2021 TOYOTA HIGHLANDER Accessories, Audio & Navigation (in English)

1854-7. Rear seat entertainment system
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
4The rear seat entertainment
system can be operated from
this screen.
Adjusting the sound settings
Turning on/off the rear sys-
tem lock
• The operation lock on the rear
seat entertainment system can be
turned on or off.
Selecting the rear seat enter-
tainment system’s media
mode
Audio/visual operation but-
tons
Turning on/off the rear seat
entertainment system
A
B
C
D
E

1864-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
4-8.Rear seat entertainment system operation
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the menu screen
Displaying the option screen
Changing the audio language
Selecting a chapter
Turning on the BD/DVD
mode
Playing a Blu-ray
Disc™ (BD) and DVD
discs
This system can play
Blu-ray Disc™ (BD) videos
with digital sound. In addi-
tion to commercial BD and
DVD titles, AVCHD, BDAV
videos and Video CD can be
played on this system, so
digital TV recorded by home
digital video recorders and
BD/DVD home videos
recorded by home digital
video cameras can also be
played on this system.
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
WA R N I N G
●BD/DVD video precaution
• Conversational speech on some
BDs/DVDs is recorded at a low
volume to emphasize the
impact of sound effects. If you
adjust the volume assuming
that the conversations represent
the maximum volume level that
the BD/DVD will play, you may
be startled by louder sound
effects or startled when you
change to a different audio
source. Loud sounds may have
a significant impact on the
human body or pose a driving
hazard. Keep this in mind when
you adjust the volume.
Remote controller
A
B
C
D
E
F
G
H
I
J
K

1874-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
1Insert a disc or press the
“DISC” button.
 The player will start to play
the disc automatically.
1 Press the button to
play/pause.
 Press and hold the but-
ton while pausing, the video is
played slowly.
1 Press the “MENU” button.
2 Select the menu item, and
press the “ENT” button to
enter.
Press the “OPTION” button
while watching a BD/DVD video,
the following screen appears.
Press the “OPTION” button
once again or select “Hide But-
tons” to turn off the option
screen.
When there are two pages,
select “>” or “<” to change the
page.
BD video
DVD video
Turning on the BD/DVD
mode
Playing/pausing a disc
Operating the disc menu
Option screen

1884-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
AV C H D
BDAV
Video CDDisplaying the initial setup
screen
Turning off the option screen
Displaying the top menu
screen
Displaying the pop-up menu
Rewind
Stop
Play/pause
Fast-forward
Searching for a title
Searching for a chapter
Returning to the predeter-
A
B
C
D
E
F
G
H
I
J
K

1894-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
mined scene
Changing the audio language
Changing the subtitle lan-
guage
Changing the angle
Displaying the color key but-
tons
Displaying the 10 key pad
Displaying the secondary
video (Picture-in-picture)
Changing the secondary
audio
Displaying the menu screen
Changing the playback mode
Changing the audio channel
Searching by track
Returning to the previous
page screen (with the disc
menu displayed)
Proceeding to the next page
screen (with the disc menu
displayed)
BD video
Some BD video discs have a
pop-up navigation menu that
can be called up and be oper-
ated on the screen without inter-
rupting playback.
1 Select “Pop-up Menu”.
2 Select the menu item, and
press the “ENT” button to
enter.
BD video, DVD video,
AVCHD, BDAV
1 Select “Title”, “Chapter” or
“Search”.
2 Input the title number or
chapter number, and select
“OK”.
BD video, DVD video, BDAV
The angle can be changed for
discs that are multi-angle com-
patible when the angle mark
appears on the screen.
1 Select “Angle”.
2 Each time “Angle” is
selected, the angle changes.
Displaying the pop-up menu
L
M
N
O
P
Q
R
S
T
U
V
W
X
6HDUFKLQJIRUDWL\
WOHRUFKDS
WHU
&KDQJLQJWKHDQJOH

1904-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
BD video, DVD video, AVCHD
The subtitle language can be
changed for discs with multiple
subtitle languages.
1 Select “Subtitle”.
2 Each time “Subtitle” is
selected, another language
available on the disc is
selected.
“Hide”: Subtitle can be hidden.
BD video
“Style”: Subtitle style can be
changed.
BD video, DVD video,
AVCHD, BDAV
The audio language can be
changed for discs with multiple
audio languages.
1 Select “Audio”.
2 Each time “Audio” is
selected, another language
available on the disc is
selected.
BDAV, Video CD
The audio channel can be
changed for discs with multiple
audio channels.
1 Each time “Main/Sub” is
selected, the mode changes
in the following order:
“Main”: Main audio channel
Changing the subtitle lan-
guage
Changing the audio lan-
guage
Changing the audio channel

1914-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
“Sub”: Sub audio channel
“Main/Sub”: Both the main and
sub audio channels
BDAV
The playback mode can be
changed to program mode or
playlist mode. Playlist mode
cannot be selected if a playlist is
not stored on the disc.
1 Select “Playback Mode”.
2 Each time “Playback Mode”
is selected, the mode
changes in the following
order:
“Program” mode: Playback the
disc in order of program number
“Playlist” mode: Playback the
disc in order of playlist number
BD video
Picture-in-picture is a secondary
video that plays embedded in
the primary video. The second-
ary video can be played from a
disc compatible with the pic-
ture-in-picture function.
1 Select “PinP”.
2 The secondary video is dis-
played on the screen. Each
time “PinP” is selected,
another secondary video
available on the disc is
selected.
“Hide”: Secondary video can be hid-
den.
Changing the playback mode
Displaying the secondary
video

1924-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
BD video
The secondary audio that for the
secondary video can be
changed.
1 Select “PinP Audio”.
2 Each time “PinP Audio” is
selected, another secondary
audio stored on the disc is
selected.
“Off”: Secondary audio can be
turned off
BD video
The color key button is used for
various uses according to direc-
tions of contents.
1 Select “Color Keys”.
2 The color key buttons are
displayed on the screen.
Changing the secondary
audio
Displaying the color key but-
tons
