2019 Ram 2500 Owner's Manual

SAFETY 263
Recommendations For Attaching Child Restraints Restraint Type Combined Weight
of the Child +
Child Restraint Use Any Attachment Method Shown With An “X” Below
LATCH – Lower Anchors Only Seat Belt OnlyLATCH – Lower
Anchors + Top Tether Anchor Seat Belt + Top
Tether Anchor
Rear-Facing Child Restraint Up to 65 lbs
(29.5 kg) X
X
Rear-Facing Child Restraint More than 65 lbs
(29.5 kg) X
Forward-Facing Child Restraint Up to 65 lbs
(29.5 kg) X
X
Forward-Facing Child Restraint More than 65 lbs
(29.5 kg) X
4

264 SAFETY
Lower Anchors And Tethers For CHildren (LATCH)
Restraint System LATCH Label Your vehicle is equipped with the child restraint anchorage
system called LATCH, which stands for Lower Anchors and
Tethers for CHildren. The LATCH system has three vehicle
anchor points for installing LATCH-equipped child seats.
There are two lower anchorages located at the back of the
seat cushion where it meets the seatback and one top tether
anchorage located behind the seating position. These anchor
-
ages are used to install LATCH-equipped child seats without
using the vehicle’s seat belts. Some seating positions may
have a top tether anchorage but no lower anchorages. In
these seating positions, the seat belt must be used with the
top tether anchorage to install the child restraint. Please see
the following table for more information.

SAFETY 265
LATCH Positions For Installing Child Restraints In This
VehicleRegular Cab LATCH Positions
Crew Cab 60/40 Split Bench LATCH Positions
Top Tether Anchorage Symbol
Top Tether Anchorage Symbol
Lower Anchorage Symbol (2 Anchorages Per Seating Position)
4

266 SAFETY
Mega Cab LATCH PositionsCrew Cab Full Bench LATCH Positions
Top Tether Anchorage Symbol
Lower Anchorage Symbol (2 Anchorages Per Seating Position) Top Tether Anchorage Symbol
Lower Anchorage Symbol (2 Anchorages Per Seating Position)

SAFETY 267
Frequently Asked Questions About Installing Child Restraints With LATCH
What is the weight limit (child’s weight
+ weight of the child restraint) for using
the LATCH anchorage system to attach
the child restraint? 65 lbs (29.5 kg)Use the LATCH anchorage system until the
combined weight of the child and the child
restraint is 65 lbs (29.5 kg). Use the seat belt
and tether anchor instead of the LATCH
system once the combined weight is more
than 65 lbs (29.5 kg).
Can the LATCH anchorages and the
seat belt be used together to attach a
rear-facing or forward-facing child
restraint? NoDo not use the seat belt when you use the
LATCH anchorage system to attach a
rear-facing or forward-facing child restraint.
Booster seats may be attached to the LATCH
anchorages if allowed by the booster seat
manufacturer. See your booster seat owner’s
manual for more information.
Can a child seat be installed in the
center position using the inner LATCH
lower anchorages from the outboard
seating positions? No – Crew Full Bench
N/A – Mega / Crew Split BenchRegular Cab Front / Crew Cab with full
bench rear seat: use the seat belt and tether
anchor to install a child seat in the center
seating position
Crew Cab with split bench rear seat / Mega
Cab: Child restraints can be installed using
the supplied lower anchorages for the center
seating position.
4

268 SAFETY
Can two child restraints be attached
using a common lower LATCH
anchorage?NoNever “share” a LATCH anchorage with two
or more child restraints. If the center position
does not have dedicated LATCH lower
anchorages, use the seat belt to install a child
seat in the center position next to a child seat
using the LATCH anchorages in an outboard
position.
Can the rear-facing child restraint touch
the back of the front passenger seat? YesThe child seat may touch the back of the front
passenger seat if the child restraint
manufacturer also allows contact. See your
child restraint owner’s manual for more
information.
Can the rear head restraints be
removed? YesThe head restraints can be removed in every
rear seating position if they interfere with the
installation of the child restraint. Refer to
“Head Restraints” in “Getting To Know Your
Vehicle” for further information.
Frequently Asked Questions About Installing Child Restraints With LATCH

SAFETY 269
Locating The LATCH Anchorages The lower anchorages are round bars that are found
at the rear of the seat cushion where it meets the seat -
back. They are just visible when you lean into the
rear seat to install the child restraint. You will easily feel
them if you run your finger along the gap between the seat -
back and seat cushion.
Mega Cab/Crew Cab Rear Outboard Seats Driver Side Locating The Upper Tether Anchorages
Regular Cab models have tether strap anchorages
behind the front center and right seats. Mega Cab
and Crew Cab models have tether strap anchorages
located behind each of the rear seats.
Regular Cab Tether Anchorages (Behind Covers)
1 — Tether Strap Hook
2 — Tether Strap To Child Restraint
3 — Tether Anchor
4

270 SAFETY
Crew Cab Outboard Tether AnchorageCrew Cab Center Tether Anchorage With Head Restraint
In Raised Position
