2020 MAZDA MODEL CX-5 Owners Manual (in English)

Cup Holder
WA R N I N G
Never use a cup holder to hold hot liquids
while the vehicle is moving:
Using a cup holder to hold hot liquids while
the vehicle is moving is dangerous. If the
contents spill, you could be scalded.
Do not put anything other than cups or
drink cans in cup holders:
Putting objects other than cups or drink
cans in a cup holder is dangerous.
During sudden braking or maneuvering,
occupants could be hit and injured, or
objects could be thrown around the
vehicle, causing interference with the driver
and the possibility of an accident. Only use
a cup holder for cups or drink cans.
▼Front
▼
Rear*
The rear cup holder is on the rear center
armrest.
Interior Features
Interior Equipment
*Some models.5-99
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

Bottle Holder
Bottle holders are on the inside of the
doors.
Front
Bottle holder
Rear
Bottle holder
CAUTION
Do not use the bottle holders for containers
without caps. The contents may spill when
opening/closing the door or while driving
the vehicle.
Storage Compartments
WA R N I N G
Keep storage boxes closed when driving:
Driving with the storage boxes open is
dangerous. To reduce the possibility of
injury in an accident or a sudden stop, keep
the storage boxes closed when driving.
When loading cargo, make sure that it is
completely secured:
If the cargo is not completely secured, it
may move or collapse while driving or
during sudden braking, resulting in injury
or an accident.
Do not put articles in storage spaces with
no lid:
Putting articles in storage spaces with no
lid is dangerous as they could be thrown
around the cabin if the vehicle is suddenly
accelerated and cause injury depending on
how the article is stored.
CAUTION
Do not leave lighters or eyeglasses in the
storage boxes while parked under the sun.
A lighter could explode or the plastic
material in eyeglasses could deform and
crack from high temperature.
▼Overhead Console
This console box is designed to store
eyeglasses or other accessories.
Interior Features
Interior Equipment
5-100
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

Push and release to open.
Type A
Type B
▼Glove Compartment
To open the glove co
mpartment, pull the
latch toward you.
To close the glove compartment, firmly
press in the center of the glove
compartment lid.
▼ Center Console
To open, pull the release latch.
Storage tray
The storage tray can be removed.
Storage tray
▼
Armrest Box*
To open, push the button and pull up the
lid.
Interior Features
Interior Equipment
*Some models.5-101
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

▼Luggage Compartment
Cargo Securing Loops
Use the loops in the luggage compartment to secure cargo with a rope or net. The tensile
strength of the loops is 196 N (20 kgf, 44 lbf). Do not apply excessive force to the loops as
it will damage them.
Cargo Sub-Compartment
Open the cover to put small items in the cargo sub-compartment.
NOTE
Loading golf bags
(Some golf bags may not fit using the following methods depending on their sizes.)
Up to four golf bags can be carried in the luggage compartment.

Bottom: Place the first and second golf bags in the luggage compartment with the bottoms
pointed to the right.
Interior Features
Interior Equipment
5-102
CX-5_8HX6-EA-19I_Edition2_old
2019-9-19 9:26:07

Top: Place the third golf bag with its bottom pointed to the left and the fourth golf bag with
its bottom pointed to the right in the luggage compartment.
The arrows indicate the bottoms of the golf bags.To p
Bottom
▼ Rear Coat Hooks
WA R N I N G
Never hang heavy or sharp objects on the
assist grips and coat hooks:
Hanging heavy or sharp-ended objects
such as a coat hanger from the assist grips
or coat hooks is dangerous as they can
fly
off and hit an occupant in the cabin if a
curtain air bag was to deploy, which could
result in serious injury or death.
Always hang clothes on the coat hooks
and the assist grips without hangers.
Coat hook
Interior Features
Interior Equipment
5-103
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

MEMO
5-104
CX-5_8HX6-EA-19I_Edition2_old2019-9-19 9:26:07

6Maintenance and Care
How to keep your Mazda in top condition.
Essential Information........................6-2 Introduction.................................. 6-2
Scheduled Maintenance.................... 6-4 Scheduled Maintenance (U.S.A.,
Canada, and Puerto Rico)............. 6-4
Scheduled Maintenance
(Mexico)..................................... 6-11
Maintenance Monitor................. 6-16
Owner Maintenance........................ 6-19 Owner Maintenance
Precautions................................. 6-19
Hood........................................... 6-21
Engine Compartment
Overview.................................... 6-23
Engine Oil...................................6-25
Engine Coolant........................... 6-29
Brake/Clutch Fluid. .................... 6-31
Washer Fluid............................... 6-31
Diesel Exhaust Fluid (DEF)....... 6-32
Body Lubrication...... .................. 6-36
Wiper Blades.............................. 6-37
Battery........................................ 6-42
Key Battery Replacement........... 6-44
Tires............................................ 6-48
Light Bulbs................................. 6-52
Fuses........................................... 6-58
Appearance Care............................. 6-65
Exterior Care.............................. 6-65
Interior Care................................6-71
6-1
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07

Introduction
Be careful not to hurt yourself when inspecting your vehicle, replacing a tire, or doing some
kind of maintenance such as car washing. In particular, wear thick work gloves such as
cotton gloves when touching areas that are difficult to see while inspecting or working on
your vehicle. Doing inspections or procedures with your bare hands could cause injury.

If you are unsure about any procedure this manual describes, we strongly urge you to have a
reliable and qualified service shop perform the work, preferably an Authorized Mazda
Dealer.

Factory-trained Mazda technicians and genuine Mazda parts are best for your vehicle.
Without this expertise and the parts that have been designed and made especially for your
Mazda, inadequate, incomplete , and insufficient servicing may result in problems. This
could lead to vehicle damage or an accident and injuries.

For expert advice and quality service, consult an Authorized Mazda Dealer.

To continue warranty eligibility and to protect your investment, it is your responsibility to
properly maintain your vehicle according to factory recommended schedules outlined in this
manual. As part of this you must keep your maintenance records, receipts, repair orders and
any other documents as evidence this maintenance was performed. You must present these
documents, should any warranty coverage disagreement occur. Failure to do so can result in
your warranty being voided either in whole or in part.

This evidence may consist of the following:
The Mazda Scheduled Maintenance Record, refer to the Warranty Booklet, must be
completely filled out showing mileage, repair order number, date for each service, and
signed by a qualified automotive service technician who service vehicles.
Original copies of repair orde rs or other receipts that include the mileage and date the
vehicle was serviced. Each receipt should be signed by a qualified automotive service
technician.
For self maintenance, a statement that you completed the maintenance yourself,
displaying mileage and the date the work was performed. Also, receipts for the
replacement parts (fluid, filters, etc.) indicat ing the date and mileage must accompany this
statement.

Maintenance and Care
Essential Information
6-2
CX-5_8HX6-EA-19I_Edition2_old 2019-9-19 9:26:07
