After driving in emergency mode havetherimscheckedbyaqualified special‐istworkshop withregardtotheir furtheruse.
The defective tire must bereplaced ineverycase.
WithMOExtended tires (run-flat tire),you cancontinuetodriveyourvehicleeven ifthere is atotal loss of pressure in one or more tires. How‐ever,the tire affected must not show any clearlyvisible damage.
You canrecognize MOExtended tiresbytheMOExtended marking which appears onthe sidewall ofthe tire.
Vehicles with tire pressure losswarning sys‐tem:MOExtended tires may only be used in con‐junction withan activated tire pressure losswarning system.
Vehicles with tire pressure monitoring sys‐tem:MOExtended tires may only be used in con‐junction withan activated tire pressure monitor‐ing system.
If a pressure losswarning message appears inthe multifunction display,proceed asfollows:
RCheckthe tirefor damage.
RIf driving on, observethefollowing notes.
Driving distance possible in emergencymode after the pressure losswarning:
Load condition Driving distance pos‐sible in emergencymode
Partially laden50 miles (80 km)
Fully laden19miles (30 km)
The driving distance possible in emergencymode mayvarydepending onthe drivingstyle.Observethe maximum permissible speed of50mph (80 km/h).
If a tire has goneflat and cannot bereplacedwith an MOExtended tire,you can use astand‐ard tire as atemporary measure.
TIREFIT kitstoragelocation
Mercedes-AMGvehicles:observethe notes inthe Supplement. Otherwise,you mayfailtorec‐ognize dangers.
The TIREFIT kit is located underthe trunkfloor.
1Tiresealant bottle
2Tireinflation compressor
Usingthe TIREFIT kit
Requirements:RTiresealant bottle
RTIREFITsticker
Breakdown assistance371

allowthe TPMStocontinuetofunction prop‐erly.
The systemchecksthe tire pressure andthe tiretemperature ofthe tires installed onthevehiclebymeans of a tire pressuresensor.
New tire pressure sensors, e.g. in winter tires,are automaticallytaught-in duringthefirst jour‐neytheyare used.
The tire pressure andthe tiretemperatureappear inthe multifunction display(page 396).
Ifthere is a substantial pressure loss or ifthetiretemperature isexcessive,you will bewarnedinthefollowingways:
Rvia display messages (page 466)
Rviathewwarning lamp inthe instrumentcluster (page 490)
The tire pressuremonitoring system is only anaid. It isthe driver'sresponsibilitytosetthe tirepressuretotherecommended cold tire pressuresuitableforthe operating situation. Setthe tirepressurefor cold tires using a tire pressure
gauge.Notethatthe correct tire pressureforthecurrent operating situation mustfirst betaught-intothe tire pressure monitoring system.
In most cases,the tire pressure monitoring sys‐tem will automatically updatethe newreferencevalues afteryou havechangedthe tire pressure.You can, however,also updatethereferenceval‐uesbyrestartingthe tire pressure monitoringsystem manually (page 397).
System limitations
The system may be impaired or may not functioninthefollowing situations:
RIfthe tire pressure is set incorrectly
RIfthere is a sudden pressure loss caused,forexample,byaforeign object penetratingthetire
RIfthere is a malfunction causedbyanotherradio signal source
Make suretoobservethefollowing furtherrela‐ted subject:
RNotes on tire pressure (page 392)
Checkingthe tire pressure withthe tire pres‐sure monitoring system
Requirements:RThe ignition is switched on.
On-board computer:
ServiceTires
One ofthefollowing displaysappears:
RCurrent tire pressure and tiretemperature ofthe individual wheels:
RTire pressure will be displayed after driving afew minutes
396Wheels and tires

RTire Pressure Monitor Active:theteach-inprocess ofthe system is notyet complete.The tire pressures are already being moni‐tored.
Comparethe tire pressure withtherecom‐mended tire pressureforthe current operat‐ing condition (page393). Observethenotes on tiretemperature (page 392).
Thevalues displayed inthe multifunction dis‐play may deviate fromthose ofthe tire pres‐suregauge astheyrefertosea level.Athighaltitudes,the tire pressurevalue indicatedbya pressuregauge are higherthanthoseshownbythe on-board computer. Inthiscase, do notreducethe tire pressure.
Make suretoobservethefollowing furtherrela‐ted subject:
RNotes on tire pressure (page 392)
Restartingthe tire pressure monitoring sys‐tem
Requirements:RTherecommended tire pressure is correctlysetfortherespective operatingstatus oneach ofthefour wheels (page 392).
Restartthe tire pressure monitoring system inthefollowing situations:
RThe tire pressure haschanged.
RThe wheels or tires havebeenchanged ornewly installed.
On-board computer:
ServiceTires
Swipe downwards onTouch Control ontheleft-hand side ofthesteering wheel.TheUse Current Pressures as New Refer-ence Values?message is shown inthe multi‐function display.
Tobeginrestart, pressTouch Control ontheleft-hand side ofthesteering wheel.TheTire Press. Monitor Restartedmessage isshown inthe multifunction display.
Currentwarning messages are deleted andtheyellowwwarning lamp goes out.
Afteryou havebeen drivingfor afewminutes,the systemcheckswhetherthe cur‐rent tire pressures are withinthe specifiedrange. The current tire pressures arethenaccepted asreferencevalues and monitored.
Make suretoobservethefollowing furtherrela‐ted subject:
RNotes on tire pressure (page 392)
Radio equipment approval ofthe tire pres‐sure monitoring system
Radio equipment approval numbers
CountryRadio type approval number
Canada IC: 2546A-GG4T
IC: 2546A-DG6W2D4
IC: 2546A-MC34MA4
USAFCC ID: MRXGG4T
FCC ID: MRXDG6W2D4
FCC ID: MRXMC34MA4
Wheels and tires397

Further information onthe declaration of con‐formityfor wirelessvehicle components(page 25).
Tirepressure losswarning system
Function ofthe tire pressure losswarningsystemThe tire pressure losswarning systemwarnsthedriverbymeans of display messages whenthereis a severetire pressureloss.
After achange in tire pressure, a wheelrotationor a tirechange, or ifyou havere-installedwheels or tires,the tire pressure losswarningsystem hastoberestarted (page 398).
The tire pressure losswarning system does notreplacethe needtoregularlycheckthe tire pres‐sure.
System limitations
The system may be impaired or may not functionparticularlyinthefollowing situations:
RIncorrectly set tire pressure
RSudden pressure loss caused,forexample,byaforeign object penetratingthe tire
RSteady pressure loss in several tires
The system has arestricted or delayed functionparticularly inthefollowing situations:
RPoor ground conditions, e.g. snow or gravel
RDriving withsnowchains
RWhen adopting averysporty drivingstylewith high cornering speeds or sudden accel‐eration
RDriving with a high load
Be suretoalso observethefollowing furtherrelated subjects:
RNotes on tire pressure (page 392)
RDisplay messages aboutthe tires(page 466)
Restartingthe tire pressure losswarningsystem
Requirements:RTherecommended tire pressure is correctlysetfortherespective operatingstatus oneach ofthefour wheels (page 392).
Restartthe tire pressure losswarning system inthefollowing situations:
RThe tire pressure haschanged.
RThe wheels or tires havebeenchanged ornewly installed.
On-board computer:
ServiceTires
Swipe downwards ontheTouch Control onthe left-hand side ofthesteering wheel.TheTire Pressure Control SystemActiveRestart: Press Touch Controlmessageis shown inthe multifunction display.
Restartthe tire pressure losswarning system inthefollowing situations:
RThe tire pressure haschanged.
RThe wheels or tires havebeenchanged ornewly installed.
Tobegintherestart, presstheTouch Controlonthe left-hand side ofthesteering wheel.TheTire Pressure Now OK?message isshown inthe multifunction display.
398Wheels and tires

SelectYes.
Toconfirmtherestart, presstheTouch Con‐trol onthe left-hand side ofthesteeringwheel.TheRun Flat Indicator Restartedmessage isshown inthe multifunction display.
Afteryou havedrivenfor afew minutes,thetire pressurelosswarning system monitorsthe set tire pressures of allthe tires.
Be suretoalso observethefollowing furtherrelated subjects:
RNotes on tire pressure (page 392)
Loadingthevehicle
Notes onTireand Loading Information plac‐ard
\nWARNINGRisk of accident fromoverloa‐ded tires
Overloaded tires mayoverheat and burstas aconsequence. Overloaded tires can alsoimpairthesteering and handlingcharacteris‐tics and leadtobrakefailure.
Observethe load-bearing capacity ofthe tires.
The load-bearing capacity must be atleast halfthe gross axleweightrating ofthevehicle.
Neveroverloadthe tiresby exceedingthe maximum load.
TheTireand Loading Information placard is onthe B-pillar onthe driver's side ofthevehicle.
1Tireand Loading Information placard
The data shown inthe illustration isexampledata.
TheTireand Loading Information placard shows:
RMaximum number of seats2accordingtothe maximum number of people permittedtotravel inthevehicle.
RMaximum permissible load3comprisesthegrossweight of allvehicle occupants, loadand luggage.
Wheels and tires399

Display messages
Introduction
Notes on display messagesDisplay messages appear onthe multifunctiondisplay.
Displaymessages with graphic symbols are sim‐plified inthe Operator's Manual and may differfromthe symbols onthe multifunction display.The multifunction display showshigh-priority dis‐play messages inred. Certain display messagesare accompaniedbyawarningtone.
Pleaserespond in accordance withthe displaymessages andfollowthe additional notes inthisOperator's Manual.
For some display messages, a symbol is alsoshown:
R

Safety systems
Display messagesPossible causes/consequences andPPSolutions

Display messagesPossible causes/consequences andPPSolutions
$
(Canada only)
Turn On the Ignition toRelease the Parking Brake
I
(USA only)
$
(Canada only)
Parking Brake See Opera-tor's Manual
*Theyellow$indicator lamp is lit. The electric parking brake is malfunctioning.
Toapply:
Switch offthe ignition and switch it back on.
Applythe electric parking brake manually (page169).
If it isnot possibletoapplythe electric parking brake:
Visit aqualified specialistworkshop.
Where necessary,also safeguardthe parkedvehicle againstrollingaway.Theyellow$andtheredI(USA only) or$(Canada only) indicator lamps are lit. The electric parkingbrake is malfunctioning.
Torelease:
Switchoffthe ignition and switch it back on.
Releasethe electric parking brake manually (page169).
Displaymessages andwarning/indicator lamps435
