2021 TOYOTA 4RUNNER navigation system

773-1. Basic operation
3
Navigation system
4RUNNER_NAVI_(U)some countries or areas.
1
Select on the map
screen. ( P.72)
2 Select “Map Mode”.
3 Select the desired configura-
tion button.
Select to display the single
map screen.
Select to display the dual
map screen. ( P.77)
Select to display the com-
pass mode screen. ( P. 7 8 )
Select to display the turn list
screen. ( P.99)
Select to display the freeway
exit list screen. ( P. 9 7 )
Select to display the intersec-
tion guidance screen or the
guidance screen on the free-
way. ( P. 9 8 )
Select to display the
turn-by-turn arrow screen.
( P. 9 9 )
 Depending on the conditions,
certain screen configuration
buttons cannot be selected. The map on the left is the main
map. The right side map can be
edited.
1
Select any point on the right
side map.
2 Select the desired item.
Select to change the orienta-
tion of the map. ( P. 7 5 )
Select to display POI icons.
( P.78)
Select to show traffic infor-
mation.
* (  P. 8 1 )
Select to change the map
scale. ( P. 7 4 )
*: This function is not available in
some countries or areas.
3 Select “OK”.
Switching the map mode
A
B
C
D
E
F
G
'XDOPDS
A
B
C
D

793-1. Basic operation
3
Navigation system
4RUNNER_NAVI_(U)
3Check that the selected POI
is displayed on the map
screen.
The traveled route can be stored
and retraced on the map screen.
This feature is available when
the map scale is 30 miles (50
km) or less.
1 Select on the map
screen. ( P.72)
2 Select “Route Trace”.
 The route trace starts.
3 Check that the traveled line is
displayed. 1
Select on the map
screen. ( P. 7 2 )
2 Select “Route Trace” again.
3 A confirmation screen will be
displayed.
“Yes”: Select to keep the recorded
route trace.
“No”: Select to erase the recorded
route trace.
●The traveled route can be stored
up to approximately 621 miles
(1000 km).
When the cursor is placed over
an icon on the map screen, the
name is displayed at the top of
the screen. If is shown to the
right of the name, detailed infor-
mation can be displayed.
1Place the cursor over an
icon.
2 Select .
Route trace
Start recording the route
trace
Stop recording the route
trace
Displaying information
about the icon where the
cursor is set

813-1. Basic operation
3
Navigation system
4RUNNER_NAVI_(U)
*: This function is not available in some countries or areas.
1 Press the “MENU” button.
2 Select “Info”.
3 Select “Traffic Incidents”.
When the route has not been
set
Select to display traffic infor-
mation for the current road.
( P. 8 2 ) Select to display nearby traf-
fic information. (
P.82)
Select to display a map with
predictive traffic data.
( P.82)
Select to display traffic along
the saved routes. ( P.82)
When the route has been set
Select to display traffic infor-
mation for the set route.
( P.82)
Select to display nearby traf-
fic information. ( P.82)
Select to display a map with
predictive traffic data.
( P.82)
Select to display traffic along
the saved routes. ( P.82)
●If a large amount of information is
being received, it may take longer
than normal for th e information to
be displayed on the screen.
●If traffic information cannot be
received because the vehicle is
outside of HD Radio coverage
area, it may still be able to be
received using DCM. ( P.176)
Tr af fic infor mation*
Traffic data can be received
via HD Radio™ broadcast or
via DCM (Data Communica-
tion Module) to display traf-
fic information on the map
screen.
Displaying the traffic
screen
A
B
C
D
A
B
C
D

833-1. Basic operation
3
Navigation system
4RUNNER_NAVI_(U)“Options”: Select to add, edit or
delete personal traffic routes.
(
 P. 1 1 1 )
 If routes have not been regis-
tered yet, a confirmation
screen will be displayed.
Select “Yes” to register the
route.
4 Select the desired traffic
information.
5 Check that the traffic informa-
tion is displayed.
“Detail”: Select to display detailed
traffic information.
1 Select on the map
screen. ( P.72)
2 Select “Traffic Information”.
3 Check that the traffic informa-
tion is displayed.
●The icons indicate traffic incidents
such as construction, accidents,
etc. Select an ic on to hear more
detail by voice.
●The arrows indic ate the flow of
traffic. The color changes depend-
ing on the speed.
Displaying traffic informa-
tion on the map

843-2. Destination search
4RUNNER_NAVI_(U)
3-2.Destination search
The destination screen enables
to search for a destination. The
destination screen can be
reached by the following meth-
ods:
■From the map screen
1 Press the “MAP” button.
2 Select .
3 Follow the steps in “From the
menu screen” from step 3.
( P. 8 4 )
■From the menu screen
1 Press the “MENU” button.
2 Select “Destination”.
3 Select the desired search
method.
Select to set a destination by home. (
P.85)
Select to search for a desti-
nation by entering keywords.
( P.85)
Select to search for a desti-
nation via the Toyota
response center.
* (  P.234)
Select to search for a desti-
nation from a registered entry
in “Favorites”. ( P. 8 6 )
Select to search for a desti-
nation from recent set desti-
nations. ( P. 8 6 )
Select to search for a desti-
nation from emergency ser-
vice points. ( P.87)
Select to search for a desti-
nation by address. ( P. 8 7 )
Select to search for a desti-
nation by point of interest.
( P.88)
Select to search for a desti-
nation from contact data
which had been transferred
to the navigation system from
a registered Bluetooth
®
phone. ( P.87)
*: This function is not available in
some countries or areas.
●To hide the destination screen,
touch any part of the map screen.
Destination search
operation
Destination screen
A
B
C
D
E
F
G
H
I

853-2. Destination search
3
Navigation system
4RUNNER_NAVI_(U)
The selected state (province)
can be changed to set a desti-
nation from a different state
(province) by using “Address” or
“Point of Interest”.
1Display the destination
screen. ( P.84)
2 Select “Address” or “Point of
Interest”.
3 Select “Change State/Prov-
ince”.
 If a state (province) has not
been selected yet,
“State/Province” screen is dis-
played directly.
4 Select the desired state
(province).
 To change countries, select
“Change Country”. To use this function, it is neces-
sary to register a home address.
(
P.103)
1 Display the destination
screen. ( P. 8 4 )
2 Select “Home”.
 The navigation system per-
forms a search for the route
and the route overview is dis-
played. ( P.92)
The destination can be
searched by entering various
keywords.
1 Display the destination
screen. ( P. 8 4 )
2 Select “Search”.
3 Enter characters on the key-
board.
4 Select “Search”.
5 When there is more than 1
result, select the desired item
from the list.
: Select to display updated infor-
mation about the selected entry.
Selecting search areaSetting home as destina-
tion
Searching by keyword

873-2. Destination search
3
Navigation system
4RUNNER_NAVI_(U)
1Display the destination
screen. ( P.84)
2 Select “Emergency”.
3 Select the desired emer-
gency category.
4 Select the desired destina-
tion.
●The navigation system does not
guide in areas where route guid-
ance is unavailable. ( P. 1 1 6 )
To use this function, it is neces-
sary to have contact data which
had been transferred to the nav-
igation system from a registered
Bluetooth
® phone. ( P.194)
1 Display the destination
screen. ( P.84)
2 Select “Contacts”. 3
Select the desired contact.
4 Select “Addresses”.
5 Select the desired address.
6 Follow the steps in “Search-
ing by keyword” from step 4.
( P.85)
●This function may not be available
depending on the type of Blue-
tooth
® phone.
1Display the destination
screen. ( P. 8 4 )
2 Select “Address”.
3 Enter a house number and
select “Search”.
4 Enter a street name and
select “Search”.
5 Select the desired street
name.
Searching by emergency
Searching by contact
Searching by address

893-2. Destination search
3
Navigation system
4RUNNER_NAVI_(U)
1Select “Sort/Category/City”.
2 Select “Change POI cate-
gory”.
3 Select the desired category.
 Select “Other POIs” to select
other than default POI catego-
ries. The following button can
be displayed.
“List All Categories”: Select to dis-
play all POI categories.
4 Select the desired POI.
1 Select “Category”.
2 Select the desired search
point.
Select to search for POIs
near your current position.
Select to search for POIs
along the set route.
Select to search for POIs
near a specific city center.
( P. 8 9 )
Select to search for POIs
near a destination.
When more than 1 destina- tion has been set, a list will
be displayed on the screen.
Select the desired destina-
tion.
3 Select the desired POI cate-
gory.
 If there is more than 1 result
for the selected category, a
detailed list will be displayed.
 Select “Other POIs” to select
other than default POI catego-
ries. The following button can
be displayed.“List All Categories”: Select to dis-
play all POI categories.
“Favorite POI Categories”: Select to
use the 6 POIs that have been pre-
viously set. ( P.109)
4 Select the desired POI.
●The names of POIs located within
approximately 200 miles (320 km)
from the selected search point can
be displayed. They are displayed
up to 200 names.
1Select “Near a City Center in
XX
*”.
2 Enter a city name and select
“Search”.
“Last 5 Cities”: Select the desired
city name from the list of the last 5
cities.
3Select the desired city name.
4 Select “OK” when the city
center map screen is dis-
played.
Selecting from the catego-
ries
Searching by category
A
B
C
D
:KHQ³1HDUD&LW\&HQWHULQ\
;;

´LVVHOHFWHG
