171. Charging operation
1
Charging operation
NOTICE
■When charging
Do not insert the plug into the charging inlet.
The charging inlet may be damaged.
■ After charging
● Store the charging cable out of reach from infants and children .
● After disconnecting the charging connector from the charging in let, make
sure to put on the charging inlet cap and close the charging port lid.
If the charging inlet cap is not put on, water or foreign objects may enter
the charging inlet, which could lead to vehicle damage.
● After removing the plug from the outlet, keep it in a safe plac e free from
moisture and dust.
The charging cable or plug may be damaged if the cable is stepp ed on or
ridden over by the vehicle.
■ Using private power generator
Do not use private power generators as a power source for charg ing.
Doing so may make charging unstable, the voltage may be insuffi cient, and
the error warning indicator on the CCID (Charging Circuit Inter rupting
Device) of the charging cable may flash.
■ Charging station
Due to the environment in which the power equipment is located, charging
may be unstable due to noise, the voltage may be insufficient, and the error
warning indicator on the CCID (Charging Circuit Interrupting De vice) of the
charging cable may flash.

18
PRIUS PRIME_QG_OM47D86U_(U)
1. Charging operation
Using the charging schedule function
Charging can be carried out at the desired time by registering the
charge schedule. When registering the charge schedule, the foll owing
settings can be changed.
● Select the charging mode (“Start”/“Departure”)
● Repeated setting
● Air conditioning-linked setting (“Climate Prep”)
● Turning “Charge Now” on and off
● Changing “Next Charging Event”
For details of each settings, refer to “OWNER’S MANUAL”.
The charge schedule can be registered on the multi-information dis-
play or 11.6-inch display (if equipped).
When operating charging schedule, use the charging schedule swi tch
and meter control switches.
Charging schedule switch
Meter control switches
Multi-information display
Charging schedule function
Setting operations on multi-information display
1
2
3

PRIUS PRIME_QG_OM47D86U_(U)
191. Charging operation
1
Charging operation
■Registering the charge schedulePress the charging schedule switch.
The “Charge Schedule” screen will display on the multi-informat ion dis-
play.
Press or of the
meter control switches to
select “Scheduled Events”,
and then press .
The “Scheduled Events” screen
will display.
For information about setting of the items other than “Schedule d
Events”, refer to “OWNER’S MANUAL”.
Press or of the
meter control switches to
select “+”, and then press
.
The “Edit Charging Event”
screen will display.
Operate the meter control switch es to select the item and change
the setting.
After changing the settings to the desired settings, press to return to
the previous screen.
After setting operations are complete, when the charging cable is con-
nected to the vehicle, charging will be carried out according to the
charging schedule settings.
1
2
3
4

20
PRIUS PRIME_QG_OM47D86U_(U)
1. Charging operation
■Changing the registered charge schedules
The registered charge schedules can be turned on, off, deleted or
modified.
Press the charging schedule switch.
The “Charge Schedule” screen will display on the multi-informat ion dis-
play.
Press or of the
meter control switches to
select “Scheduled Events”,
and then press .
The “Scheduled Events” screen
is displayed, which displays a
list of the registered charge
schedule.
Press or of the
meter control switches to
select the item to change,
and then press .
The “Edit Charging Event”
screen will display.
Operate the meter control
switches to select the item
and change the setting.
1
2
3
4

PRIUS PRIME_QG_OM47D86U_(U)
211. Charging operation
1
Charging operation
Press the “MENU” button, then select “Info” and “Charge Schedule”.
For details of “Charge Schedule” screen, refer to “OWNER’S
MANUAL”.
■Registering the charge schedule Display the “Charge Schedule” screen.
Press “Add”.
Select the charging mode.
Operate the time setting wheel to set the start (or departure)
time.
When activating the repeated settings, press the desired day bu t-
ton.
When the charging mode is set to “Departure”, set the “Climate
Prep” to on or off.
After setting operations are complete, press “Save”.
To cancel registration of the charging schedule, press .
After setting operations are complete, when the power switch is turned
off and the charging cable is connected to the vehicle, charging is car-
ried out according to the charging schedule settings.
Setting operations on the 11.6-inch display (if equipped)
1
2
3
4
5
6
7

22
PRIUS PRIME_QG_OM47D86U_(U)
1. Charging operation
■Changing the registered charge schedulesDisplay the “Charge Schedule” screen.
From the items displayed on the bottom of the screen, press
“Edit” in the row of the char ge schedule you wish to change.
The settings screen will display on the bottom of the screen.
It is also possible to display the settings screen by pressing the icon of
the charge schedule you wish to change from those displayed on the
calendar.
1
2

23
PRIUS PRIME_QG_OM47D86U_(U)
1. Charging operation
1
Charging operation
Charging tips
Information related to charging can be displayed and checked on the
multi-information display.
For details on the screen display for the 11.6-inch display (if equipped),
refer to “OWNER’S MANUAL”.
■
While charging
When any door is opened
during charging, the current
charging condition and remain-
ing time until charging is com-
plete can be checked.
■After charging is complete
After charging is complete, the
first time that the hybrid system
is started, a message detailing
the results of the charging is
displayed. Also, a message is
displayed if an operation that
stops charging is performed or
a situation where charging can-
not be performed occurs.
Checking information related to charging

24
PRIUS PRIME_QG_OM47D86U_(U)
1. Charging operation
Inspecting and maintaining the charging
cable
For safety, inspect the charging cable on a routine basis.
WARNING
■ Routine inspection
Check the following points regularly.
Failure to do so may cause an unexpected accident, resulting in death or
serious injury.
● The charging cable, plug, charging connector, CCID (Charging Ci rcuit
Interrupting Device) etc. have not been damaged
● The outlet has not been damaged
● The plug can be securely inserted into the outlet
● The plug does not get extremely hot during use
● The tip of the plug has not been deformed
● The plug is not dirtied by dust etc.
Remove the plug from the outlet before inspecting it. If any ab normalities
are found in the charging cable as a result of the inspection, immediately
stop use and consult your Toyota dealer.
■ Maintaining the charging cable
When the charging cable is dirty, first remove the dirt with a hard, wringed
cloth, and then wipe the cable with a dry cloth.
However, never wash it with water. If the charging cable is was hed with
water, fire or electric shock may occur during charging, possib ly resulting in
death or serious injury.
■ When not using the charg ing cable for a long time
Remove the plug from the outlet. Dust could accumulate on the p lug or in
the outlet, possibly causing overheating which could lead to a fire.
Also, keep the cable in a place free from moisture.
