2019 VOLKSWAGEN E-GOLF Owners Manual

Button/Knob More information: Climatronic ⇒ fig. 150.

Opening the Air conditioning menu
x Press the -%.5 ⇒ fig. 150 button.
The current air conditioning settings are displayed in the upper section of the screen, for example, the temperatures that are currently set for the driver and passenger sides. Set temperatures up to +72 °F (+22 °C) are shown with blue arrows, while temperatures above +72 °F (+22 °C) are shown with red arrows.
Tap the corresponding function key to switch a function on or off, or to select a submenu.

Function
key
Effect
/&& Switch off the Climatronic.
/. Switch on the Climatronic.
Setup

x Turn the temperature knob to the center position.
x Open and adjust all air vents in the instrument panel ⇒, Air vents.
x Turn the air distribution knob to the desired setting.
x Push the !

Air vents

Fig. 151 In the instrument panel: Air vents.

The air recirculation mode helps prevent outside air from entering the vehicle interior.
In very hot outside temperatures, temporarily switch to manual air recirculation in order to cool the vehicle interior faster.
For safety reasons, air recirculation is switched off in the following situations ⇒ .
x Manually: The  button is pushed (Climatronic) or the air distribution knob is turned to < (manual air conditioning).
x Automatically: A sensor detects conditions that could cause the windows to fog up.
Switching manual air recirculation on and off
Switching on: Press the 3 button. The indicator light under the button lights up.
Switching off: Press the 3 button. The indicator light under the button goes out.
Switching the automatic air recirculation mode on and off: Climatronic
x Press the -%.5 button.
x Touch the

Working in the electric motor compartment

WARNING
The electric motor compartment of any motor vehicle is a potentially dangerous area and can cause serious personal injury.
x Always use extreme caution when doing any work in the electric motor compartment. Always follow commonly accepted safety practices and use common sense. Never risk per-sonal injury.
x Never perform any work in the electric motor compartment unless you know exactly how to carry out the job and have the correct technical information and the correct tools.
x If you are uncertain about what to do, have the work performed by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified work-shop. Serious personal injury may result from improperly performed work.
x We strongly recommend that you always have HID – High Intensity Discharge (Xenon) headlights and H7 bulbs replaced by a qualified technician. Serious personal injury may re-sult from improperly performed work.
x Never open or close the electric motor hood if steam or coolant is escaping. Hot steam or coolant can cause serious burns. Always wait until you no longer see or hear steam or cool-ant escaping from the electric motor.
x Always let the electric motor cool down completely before carefully opening the hood.
x Hot parts of the electric motor and the exhaust system will burn skin on contact.
x When the electric motor has cooled down and you are ready to open the hood:
– Firmly apply the parking brake and shift the transmission into Park (P) (automatic) or Neutral (manual only).
– Take the vehicle key out of the ignition.
– On vehicles with Keyless Access, make sure that the remote control vehicle key is out of range of the vehicle and that the vehicle cannot be started by depressing the starter
button ⇒  Unlocking or locking the vehicle with Keyless Access.
– Always keep children and others away from the electric motor compartment and never leave them unsupervised.
x The electric motor coolant system is under pressure when the electric motor is hot. Never unscrew the coolant expansion tank cap when the electric motor is hot. Hot coolant can spray out and cause severe burns and other serious injuries.
– Turn the cap slowly and very carefully in a counterclockwise direction while applying light downward pressure on the top of the cap.
– Always protect your face, hands, and arms from hot escaping coolant or steam by covering the cap with a large, thick rag.
x Never spill fluids on the electric motor or exhaust system when refilling. Spilling fluids onto hot parts of the electric motor or exhaust system can cause a fire.
