2020 YAMAHA YXZ1000R SS Owners Manual

7-5
7
5. When vehicle speed has sufficiently in-creased, use the shift paddle “ ” to shift
into second gear (“2”).
6. Follow the same procedure when shifting to the next higher gear.
To decelerate
When slowing down, release the accelerator
pedal and apply the brake pedal smoothly. As
you slow down, shift to a lower gear. Be sure
that the engine has sufficiently slowed before
engaging a lower gear. Improper use of the
brake pedal or shift paddles can cause the
tires to lose traction, reducing control and in-
creasing the possibility of an accident.
WARNING
EWB00712Make sure the engine has sufficiently
slowed before shifting to a lower gear. En-
gaging a lower gear when the engine
speed is too high could make the wheels
stop rotating and lose traction. This could cause loss of control, an accident and inju-
ry. It could also cause engine or drivetrain
damage.
Recommended shift points
The recommended shift points during accel-
eration and deceleration are shown in the fol-
lowing table.TIPWhen coming to a stop under normal condi-
tions, AUTO DOWNSHIFT will shift the trans-
mission into first gear automatically. Shift up points:
1st → 2nd: 19 km/h (12 mi/h)
2nd → 3rd: 33 km/h (21 mi/h)
3rd → 4th: 44 km/h (27 mi/h)
4th → 5th: 53 km/h (33 mi/h)
Shift down points: 5th → 4th: 30 km/h (19 mi/h)
4th → 3rd: 17 km/h (11 mi/h)
UBAS7AE0.book Page 5 Wednesday, June 19, 2019 11:51 AM

7-6
7
To drive in reverse
WARNING
EWB03300Before you shift into reverse, make sure
there are no obstacles or people behind
you. When it is safe to proceed, go slowly.
Hitting an obstacle or person could result
in serious injury or death. 1. Stop the vehicle and continue to apply the brake pedal.
2. Check behind you.
3. Shift the transmission into reverse.
TIP To shift into reverse, the engine must be
running and at idle speed.
 When in reverse, the transmission gear dis-
play should show “R” and the reverse indi-
cator light should come on.
 The reverse buzzer will sound while the
transmission is in reverse. 4. Release the parking brake (if applied).1. Drive select lever
2. Reverse gear
1
2
UBAS7AE0.book Page 6 Wednesday, June 19, 2019 11:51 AM

7-7
7
5. Check behind you, then release the brake
pedal and press the accelerator pedal
gradually.
6. Continue to watch to the rear while driv-
ing in reverse.EBU37790Dynamic clutch engagementWhen driving up a steep hill or over rocky ter-
rain at very slow speed in 1st gear, or when
stuck in a rut and extra “oomph” is needed to
climb up and over the obstacle, use this fea-
ture as follows.
1. With the transmission in 1st gear, fully de- press the accelerator pedal.
2. After a few moments, YCC-S will fully en-
gage the clutch thereby transmitting full
power to the drive wheels.
3. Release the accelerator pedal as needed
and resume normal driving.TIPCorrect accelerator pedal free play is nec-
essary for proper operation. 
Dynamic clutch engagement works in 1st
gear only.
 Time to engagement will vary depending on
conditions.
NOTICEECB03740Do not use repeatedly in a short period of
time. Otherwise, the clutch system may be
damaged. EBU36733Launch system operationThe launch system allows you to start off at a
higher engine speed, and thus have a higher
initial acceleration rate than normal operation.
Only use the launch system on level ground
with a clear and safe path ahead of you.TIPThe launch system will be prevented from op-
erating if any of the following conditions are
present:
UBAS7AE0.book Page 7 Wednesday, June 19, 2019 11:51 AM

7-8
7
the engine is not warmed up or is overheat-
ing.
 the driver seat belt is not latched.
 the differential gear is locked (“DIFF LOCK”
is selected) or the differential gear lock indi-
cator is flashing.
 the parking brake is applied.
 an engine or system malfunction is detect-
ed (a warning light is on). To activate the launch system1. Confirm that the front wheels and steer-
ing wheel are pointed straight ahead.
2. Shift the transmission into first gear.
3. While pressing the brake pedal, pull both
shift paddles toward you and hold them
in that position. The launch system indi-
cator light will come on, and the launch
system enters standby mode. 4. While checking in front of you for obsta-
cles or anything that may cross your
path, release the brake pedal, and then
press the accelerator pedal to rev the en-
gine to the desired launch engine speed.
TIPThe engine speed at launch must be be-
tween 5000–10000 r/min.
 If you release one shift paddle, or if a sys-
tem restriction is detected during standby
mode, the launch system indicator light will
begin to flash and the launch will be can-
celled.
UBAS7AE0.book Page 8 Wednesday, June 19, 2019 11:51 AM

7-9
7
If the indicator light is flashing, release the
accelerator pedal and let the engine return
to idle speed. When the indicator light goes
off, you may start off normally or retry acti-
vating the launch system. 5. When ready, release both shift paddles at the same time and further press the ac-
celerator pedal to launch the vehicle.TIPWhen the clutch has completely engaged, the
launch system and the launch system indica-
tor light will turn off. NOTICEECB03430Do not make consecutive launches with-
out allowing the clutch to cool down. Oth-
erwise, the clutch system may be
damaged. UBAS7AE0.book Page 9 Wednesday, June 19, 2019 11:51 AM

7-10
7
EBU35061Selecting the drive modeThe vehicle handles differently in each of the drive modes: “2WD”, “4WD” and “DIFF LOCK”. For
example, the vehicle requires more effort to turn in “DIFF LOCK” than in “2WD”. Always stop the
vehicle before changing the position of th e On-Command drive knob. The drive mode icon
changes according to the selected drive mode. The drive mode icon and the “DIFF LOCK” indi-
cator light come on as follows:
Knob position Indication Drive mode
(none)
“2WD” (two-wheel drive): Drive power is supplied to the rear
wheels only.
“4WD” (four-wheel drive): Drive power is supplied to the
front and rear wheels.
“DIFF LOCK” (four-wheel drive with the differential gear
locked): Drive power is supplied to the front and rear wheels
and the differential gear is locked.
Unlike in four-wheel drive, all wheels turn at the same
speed.
UBAS7AE0.book Page 10 Wednesday, June 19, 2019 11:51 AM

7-11
7
TIPWhen the knob is set to “DIFF LOCK” or “4WD ”, the drive mode icon and the indicator light
will flash until the differential gear is completely locked or unlocked.
 Turning the steering wheel back and forth will help the differential gear lock to engage or dis-
engage.
 To protect the drivetrain from damage, vehicle speed is limited until the differential gear lock
has properly transitioned. UBAS7AE0.book Page 11 Wednesday, June 19, 2019 11:51 AM

7-12
7
EBU35441ParkingWhen parking, shift into first or reverse gear,
stop the engine, and then apply the parking
brake. See page 8-16 for when parking on a
slope.EBU35354LoadingTake extra precautions when driving with a
load. Turn gradually and drive more slowly
than you would without a load. The more
weight you carry, the slower you should go.
Although conditions vary, it is good practice
to keep the vehicle in a low gear when you are
carrying a heavy load. Follow these instruc-
tions and always use common sense and
good judgment when carrying a load.Cargo bed
Use the hooks equipped on the cargo bed
(page 5-31) to tie down loads. Make sure the
load is securely fast
ened down, centered in
the cargo bed, and not top-heavy. Never al-
low anyone to ride in the cargo bed.
WARNING
EWB03923Improper loading or any pulling or towing
will increase the risk of loss of control, an
overturn, or other accident:
 Do not pull objects, other vehicles, or
tow a trailer—this vehicle is not de-
signed for such operation.
 Keep weight in the cargo bed centered
side to side, and as low and as far for-
ward as possible. Top-heavy loads in-
crease the risk of overturn.
 Make sure that cargo is securely fas-
tened down—a loose load could change
handling unexpectedly or strike occu-
pants.
