2021 INFINITI QX50 Owner's Manual

12. Glove box (P. 2-50)
13. Audio system controls*Front passenger air bag status light
(P. 1-41)
14. INFINITI controller*
15. Power outlet (P. 2-48) USB port*
Cup holders (P. 2-50)
Storage (P. 2-50)
16. Shift lever (P. 5-18)
17. Push-button ignition switch (P. 5-13) Electronic parking brake switch (P. 5-23)
Automatic brake hold switch (P. 5-25)
18. Hazard warning flasher switch (P. 6-2)
19. ProPILOT Assist Switch (if so equipped)
(P. 5-77)
Cruise control switches (if so equipped)
(P. 5-75)
Distance control switch (if so equipped)
(P. 5-106)
Control panel and vehicle information
display switches (P. 2-19)
20. Driver supplemental knee air bag
(P. 1-41)
21. Tilt and telescopic steering wheel control
(P. 3-31) 22. Hood release (P. 3-21)
23. Instrument brightness control (P. 2-36)
Front and rear sonar system switch
(if so equipped) (P. 5-160)
Steering assist switch (for vehicles with
ProPILOT Assist) (if so equipped)
(P. 2-45)
Instrument panel liftgate switch (P. 3-21)
Headlight switch (P. 2-36)
Fog light switch (if so equipped) (P. 2-42)
Head Up Display (HUD) OFF switch
(if so equipped) (P. 2-46)
*: Refer to the separate INFINITI InTouchTM
Owner's Manual.
Refer to the page number indicated in paren-
theses for operating details.
Illustrated table of contents0-7

2.0L 4 cylinder (KR20DDET engine model)
1. Engine coolant reservoir (P. 8-15)
2. Drive belt location (P. 8-15)
3. Air filter (P. 8-15)4. Brake fluid reservoir (P. 8-10)
5. Battery (P. 8-12)
6. Fuse/Fusible link box (P. 8-15)7. Windshield-washer fluid reservoir
(P. 8-11)
8. Engine oil filler cap (P. 8-6)
9. Engine oil dipstick (P. 8-6)
Refer to the page number indicated in paren-
theses for operating details.
LDI3173
ENGINE COMPARTMENT CHECK
LOCATIONS
0-8Illustrated table of contents

Warning/Indicator
light (red) Name Page
or
Brake warning
light
2-10
Charge warning
light 2-11
Electric shift
control system
warning light2-11
or
Electronic parking
brake indicator
light2-11
Warning/
Indicator
light (red) Name Page
Engine oil pressure
warning light
2-11
Master warning
light2-12
Seat belt warning
light and chime2-12
Security indicator
light2-12
Supplemental air
bag warning light2-12
Warning/
Indicator light
(yellow) Name Page
or
Anti-lock Braking
System (ABS)
warning light
2-13
or
Electronic parking
brake warning
light2-13
Forward
Emergency
Braking (FEB) with
Pedestrian
Detection system
warning light2-13
WARNING/INDICATOR LIGHTS
Illustrated table of contents0-9

Warning/Indicator light
(yellow) Name Page
Front passenger
air bag status light
2-13
Low tire pressure
warning light2-13
Malfunction
Indicator Light
(MIL) 2-15
Master warning
light
2-12
Power steering
warning light2-16
Rear Automatic
Braking (RAB)
warning light2-16
Warning/
Indicator light
(yellow) Name Page
Slip indicator light 2-16
Vehicle Dynamic
Control (VDC)
OFF indicator light
2-17
Warning/
Indicator light
(other) Name Page
Automatic brake
hold indicator light
(white/green)
2-17
Eco drive indicator
light (green) (if so
equipped)2-17
Warning/
Indicator light
(other) Name Page
Front fog light
indicator light
(green) (if so
equipped) 2-17
High Beam Assist
indicator light
(green)
2-17
High beam
indicator light
(blue)2-18
Side light and
headlight indicator
light (green)2-18
Turn signal/hazard
indicator lights
(green)2-18
0-10Illustrated table of contents

1 Safety-Seats, seat belts and supplemental
restraint system
Seats............................................1-2
Front power seat adjustment ..................1-3
Rear bench seat adjustment ...................1-4
Armrests .....................................1-5
Flexible seating ...............................1-5
Head restraints/headrests .......................1-7
Adjustable head restraint/headrest
components ..................................1-8
Non-adjustable head restraint/headrest
components ..................................1-8
Remove ......................................1-9
Install ........................................1-9
Adjust ...................................... 1-10
Seat belts ....................................... 1-11
Precautions on seat belt usage ...............1-11
Seat belt warning light and chime .............1-14
Injured persons .............................. 1-14
Pregnant women ............................ 1-14
Three-point type seat belt with retractor ......1-15
Seat belt extenders .......................... 1-19
Seat belt maintenance .......................1-19Child safety
.................................... 1-20
Infants ..................................... 1-20
Small Children .............................. 1-20
Larger children ............................... 1-21
Child restraints .................................. 1-22
Precautions on child restraints ................1-22
LATCH (Lower Anchors and Tethers for
CHildren) system ............................ 1-24
Rear-facing child restraint installation
using LATCH ................................ 1-27
Rear-facing child restraint installation
using the seat belts ......................... 1-29
Forward-facing child restraint installation
using LATCH ............................... 1-32
Forward-facing child restraint installation
using the seat belts ......................... 1-34
Booster seats ............................... 1-38
Supplemental Restraint System (SRS) ............1-41
Precautions on SRS .......................... 1-41
Supplemental air bag warning labels .........1-60
Supplemental air bag warning light ...........1-61

WARNING
• Do not ride in a moving vehicle when the
seatback is reclined. This can be danger-
ous. The shoulder belt will not be against
your body. In an accident, you could be
thrown into it and receive neck or other
serious injuries. You could also slide un-
der the lap belt and receive serious inter-
nal injuries. •
For the most effective protection when
the vehicle is in motion, the seat should
be upright. Always sit well back and up-
right in the seat with both feet on the
floor and adjust the seat properly. For
additional information, see “Precautions
on seat belt usage” (P. 1-11).
• After adjustment, gently rock in the seat
to make sure it is securely locked.
• Do not leave children unattended inside
the vehicle. They could unknowingly ac-
tivate switches or controls or make the
vehicle move. Unattended children could
become involved in serious accidents. •
To help avoid risk of injury or death
through unintended operation of the ve-
hicle and/or its systems, do not leave
children, people who require the assis-
tance of others or pets unattended in
your vehicle. Additionally, the tempera-
ture inside a closed vehicle on a warm day
can quickly become high enough to cause
a significant risk of injury or death to
people and pets.
• Do not adjust the driver’s seat while
driving so full attention may be given to
vehicle operation. The seat may move
suddenly and could cause loss of control
of the vehicle.
• The seatback should not be reclined any
more than needed for comfort. Seat
belts are most effective when the pas-
senger sits well back and straight up in
the seat. If the seatback is reclined, the
risk of sliding under the lap belt and be-
ing injured is increased.
CAUTION
When adjusting the seat positions, be sure
not to contact any moving parts to avoid
possible injuries and/or damage.
ARS1152
SEATS
1-2Safety-Seats, seat belts and supplemental restraint system

FRONT POWER SEAT
ADJUSTMENT
Operating tips
• The power seat motor has an auto-resetoverload protection circuit. If the motor
stops during operation, wait 30 seconds
then reactivate the switch.
• Do not operate the power seat switch for a long period of time when the engine is off.
This will discharge the battery.
For additional information, see “Memory
seat” (P. 3-36).
Forward and backward
Moving the switch as shown will slide the
seat forward or backward to the desired
position.
Reclining
Move the recline switch as shown until the
desired angle is obtained. The reclining feature allows adjustment of
the seatback for occupants of different sizes
for added comfort and to help obtain proper
seat belt fit. For additional information, see
“Precautions on seat belt usage” (P. 1-11).
Also, the seatback can be reclined to allow
occupants to rest when the vehicle is stopped
and the shift lever is in P (Park).
LRS2985
Safety-Seats, seat belts and supplemental restraint system1-3

Seat lifter
Move the switch as shown to adjust the
angle and height of the seat cushion.Lumbar support (for driver's seat
and if so equipped for passenger’s
seat)
The lumbar support feature provides adjust-
able lower back support to the driver and
passenger (if so equipped). Move the switch
as shown to adjust the seat lumbar area.
REAR BENCH SEAT
ADJUSTMENT
Forward and backward
Pull the center of the barO1up and hold it
while you slide the seat forward or backward
to the desired position. Release the bar to
lock the seat in position.
Reclining
To recline the seatback, pull up on the lever
O2and lean back. To bring the seatback for-
ward, pull the lever
O2up and lean your body
LRS3181LRS3046
Driver’s seat
LRS2988
1-4Safety-Seats, seat belts and supplemental restraint system
