2019 MASERATI QUATTROPORTE dashboard

Dear Customer,
Thank you for choosing a Maserati.
This vehicle represents the result of Maserati's great experience in the design and production of sports, touring and
racing vehicles.
With this manual you will acquaint yourself with the equipment and options of your Maserati in order to take advantage
of its full potential.
Before driving your vehicle for the first time, we suggest reading the printed Quick Guide carefully in order to quickly
acquaint with commands and functions of your vehicle. You can consult this Owner's Manual and the Maserati Touch
Control Plus guide directly from the dashboard touchscreen display of your vehicle.
The updated version of the onboard documentation can be consulted by accessing the section “Services” on the website
www.maserati.com.
In a dedicated section of this manual you will also find instructions for basic maintenance procedures, in order to ensure
steady levels of performance, quality and safe driving.
Keep in mind that proper maintenance is an essential factor to help preserve the value of the vehicle over time and
protect the environment.
For “Scheduled Maintenance” or any other operation, contact your Authorized Maserati Dealer : you can trust our
trained technical staff, who is constantly updated and provided with the required equipment in order to ensure that all
service operations are performed properly and reliably.
The Quick guide and other documents contained in onboard documentation kit are integral part of the vehicle and
should always be kept on board.
You can purchase a printed copy of the documents visible on dashboard touchscreen display at your dealer of your
Authorized Maserati Dealer .
2

Introduction
Before Starting
Understanding the Vehicle
Dashboard Instruments and Controls
Driving
In an Emergency
Maintenance and Care
Features and Specifications
Index 1
2
3
4
5
6
7
8
9 5

• NEW VEHICLES: Your membership
begins on the date the Registered
Vehicle was originally sold (in service
date) and continues until the
expiration date of the New Car
Limited Warranty or unless
terminated by Maserati North
America, Inc. for cause.
• PRE OWNED VEHICLES: Your
membership begins on the date the
registered vehicle was sold (in service
date) and continues until the
expiration date of the Maserati
Certified Pre-Owned Limited
Warranty or unless terminated by
Maserati North America, Inc for
cause. Address Inquiries to
General Inquiries:
Maserati Roadside Assistance
P.O. Box 968008
Schaumburg, IL 60173
Rental Car Reimbursements:
Within 20 days of your rental car
transaction, the original pre-printed
rental car receipt, which must include
your name, address, telephone
number, VIN, rental dates and the
corresponding warranty repair order
should be submitted to:
Maserati Roadside Assistance ATTN:
Maserati Rental Car Claims Dept.
P.O. Box 8140
Ft. Washington, PA 19034Vehicle Identification Data Vehicle Identification Number The vehicle's identification number
(VIN) is punched on the foot platform,
in front of the right-hand front seat.
To read the number, lift the mat and
slide the guard.
The VIN Number is also visible from
the outside through the windshield on
the front left corner of the dashboard.Introduction
1
18

Passenger Air bag Labels
The labels are applied on the external
side of sun visors and behind it, on the
dome.
Another label is applied on the
dashboard to indicate that air bag
system is installed. Loading Information Label
This label applied on the driver's side
rear door pillar attests the compliance
with safety standards. Tire Information Label
This paper label is applied on the
driver's side rear door pillar.
NOTE:
For further informations see “Tire
Safety Information” in section
"Driving".
Paint Identification Label
The label is applied on the lower left
side of the hood.Introduction
1
20

NOTE:
Refer to “MTC+ Settings” in Section
“Dashboard Instruments and Controls”
for further information.
WARNING!
• When leaving the vehicle, always
remove the key fob and lock your
vehicle.
• Do not allow children to be in a
vehicle unattended or with access to
an unlocked vehicle. A child or
others could be seriously or fatally
injured. Children should be warned
not to touch the parking brake
trigger, brake pedal or the shift
lever.
• Do not leave the key fob in or near
the vehicle, and do not leave the
ignition switch in the ACC or RUN
mode. A child could operate power
windows, other controls, or move
the vehicle.
• Do not leave children or animals
inside parked vehicles in hot
weather. Interior heat build-up may
cause serious injury or death.
• An unlocked car is an invitation to
thieves. Always remove the key fob
from vehicle, cycle the ignition switch to OFF and lock all doors
when leaving the vehicle
unattended.
Sentry Key ®
Immobilizer
System The Sentry Key ®
Immobilizer System
prevents unauthorized vehicle
operation by disabling the engine. The
system does not need to be armed or
activated. Operation is automatic,
regardless of whether the vehicle is
locked or unlocked.
The system uses a key fob with Remote
Keyless Entry (RKE) transmitter, an
ignition switch and a RF (Radio
Frequency) receiver to prevent
unauthorized vehicle operation.
Therefore, only key fobs expressly
programmed can be used to start and
operate the vehicle.
After placing the ignition in the RUN
position, the Vehicle Security Light (see
picture) will light up for a three
seconds bulb check.Before Starting
2
26

Vehicle Security Alarm The vehicle security alarm monitors the
vehicle doors and trunk for
unauthorized entry and the
START/STOP button for unauthorized
operations.
The system includes a dual function
anti-intrusion sensor and vehicle
anti-lift sensor. The anti-intrusion
sensor monitors the vehicle interior for
motion.
The vehicle anti-lift sensor monitors
the vehicle for any lifting or tilting
actions (tow away, tire removal, ferry
transport, etc). A siren with battery
backup which senses interruptions of
power and communications is also
included.
While the vehicle security alarm is
enabled, interior door locks switches,
trunk lid and fuel filler door release
are disabled. If something triggers the
alarm, the vehicle security alarm will
provide the following audible and
visible signals: intermittent buzzer,
position lights and/or turn signals and
the vehicle security light on the
dashboard will flash.
This light will fast flash for
approximately 15 seconds, when the
vehicle security alarm is being armed, and will then flash slowly until the
vehicle is disarmed.
Rearming the System If something triggers the security
alarm, and no quick action is taken to
disarm it, the vehicle security alarm
will turn off the beeper after 29
seconds, and turn off all of the visual
signals after 31 more seconds; the
vehicle security alarm will then rearm
itself. Arming the System Follow these steps to arm the vehicle
security alarm.
• Make sure the vehicle ignition switch
is OFF .
• Perform one of the following
methods to lock the vehicle:
• Press the
lock button on the
interior power door lock switch
located on the driver door trim
panel with the driver and/or
passenger door open.Before Starting
2
28

Vehicle Lighting with
Open/Closed Doors • If one or more doors are open, the
central light, front/rear domelights
(main and spot light), the instrument
cluster, the MTC+ display, the night
front seats lighting and the ignition
switch backlight will turn on and will
light up for 27 seconds.
• If the doors are closed, all lights will
turn off (within 3 seconds) with the
exception of the console display and
the ignition switch backlight, which
will turn off after 27 seconds. Use of Light Switch for Vehicle
Lighting Vehicle lighting can be operated from
the key fob RKE transmitter, the
“Passive Entry” system and from the
light switch on the left side of the
dashboard (refer to “Lights” in section
“Understanding the Vehicle” for
further information).Before Starting
2
32

Unlock the Doors, Fuel Filler
Door and Trunk Press and release the unlock button
on the key fob RKE transmitter once
to unlock the driver's door or twice
within five seconds to unlock all doors,
the fuel filler door and the power
trunk lid. The turn signal lights will
flash for the unlock signal recognition.
The illuminated entry/exit system will
also turn on. See “Passive Entry
System” in this section for further
information.
Unlock Driver Door/All Doors with
Remote Key 1 st
Press
This feature allows you to program the
system to unlock either the driver's
door or all doors, the fuel filler door
and the trunk lid, by the first press of
the unlock button
on the key fob
RKE transmitter. To change the current
setting, see “MTC+ Settings” in section
“Dashboard Instruments and
Controls”.
Lock/Unlock Doors Flash Lights
This feature will cause the flash of the
turn signal lights when the doors are
locked or unlocked with the key fob
RKE transmitter. This feature can be
turned on or turned off. To change the
current setting, see “MTC+ Settings” in section “Dashboard Instruments and
Controls”.
Turn Headlights On with Remote key
This feature activates the headlights
for up to 90 seconds when the doors
are unlocked with the key fob RKE
transmitter. The duration can be set as
desired. To change the current setting,
see “MTC+ Settings” in section
“Dashboard Instruments and
Controls”.
Locking Doors Sound Alarm This feature will cause the alarm to
activate when the doors are locked
with the key fob RKE transmitter. This
feature can be enabled or disabled. To
change the current setting, see “MTC+
Settings” in section “Dashboard
Instruments and Controls”.
Unlatch the Trunk Lid Press the button on the key fob
RKE transmitter two times within five
seconds to unlatch and fully open the
power trunk lid.
See chapters “Passive Entry System”
and “Power Trunk Lid Operation” in
this section for further information.Requiring and Setting
Additional Key fobs Provide your Authorized Maserati
Dealer the following when ordering
additional key fob RKE transmitters:
• all key fobs RKE transmitters in your
possession;
• a personal ID;
• the identification and registration
documents proving ownership of the
vehicle.
Setting new key fobs or re-setting the
original ones can only be performed at
an Authorized Maserati Dealer .
NOTE:
Codes of any key fob RKE transmitters
that are not present when the new
setting procedure is done will be
deleted from the memory to prevent
lost or stolen key fobs transmitters
being used to disarm the electronic
alarm system.Before Starting
2
34
