2021 ALFA ROMEO GIULIA Owners Manual

255

For the enthusiasts, the technician, or those
who just want to know every detail of their
vehicle, useful information on understanding
how your vehicle works is contained in this
chapter and illustrated with data, tables, and
graphics.VEHICLE IDENTIFICATION
NUMBER (VIN)
The VIN is stamped on a plate on the front left
corner of the dashboard cover, which can be
seen from outside the vehicle, through the
windshield.Windshield VIN Location
Vehicle Identification Number (VIN) Plate
The plates are located on the left side A-pillar
and contain the data about:
Vehicle Identification Number (VIN).
Vehicle type (USA and Canada only).
Color code.
Place of manufacturing of the vehicle (USA
and Mexico only).
Vehicle manufacturing date.
Maximum permitted weights.
Permitted tire inflation pressure (USA and
Canada only).
21_GA_OM_EN_USC_t.book Page 255

TECHNICAL SPECIFICATIONS

256

ENGINE
2.0L Engine
CycleFour
Number and position of cylinders 4 inline
Piston bore and stroke (mm) 84 / 90
Total displacement (cm³) 1,995
Compression ratio 10:1
Maximum power (SAE) (HP) 280
Maximum power (kW) 209
Corresponding engine speed (RPM) 5,200
Maximum torque (SAE) (ft-lb) 295
Maximum torque (Nm) 400
Corresponding engine speed (RPM) 2,250 – 4,000
Fuel 87 Octane (R+M)/2 Method Minimum,
91 Recommended, ethanol percentage is 0–15%
21_GA_OM_EN_USC_t.book Page 256

257

POWER SUPPLY
2.9L Engine
CycleFour
Number and position of cylinders 6 / V
Piston bore and stroke (mm) 86.5 × 82
Total displacement (cm³) 2,891
Compression ratio 9.3:1
Maximum power (SAE) (kW) 375
Maximum power (SAE) (HP) 505
Corresponding engine speed (RPM) 6,500
Maximum torque (SAE) (Nm) 600
Maximum torque (SAE) (ft. lb) 443
Corresponding engine speed (RPM) 2,500
Fuel 87 Octane (R+M)/2 Method Minimum,
91 Recommended, ethanol percentage is 0–15%
Power Supply
2.0L Engine Electronic timed sequential injection with knock control
Power supply
2.9L EnginePhased sequential electronic injection with knock control and
variable intake valve actuation
21_GA_OM_EN_USC_t.book Page 257

TECHNICAL SPECIFICATIONS

258

TRANSMISSION
BRAKES
ModelTransmissionTraction
2.0L EngineEight forward gears plus
reverse Rear-wheel drive
or
All-wheel drive
ModelTransmissionTraction
2.9L Engine Eight forward gears plus
reverse Rear
ModelFront brakesRear brakesParking brake
2.0L Engine
DiscDiscElectric
ModelFront brakesRear brakesParking brake
2.9L Engine Disc
or
Carbon Ceramic disc Disc
or
Carbon Ceramic disc Electric
CAUTION!
Water, ice and salt spread on the roads may deposit on the brake discs, reducing braking efficiency the first time the brakes are applied.
To obtain the maximum efficiency of the braking system, a bedding-in period of about 300 miles (500 km) is needed: during this period it is
better to avoid sharp, repeated and prolonged braking.
21_GA_OM_EN_USC_t.book Page 258

259

SUSPENSION
STEERING SYSTEM
ModelFrontRear
2.0L Engine and 2.9L EngineIndependent wheel
double-wishbone suspension Independent wheel with
multi-link system
ModelCurb-to-curb turning circleType
2.0L Engine 35.50 ft (10.80 m)Rack and pinion with electric
power steering
ModelCurb-to-curb turning circleType
2.9L Engine 37.10 ft (11.30 m)Rack and pinion with electric
power steering
21_GA_OM_EN_USC_t.book Page 259

TECHNICAL SPECIFICATIONS

260

DIMENSIONS — 2.0L ENGINE
Dimensions are expressed in inches and refer to the vehicle equipped with its standard-supplied tires. Height is measured with vehicle unladen.
Small variations with respect to the reported values are possible depending on the dimensions of the rims.
A
Front
OverhangB
WheelbaseC
Rear
OverhangD
Overall LengthE
Overall HeightF
Front TrackG
Rear Track
H
Overall
Width (Incl. Mirrors)I
Overall Width (Excl.
Mirrors)
31.30
Inches 111.02
Inches 40.47
Inches 182.80
Inches 56.54 Inches1
57.09 Inches2 61.30 Inches
1 61.38 Inches
2 63.98 Inches
1 63.15 Inches
2 1.
RWD models
2. AWD models79.69
Inches 73.23
Inches
21_GA_OM_EN_USC_t.book Page 260

261

DIMENSIONS — 2.9L Engine
Dimensions are expressed in inches and refer to the vehicle equipped with its standard-supplied tires. Height is measured with vehicle unladen.
A
Front
OverhangB
WheelbaseC
Rear
OverhangD
Overall LengthE
Overall HeightF
Front TrackG
Rear Track
H
Overall
Width (Incl. Mirrors)I
Overall
Width (Excl. Mirrors)
31.30
Inches 111.02
Inches 40.31
Inches 182.64
Inches 56.14
Inches 61.22
Inches 63.27
Inches 79.69
Inches 73.74
Inches
21_GA_OM_EN_USC_t.book Page 261

TECHNICAL SPECIFICATIONS

262

WEIGHTS — 2.0L ENGINE
WEIGHTS — 2.9L ENGINE
Weights (lbs)AWDRWD
Unloaded weight (with all fluids, fuel tank filled to 90% and without
optional equipment) 3,622
3,522
Payload including the driver
1
1. If special equipment is fitted (trailer towing equipment, etc.) the empty weight will increase and consequently the payload will decrease in relation to the maximum permitted loads.
905 905
Maximum permitted loads
2
2. Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or on the load platform within the maximum permitted loads.
155 155
Front axle 2,2052,205
Rear axle 2,6462,646
Total 4,7234,612
Weights (lbs)2.9L Engine
Unloaded weight (with all fluids, fuel tank filled to 90% and without
optional equipment) 3,820
Payload including the driver
1
1. If special equipment is fitted (trailer towing equipment, etc.) the empty weight will increase and consequently the payload will decrease in relation to the maximum permitted loads.
905
Maximum permitted loads
2
2. Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or on the load platform within the maximum permitted loads.
155
Front axle 2,260
Rear axle 2,646
Total 4,774
21_GA_OM_EN_USC_t.book Page 262
