2020 MITSUBISHI MIRAGE G4 Owner's Manual (in English)

Vehicle labeling 11-2 Specifications
11
N01147401895
Keep a record of the chassis number and vehicle identification
number. Such informa-
tion will assist police if
your vehicle is stolen.
The vehicle emission
control information
label is affixed on the underside of the enginehood. The vehicle identificati
on number is stamped
on the plate riveted to the left front corner ofthe vehicle body. It is
visible from outside of
the vehicle through the windshield. The air conditioning label is affixed on the inside panel of the engine hood. The vehicle information code plate is located on the front passenger door sill.
The chassis number is stamped on the bulk- head as shown in the illustration.
Vehicle labeling
1 - Vehicle emission control information label 2 - Vehicle identification num- ber plate 3 - Air conditioning label 4 - Vehicle information code plate
Chassis number
BK0284300US.book 2 ページ ２０１９年５月２３日　木曜日　午後１２時２２分

Vehicle dimensions
Specifications 11-3
11
The engine model a
nd serial number are
stamped on the cylinder block as shown in the illustration.
N01148101668
The tire and loading information placard is located on the driver’s door sill.

N01148200242
The certification label is located on the driver’s door sill.
N01147501652
Engine model/serial number *- Front of the vehicleTire and loading information placard
Certification label Vehicle dimensions Overall length 169.5 in (4,305 mm)Overall width 65.7 in (1,670 mm)Overall height 59.3 in (1,505 mm)Wheel base 100.4 in (2,550 mm)
BK0284300US.book 3 ページ ２０１９年５月２３日　木曜日　午後１２時２２分

Vehicle weights 11-4 Specifications
11
N01147602096
GVWR: maximum total weight (load)
limit specified for the vehicle
GAWR: maximum weight (load) limit sp
ecified for the front or rear axle
Seating capacity: the maximum number of occupantsVe h i c l e w e i g h t s
Item
Manual transaxle
Continuously variable transmis-
sion (CVT)
Gross vehicle weight rating (GVWR) 3,053 lb (1,385 kg) 3,108 lb (1,410 kg)Gross axle weight rat-ing (GAWR)
Front 1,609 lb (730 kg)Rear 1,521 lb (690 kg)
Vehicle capacity weight 827 lb (375 kg)Seating capacity 5 personsMaximum roof load 110 lb (50 kg)
NOTE
Roof load is important because it affects the vehicle
capacity weight. Refer to “L
oading cargo on the roof” on
page 6-11.
BK0284300US.book 4 ページ ２０１９年５月２３日　木曜日　午後１２時２２分

Engine specifications Specifications 11-5
11
N01147701612
N01147800296
Battery is a 12 volt type.
N01147901975
PCD: Pitch Circle Diameter (installation holes)
Engine specifications Engine model
3A92
Engine displacement
72.8 CID (1,193 cm
3)
No. of cylinders and cyli
nder arrangement Inline-3
Bore
2.95 in (75.0 mm)
Stroke
3.54 in (90.0 mm)
Compression ratio
10.5:1
Thermostat valve opening temperature 189 °F (87 °C)Spark plugs
NGK LZFR5DI-11
Spark plug gap .040 to .043 in (1.0 to 1.1 mm)Firing order
1-3-2
Battery
55D23L (356CCA/99RC)
Tires and wheels Tire
165/65 R14 79S
175/55 R15 77V
Wheel
Size 14 x 5 J
15 x 5 1/2J
PCD 3.93 in (100 mm)Offset (Inset)
1.5 in (38 mm)
NOTE
Contact an authorized Mitsubi- shi Motors dealer for details onthe combination used on your vehicle.These tires satisfy vehicle load-ing conditions d
escribed in this
owner’s manual.
BK0284300US.book 5 ページ ２０１９年５月２３日　木曜日　午後１２時２２分

Capacity 11-6 Specifications
11
N01148002404
* : similar high quality ethylene
glycol based non-silicate, non-
amine, non-nitrate and non-borate
coolant with long life hybrid
organic acid tech-
nologyCapacity
Item
Capacity
Lubricants
Fuel (approximate)
9.2 gal (35 L) Refer to “Fue
l selection” on page 3-2
Engine oil
Oil pan 2.9 qt (2.8 L) Engine oils displa
ying the ILSAC certification mark (“star-
burst” symbol) on the container. If these oils are not available,
an API classification SN or
higher can be used.
Oil filter .21 qt (0.2 L)
Manual transaxle 1.7 qt (1.6 L)
Mitsubishi Motors Genuine
NEW MULTI GEAR OIL ECO
API GL-4 SAE 75W-80
Continuously variable transmission (CVT) 7.4 qt (7.0 L)
Refer to “Continuously variable
transmission (CVT) fluid” on
page 9-9.
Brake As required Conforming to Brake fluid DOT3 or DOT4Hood lock release mechanism and safety catch A
s required Multipurpose type
grease NLGI Grade 2
Engine coolant {Includes .53 qt (0.5 L) in reserve tank}
Manual trans- axle
4.2 qt (4.0 L)
Mitsubishi Motors Genuine Supe
r Long Life Coolant Premium
or equivalent
*
CVT 4.8 qt (4.6 L)
Washer fluid 2.6 qt (2.5 L) —Refrigerant (air conditioning)
Refer to the “Air con- ditioning label” on
page 11-2.
HFO-1234yf
BK0284300US.book 6 ページ ２０１９年５月２３日　木曜日　午後１２時２２分

Alphabetical index
12-1
12
A
Accessory (installation)
.........................
3-5
Active stability control (ASC)
..............
5-52
Air cleaner filter
...................................
9-8
Air conditioning
Automatic air conditioning
................
7-4
Important air condi
tioning operating tips
..
7-10
Air purifier
.........................................
7-11
Airbag
...............................................
4-22
Aluminum wheels
...............................
9-37
Antenna
.............................................
7-11
Anti-lock braking system
.....................
5-49
Arm rest
........................................
4-4
, 4-5
Assist grips
........................................
5-89
Automatic air conditioning
....................
7-4
B
Back-up light
Bulb capacity
.................................
9-29
Replacement
..................................
9-32
Ball joint, steering li
nkage seals and drive
shaft boots
........................................
9-23
Battery
...............................................
9-11
Charging system warning light
.........
5-77
Checking battery el
ectrolyte level
.....
9-11
Disconnection and connection
..........
9-11
During cold weather
.......................
9-11
Specification
..................................
11-5
Bottle holders
.....................................
5-88
Brake
Fluid
.............................................
11-6
Brake assist system
.............................
5-49
Braking
...............................................
6-5
Anti-lock braking system
................
5-49
Hose
.............................................
9-23
Pad wear alarm
..............................
5-47
Parking brake
.................................
5-33
Pedal
.............................................
5-46
Pedal free play
...............................
9-20
Power brakes
.................................
5-47
Service brake
.................................
5-46
Warning lights
...............................
5-75
Break-in recommendations
....................
5-2
Bulb capacity
.....................................
9-29
Bulb location
.....................................
9-29
C
California Perchl
orate Materials
Requirements
.....................................
3-7
Capacity
............................................
11-6
Cargo loads
........................................
6-11
Catalytic converter
...............................
9-3
Certification label
...............................
11-3
Charging system warning light
............
5-77
Child restraint systems
........................
4-14
Child safety locks for rear door
............
5-28
Cleaning
Inside of your vehicle
......................
9-34
Outside of your vehicle
...................
9-35
Clutch
Pedal free play
................................
9-20
Consumer information
.........................
10-2
Continuously variable transmission (CVT)
...
5-41 Fluid
.......................................
9-9
, 11-6
Selector lever operation
...................
5-42
Selector lever positions
....................
5-44
Convenience hook
...............................
5-88
Coolant (engine)
..........................
9-7
, 11-6
Cruise control
.....................................
5-54
Cup holders
........................................
5-87
D
Defogger (rear window)
......................
5-82
Defrosting or defogging
(windshield, door
windows)
...........................................
7-9
Dimensions
........................................
11-3
Dimmer (high/low beam change)
..........
5-79
Disc brake pads
..................................
9-23
Dome light
.........................................
5-86
Bulb capacity
.................................
9-30
BK0284300US.book 1 ページ ２０１９年５月２３日　木曜日　午後１２時２２分

Alphabetical index 12-2
12
Door-ajar warning buzzer
....................
5-77
Door-ajar warning light
.......................
5-77
Doors
Lock
..............................................
5-25
Power door locks
............................
5-27
Driving during cold weather
..................
6-4
Driving, alcohol and drugs
.....................
6-2
E
Electric power steering system (EPS)
...
5-51
Electric rear win
dow defogger switch
...
5-82
Electronic immobilizer (Anti-theft starting system)
.....................................
5-3
, 5-20
Emission-control sy
stem maintenance
..9-21
Engine
Compartment
...................................
9-5
Coolant
...................................
9-7
, 11-6
High coolant temperature warning light
....
5-77 Hood
...............................................
9-4
Model
............................................
11-3
Oil and oil filter
.......................
9-5
, 11-6
Overheating
.....................................
8-4
Serial number
.................................
11-3
Specification
..................................
11-5
Engine hood
.........................................
9-4
Engine switch
.....................................
5-13
Event Data Recording
...........................
3-7
Exhaust system
...................................
9-23
F
Floor mat
.............................................
6-2
Fluid
Brake fluid
.....................................
11-6
Continuously variable
transmission (CVT)
fluid
......................................
9-9
, 11-6
Engine coolant
.........................
9-7
, 11-6
Manual transaxle
.............................
11-6
Washer fluid
............................
9-9
, 11-6
Fluid capacities and lubricants
..............
11-6
Free-hand advanced security transmitter (F.A.S.T.-key)
...................................
5-9
Front fog lights
Bulb capacity
..................................
9-29
Indicators
.......................................
5-75
Replacement
...................................
9-31
Switch
............................................
5-80
Front seat adjustment
............................
4-2
Front side-marker lights
Bulb capacity
..................................
9-29
Replacement
...................................
9-31
Front turn signal lights
Bulb capacity
..................................
9-29
Replacement
...................................
9-31
Fuel
Filling the fuel tank
..........................
3-3
Fuel economy
..................................
6-2
Fuel hoses
......................................
9-22
Fuel remaining warning display
.......
5-69
Fuel selection
...................................
3-2
Tank capacity
.................................
11-6
Fuel Pump Shut-off System
.................
8-15
Fuel remaining display
........................
5-69
Fuses
.................................................
9-24
Fusible links
.......................................
9-24
G
General maintenance
Maintenance
...................................
9-22
General vehicle data
............................
11-3
Genuine Mitsubishi Motors parts
............
3-6
Glove compartment
.............................
5-87
H
Hazard warning flasher switch
.............
5-80
Hazard warning lights
.........................
5-75
Head restraints
......................................
4-5
Headlights
Bulb capacity
.................................
9-29
Dimmer
.........................................
5-79
Headlight flasher
............................
5-79
Switch
...........................................
5-78
High beam indicator
............................
5-75
High coolant temperature warning light 5-77
BK0284300US.book 2 ページ ２０１９年５月２３日　木曜日　午後１２時２２分

Alphabetical index
12-3
12
High-mounted stop light
Bulb capacity
.................................
9-29
Hill start assist
....................................
5-47
Hood lock release me
chanism and safety
catch
................................................
9-23
Hook
Convenience hook
..........................
5-88
Horn switch
........................................
5-83
I
If the vehicle breaks down
.....................
8-2
Ignition switch
....................................
5-37
Important facts to know in
case of an accident
10-3 Indicator and warning light package
.....
5-74
Indicators
...........................................
5-75
Information display
.............................
5-66
Inside emergency trunk lid release
........
5-29
Inside rearview mirror
.........................
5-34
Instrument panel light dimmer control
..5-67
Interior lights
......................................
5-86
J
Jack
Garage jack up position
.....................
9-3
Storage
............................................
8-5
Jump-starting the engine
........................
8-2
K
Key slot
.............................................
5-19
Keyless entry system
....................
5-6
, 5-21
Keys
...................................................
5-2
L
Labeling
............................................
11-2
License plate lights
Bulb capacity
.................................
9-29
Replacement
..................................
9-33
Link System
.......................................
5-83
Loading information
.............................
6-6
Lubricants
.........................................
11-6
M
Malfunction indicator light
..................
5-76
Manual transaxle
................................
5-40
Oil
..........................................
9-9
, 11-6
Shift points
....................................
5-40
Modifications to and
racing of your vehicle
..
3-5 Multi-information display
...........
5-64
, 5-65
O
Octane number
.....................................
3-2
Oil
Engine oil
...............................
9-5
, 11-6
Manual transaxle oil
.................
9-9
, 11-6
Oil pressure warning light
....................
5-77
Operation mode
..................................
5-13
Operation under adverse driving conditions
..
8-13 Outside rearview mirrors
.....................
5-36
Overheating
..........................................
8-4
P
Parking
................................................
6-5
Parking brake lever stroke
...............
9-21
Parking brake
............................
5-33
, 9-21
Parking lights
Bulb capacity
.................................
9-29
Replacement
...................................
9-31
Polishing
............................................
9-36
Power brakes
......................................
5-47
Power outlet
.......................................
5-85
Power windows
..................................
5-30
Puncture (Tire changing)
.......................
8-6
R
Radio
General information
about your radio 7-12
Rear combination lights
Bulb capacity
.................................
9-29
BK0284300US.book 3 ページ ２０１９年５月２３日　木曜日　午後１２時２２分
