811-3. Theft deterrent system
GX460_OM_OM60T19U_(U)
1
For safety and security
■Alarm memory function
After the alarm is activated, when you unlock any door using a entry function, wireless
remote control or mechanical key, the tail lights turn on for about 2 seconds to inform
you that the system was activated.
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If mo dified or removed, the proper operation of
the system cannot be guaranteed.

821-3. Theft deterrent system
GX460_OM_OM60T19U_(U)

83
GX460_OM_OM60T19U_(U)
Instrument cluster2
2. Instrument clusterWarning and indicators lights ................................................ 84
Gauges and meters ..................... 90
Multi-information display .......... 93
Fuel consumption information ................................. 100

84
GX460_OM_OM60T19U_(U)2. Instrument cluster
Warning and indicators lights
The units used on the speedometer may di
ffer depending on the target region.
The warning and indicators lights on the instrument cluster and center panel
inform the driver of the status of the vehicle’s various systems.
For the purpose of explanation, the following illustrations display all warning
lights and indicators illuminated.

GX460_OM_OM60T19U_(U)
852. Instrument cluster
2
Instrument cluster
Warning lights inform the driver of malfunctions in any of the vehicle’s systems.
Warning lights
*1
(U.S.A.)
Brake system warning light
( P. 518)
*1
(flashes or
illuminates)
PCS warning light
(  P. 519)
*1
(Canada)
Brake system warning light
( P. 518)*1Slip indicator light
( P. 519)
*1Charging system warning
light ( P. 518)*1Kinetic dynamic suspension
system warning light
( P. 519)
*2High coolant temperature
warning light ( P. 518)
(flashes)
Low speed four-wheel
drive indicator light
( P. 520)
*2Low engine oil pressure
warning light ( P. 518)
(flashes)
Center differential lock
indicator light ( P. 520)
*1
(U.S.A.)
Malfunction indicator lamp
( P. 518) Open door warning light
(
 P. 520)
*1
(Canada)
Malfunction indicator lamp
( P. 518) Low fuel level warning light
(
 P. 520)
*1SRS warning light
( P. 518) Seat belt reminder light
(
 P. 520)
*1
(U.S.A.)
ABS warning light
( P. 519)*1Tire pressure warning light
( P. 520)
*1
(Canada)
ABS warning light
( P. 519)*2
LDA indicator ( P. 521)

86
GX460_OM_OM60T19U_(U)2. Instrument cluster
*1: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being perfor med. They will turn off after the engine is
on, or after a few seconds. There may be a ma lfunction in a system if the lights do not
turn on, or turn off. Have the vehicle inspected by your Lexus dealer.
*2: This light is displayed on the multi-information display.
(flashes)
(U.S.A.)
Parking brake indicator
(  P. 519)*2Brake Override System
warning light /Drive-Start
Control warning light
( P. 521)
(flashes)
(Canada)
Parking brake indicator
(  P. 519)

GX460_OM_OM60T19U_(U)
872. Instrument cluster
2
Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s various sys-
tems.
Indicators
Turn signal indicator
(  P. 211)*1Dynamic radar cruise
control indicator ( P. 258)
(U.S.A.)
Headlight indicator
( P. 213)*1
LDA indicator ( P. 252)
(Canada)
Tail light indicator
( P. 213) *1
(flashes)
LDA indicator ( P. 252)
Headlight high beam
indicator ( P. 214)
*2, 3
Slip indicator ( P. 356)
Automatic High Beam
indicator ( P. 216)
*2VSC OFF indicator
( P. 357)
(if equipped)
Fog light indicator
( P. 221)*1
(if equipped)
Multi-terrain Select
indicator ( P. 288)
*2
Eco Driving Indicator
Light ( P. 98)
*1
(if equipped)
Crawl Control indicator
( P. 348)
*1Cruise control indicator
( P. 258)*2
(if equipped)
Downhill assist control
system indicator
( P. 352)
*1Cruise control “SET”
indicator ( P. 258) “2nd STRT” indicator
(
 P. 207)

88
GX460_OM_OM60T19U_(U)2. Instrument cluster
Low speed four-wheel
drive indicator light
( P. 344)
*2TRAC OFF indicator
( P. 357)
Center differential lock
indicator ( P. 345)
*1
(if equipped)
MUD & SAND mode
indicator ( P. 289)
(if equipped)
Intuitive parking assist
indicator ( P. 270)*1
(if equipped)
MOGUL mode indicator
( P. 289)
*2, 4PCS warning light
( P. 242)*1
(if equipped)
ROCK mode indicator
( P. 289)
*1Smart access system with
push-button start indicator
( P. 200)*1
(if equipped)
LOOSE & ROCK mode
indicator ( P. 289)
(if equipped)
BSM indicator (P. 361)
*1
(if equipped)
ROCK & DIRT mode
indicator ( P. 289)
*5, 6
(if equipped)
BSM (Blind Spot Monitor)
outside rear view mirror
indicators ( P. 361)*1
(if equipped)
MTS AUTO indicator
( P. 289)
*1, 7Low outside temperature
indicator ( P. 90)
*2, 8
(U.S.A.)
“AIR BAG ON/
OFF” indicator
( P. 47)
*2, 8
(Canada)
“AIR BAG ON/
OFF” indicator
( P. 47)
