seat to come
loose. A child could be badly injured. Use only the
anchors provided for child seat tethers.
 To help protect against personal injury, passengers
should not be seated in the rear cargo area. The rear
cargo space is intended for load carrying purposes
only, not for passengers, who should sit in seats and
use seat belts.
The weight and position of cargo and passengers can
change the vehicle center of gravity and vehicle
handling. To avoid loss of control resulting in personal
injury, follow these guidelines for loading your vehicle:
 Do not carry loads that exceed the load limits
described on the label attached to the left door or left
door center pillar.
 Always place cargo evenly on the cargo floor. Put
heavier objects as low and as far forward as possible.
 Place as much cargo as possible in front of the rear
axle. Too much weight or improperly placed weight
over or behind the rear axle can cause the vehicle to
sway.
 Do not pile luggage or cargo higher than the top of
the seatback. This could impair visibility or become a
dangerous projectile in a sudden stop or accident.
WARNING!
Cargo must be securely tied down before driving your
vehicle. Anything improperly secured to the roof rack,
crossbars, or the roof itself can fly off the vehicle,
particularly at high speeds, resulting in collisions,
personal injury or property damage. Follow the roof rack
cautions when carrying anything on your roof or roof
rack.

23_JL_OM_EN_USC_t.book Page 102
