CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-25.
Coolant FL-22 type
Manual transaxle oil Mazda Long Life Gear Oil G7
*1
Automatic transaxle fluid Mazda Genuine ATF-FZ
Transfer case oil Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil Mazda Long Life Hypoid Gear Oil SG1
Brake fluid/Clutch fluid SAE J1703 or FMVSS116 DOT-3
*1 Mazda Long Life Gear Oil G7 is superior oil for low fuel cost and optimum shift-feel. Using Mazda Long Life
Gear Oil G7 is recommended.
If Mazda Long Life Gear Oil G7 cannot be obtained, use standard oil (API Service GL-4 (SAE 75W-80)).
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
▼Capacities
(Approximate Quantities)
Item
Capacity
Engine oil SKYACTIV-G
2.0
With oil filter replacement 4.2 L (4.4 US qt, 3.7 Imp qt)
Without oil filter replace-
ment
4.0 L (4.2 US qt, 3.5 Imp qt)
SKYACTIV-G
2.5 With oil filter replacement 4.5 L (4.8 US qt, 4.0 Imp qt)
Without oil filter replace-
ment
4.3 L (4.5 US qt, 3.8 Imp qt)
SKYACTIV-G
2.5T With oil filter replacement 4.8 L (5.1 US qt, 4.2 Imp qt)
Without oil filter replace-
ment
4.6 L (4.9 US qt, 4.0 Imp qt)
SKYACTIV-D
2.2 With oil filter replacement 5.1 L (5.4 US qt, 4.5 Imp qt)
Without oil filter replace-
ment
4.8 L (5.1 US qt, 4.2 Imp qt)
Specifications
Specifications
9-5
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

ItemCapacity
Coolant U.S.A. and Can-
ada
SKYACTIV-G 2.0
7.1 L (7.5 US qt, 6.2 Imp qt)
SKYACTIV-G 2.5 7.5 L (7.9 US qt, 6.6 Imp qt)
SKYACTIV-G 2.5T 8.5 L (9.0 US qt, 7.5 Imp qt)
SKYACTIV-D 2.2 8.7 L (9.2 US qt, 7.7 Imp qt)
Mexico SKYACTIV-G 2.0
7.6 L (8.0 US qt, 6.7 Imp qt)
SKYACTIV-G 2.5 7.7 L (8.1 US qt, 6.8 Imp qt)
SKYACTIV-G 2.5T 8.5 L (9.0 US qt, 7.5 Imp qt)
Manual transaxle oil 1.65 L (1.74 US qt, 1.45 Imp qt)
Automatic transaxle
fluid SKYACTIV-G 2.0
7.8 L (8.2 US qt, 6.9 Imp qt)
SKYACTIV-G 2.5 7.8 L (8.2 US qt, 6.9 Imp qt)/
8.0 L (8.5 US qt, 7.0 Imp qt)
SKYACTIV-G 2.5T, SKYACTIV-D 2.2 8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil 0.45 L (0.48 US qt, 0.40 Imp qt)
Rear differential oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Fuel tank FWD
56.0 L (14.8 US gal, 12.3 Imp gal)
AWD 58.0 L (15.3 US gal, 12.8 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
▼Dimensions
Item
Vehicle specification
Overall length 4,550 mm (179.1 in)
Overall width 1,840 mm (72.4 in)
Overall height 1,675 mm (65.9 in)
Front tread 17 inch styled steel wheel
vehicle
1,586 mm (62.4 in)
17 inch aluminum wheel
vehicle 1,596 mm (62.8 in)
19 inch aluminum wheel
vehicle 1,596 mm (62.8 in)
Rear tread 17 inch styled steel wheel
vehicle
1,586 mm (62.4 in)
17 inch aluminum wheel
vehicle 1,596 mm (62.8 in)
19 inch aluminum wheel
vehicle 1,596 mm (62.8 in)
Wheelbase 2,698 mm (106.2 in)
Specifications
Specifications
9-6
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

▼We i g h t s
U.S.A. and Canada
SKYACTIV-G 2.0
Item
Weight
GVWR (Gross Vehicle Weight Rating) 1,960 kg (4,321 lbs)
GAWR (Gross Axle Weight
Rating) Front
980 kg (2,161 lbs)
Rear 980 kg (2,161 lbs)
SKYACTIV-G 2.5
Item We i g h t
FWD AWD
GVWR (Gross Vehicle Weight Rating) 2,060 kg (4,541 lbs)/
2,075 kg (4,575 lbs) 2,143 kg (4,724 lbs)
GAWR (Gross Axle Weight
Rating) Front
1,060 kg (2,337 lbs)/
1,075 kg (2,370 lbs) 1,100 kg (2,425 lbs)
Rear 1,000 kg (2,205 lbs) 1,043 kg (2,299 lbs)
SKYACTIV-G 2.5T
Item We i g h t
FWD AWD
GVWR (Gross Vehicle Weight Rating) 2,140 kg (4,718 lbs) 2,180 kg (4,806 lbs)
GAWR (Gross Axle Weight
Rating) Front
1,120 kg (2,469 lbs) 1,140 kg (2,513 lbs)
Rear 1,020 kg (2,249 lbs) 1,040 kg (2,293 lbs)
SKYACTIV-D 2.2
Item We i g h t
FWD AWD
GVWR (Gross Vehicle Weight Rating) 2,175 kg (4,795 lbs) 2,240 kg (4,938 lbs)
GAWR (Gross Axle Weight
Rating) Front
1,150 kg (2,535 lbs) 1,170 kg (2,579 lbs)
Rear 1,025 kg (2,260 lbs) 1,070 kg (2,359 lbs)
Mexico
SKYACTIV-G 2.0
Item Weight
GVW (Gross Vehicle Weight) Total
2,060 kg (4,542 lbs)
Front 1,035 kg (2,282 lbs)
Rear 1,025 kg (2,260 lbs)
Specifications
Specifications
9-7
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

ItemWeight
GAW (Permissible axle load) Front
1,055 kg (2,326 lbs)
Rear 1,105 kg (2,436 lbs)
SKYACTIV-G 2.5
Item Weight
Without moonroof With moonroof
GVW (Gross Vehicle Weight) Total 2,060 kg (4,542 lbs) 2,110 kg (4,652 lbs)
Front 1,035 kg (2,282 lbs) 1,045 kg (2,304 lbs)
Rear 1,025 kg (2,260 lbs) 1,065 kg (2,348 lbs)
GAW (Permissible axle load) Front 1,055 kg (2,326 lbs) 1,065 kg (2,348 lbs)
Rear 1,105 kg (2,436 lbs) 1,145 kg (2,524 lbs)
SKYACTIV-G 2.5T
Item
Weight
GVW (Gross Vehicle Weight) Total
2,115 kg (4,663 lbs)
Front 1,100 kg (2,425 lbs)
Rear 1,015 kg (2,238 lbs)
GAW (Permissible axle load) Front
1,125 kg (2,480 lbs)
Rear 1,090 kg (2,403 lbs)
▼Air Conditioner
The type of refrigerant used is indicated on a label attached to the inside of the engine com-
partment. Check the label before recharging
the refrigerant. Refer to Climate Control Sys-
tem on page 5-4.
Item Specification
Refrigerant Type HFC134a (R-134a)
▼Light Bulbs
Exterior light
Light bulb Category
Wat t a ge UN-R*1(SAE)
Headlights/Daytime running lights LED
*2― (― )
Parking lights LED type
LED
*2― (― )
Front turn signal lights/Parking lights
*28/8 ― (#7444NA)
Front side-marker lights LED type
LED
*2― (― )
Bulb type 5 W5W ( ―)
Fog lights
*LED*2― (― )
Specifications
Specifications
9-8*Some models.
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

Light bulbCategory
Wa t t ag e UN-R*1(SAE)
Side turn signal lights LED
*2― (― )
High-mount brake light LED
*2― (― )
Rear turn signal lights 21 WY21W (7443NA)
Brake lights/Taillights/Rear
side-marker lights LED type
LED
*2― (― )
Bulb type 21/5 W21/5W (7443)
Reverse lights LED
*2― (― )
License plate lights LED
*2― (― )
*1 UN-R stands for United Nations Regulation.*2 LED is the abbreviation for Light Emitting Diode.
Interior light
Light bulb Category
Wa t t ag e UN-R*1
Luggage compartment light LED type
LED*2―
Bulb type 8―
Overhead light (Front)/Map lights LED type
LED
*2―
Bulb type 8 ―
Rear map lights LED type
LED
*2―
Bulb type 8 ―
Vanity mirror lights
*LED type LED*2―
Bulb type 2 ―
Ambient lights
*LED*2―
*1 UN-R stands for United Nations Regulation.*2 LED is the abbreviation for Light Emitting Diode.
▼ Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Pressure Label on page 9-2.
Refer to Tire Inflation Pressure on page 6-48.
Specifications
Specifications
*Some models.9-9
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

Standard tire
(U.S.A. and Canada)
Tire sizeInflation pressure
Front Rear
P225/65R17 100H 230 kPa (34 psi)230 kPa (34 psi)
P225/55R19 99V 240 kPa (35 psi)240 kPa (35 psi)
(Mexico)
Tire size Inflation pressure
Up to 3 persons ―Full load
225/65R17 102V Front 230 kPa (2.3 bar, 33 psi) 260 kPa (2.6 bar, 38 psi)
Rear 230 kPa (2.3 bar, 33 psi) 280 kPa (2.8 bar, 41 psi)
225/55R19 99V Front 250 kPa (2.5 bar, 36 psi) 260 kPa (2.6 bar, 38 psi)
Rear 250 kPa (2.5 bar, 36 psi) 290 kPa (2.9 bar, 42 psi)
1 person's weight: About 75 kg
Temporary spare tire
(U.S.A. and Canada)
Tire size
Inflation pressure
T145/90D16 106M
* １420 kPa (60 psi)
T155/90D17 101M
*2420 kPa (60 psi)
*1 SKYACTIV-G 2.0, SKYACTIV-G 2.5*2 SKYACTIV-G 2.5T, SKYACTIV-D 2.2
(Mexico)
Tire size Inflation pressure
185/80R17 99M 320 kPa (3.2 bar, 46 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108―147 N·m (12―14 kgf·m, 80 ―108 ft·lbf)
▼Fuses
Refer to Fuses on page 6-58.
Specifications
Specifications
9-10
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

Personalization Features
The following personalization features can be set or changed by the customer or an Author-
ized Mazda Dealer. Consult an Auth orized Mazda Dealer for details.
Additionally, some of the personalization features can be changed by the customer depend-
ing on the feature.
Personalization features and settings which can be changed differ depending on the market
and specification.
Settings Change Method
Settings can be changed by operating the center display screen.
A: Refer to Settings on page 5-76.
B: Refer to Fuel Economy Monitor on page 4-113.
C: Refer to Active Driving Display on page 4-58.
Settings can be changed by operating the vehicle switches.
D: Refer to Auto Lock/Unlock Function on page 3-16.
E: Refer to Transmitter on page 3-5.
F: Refer to Locking, Unlockin g with Request Switch (With the advanced keyless function)
on page 3-13.
Settings can be changed by an Authorized Mazda Dealer.
Item FeatureFactory Set-
ting Available
Settings Set-
tings
Chan
ge
Meth od
Safety
Advanced Smart
City Brake Support
(Advanced SCBS)
(page 4-172)
Smart City Brake
Support (SCBS)
(page 4-175)
Smart Brake Support
(SBS) (page 4-178) The system can be cha
nged so that Smart City
Brake Support (SCBS)/Smart Brake Support (SBS)
does not operate.
*1On On/Off A ―
The distance at which the collision warning acti-
vates can be changed. Med.Far/Med./
Near A
―
The volume of the co llision warning can be
changed. High
High/Low/Of
f A
―
Specifications
Personalization Features
9-11
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

ItemFeatureFactory Set-
ting Available
Settings Set-
tings
Chan ge
Meth od
Lane-keep Assist
System (LAS) &
Lane Departure
Warning System
(LDWS) (page
4-162) The system can be changed so that the steering
wheel assist does not operate.
On On/Off A
―
When the steer-
ing wheel opera-
tion assistance is
turned onThe system can be changed so
that the Lane Departure Warning
does not activate.
On On/Off A
―
The cancel sensitivity of the steer-
ing assistance for the Lane-keep
Assist System (LAS) & Lane De-
parture Warning System (LDWS)
can be changed. High High/Low A
―
When the steer-
ing wheel opera-
tion assistance is
turned offThe warning timin
g in which the
system determines that the vehicle
may be deviating from its lane
can be changed. At At/Before A
―
The sensitivity of the warning for
the system can be changed. Often Often/Rare A
―
Lane-keep Assist
System (LAS) &
Lane Departure
Warning System
(LDWS) (page
4-162)The type of Lane-keep Assist System (LAS) & Lane
Departure Warning System (LDWS) warning can be
changed.
Vi b r a t i o n
Vibration/
Beep/Rumbl. A
―
The warning in-
tensity/volume
of the system
can be changed. Vibration Low High/Low A
―
Rumbl.LowHigh/Mid/Lo
w A
―
Beep Low High/Low A―
Blind Spot Monitor-
ing (BSM) (page
4-128)The system can be changed
so that Blind Spot Mon-
itoring (BSM) does not operate.*1On On/Off A ―
Warning beep volume*2HighHigh/
Low/ Off A
―
Distance Recogni-
tion Support System
(DRSS) (page 4-139) The system can be changed so that Distance Recog-
nition Support System (D
RSS) does not operate.*1On On/Off A ―
The distance at which the vehicle ahead and your
vehicle indicated in the display flashes in white can
be changed. Near
Far/Med./
Near A
―
Specifications
Personalization Features
9-12
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07
