2019 LEXUS RX350 Owners Manual

528
RX350/RX350L_U 6-4. Using the storage features 
Vehicles with bench-type second-row seats
List of storage features
Glove box (  P. 530)
Auxiliary boxes (if equipped)
(  P. 535)
Door pockets (  P. 533) Bottle holders (  P. 533)
Console box (  P. 530)
Cup holders (  P. 531)
Coin box (  P. 534)1
2
3 4
5
6
7

5296-4. Using the storage features
6
Interior features
RX350/RX350L_U 
Vehicles with separate-type second-row seats
Glove box (  P. 530)
Auxiliary boxes (if equipped)
(  P. 535)
Door pockets (  P. 533) Bottle holders (  P. 533)
Console box (  P. 530)
Cup holders (  P. 531)
Coin box (  P. 534)WARNING ●
Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracke d if they come into contact with other
stored items.
• Lighters or spray cans may explode. If they come into contact with other stored
items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard. ●
When driving or when the storage compartments are not in use, keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur due to an
occupant being struck by an open lid or the items stored inside.1
2
3 4
5
6
7

530 6-4. Using the storage features
RX350/RX350L_U Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key
The glove box light turns on when the tail lights are on.
Push the knob. Lift by hand to fully open the console
box.
●
The console box light turns on when the tail lights are on.Glove box 1
2
3
Console box ●
A pen can be stored in the pen holder on the
underside of the lid.
●
Remove the tray to access a storage space
under the tray.

5316-4. Using the storage features
6
Interior features
RX350/RX350L_U Cup holders 
Front seats 
Second-row seats (Type A)
Pull down the armrest and
Then press down the button.
Second-row seats (Type B)
Press in the button.

532 6-4. Using the storage features
RX350/RX350L_U The depth of the front cup holder can be changed.
To store a water bottle, push down the bottom
of the cup holder.
To return the bottom to its original position,
press the button.
WARNING ●
Do not place anything other than cups, aluminum cans, or water bottles in the cup
holders. Other items may be thrown out of the holders in the event of an accident or
sudden braking, possibly causing injury. If possible, cover hot drinks to prevent burns.●
Rear cup holder: When not in use, keep the cup holders are closed. Injuries may
result in the event of an accident or sudden braking.
NOTICE
To prevent damage to the rear cup holder, stow the cup holder before stowing the arm-
rest. 1
2

5336-4. Using the storage features
6
Interior features
RX350/RX350L_U Door pockets 
Front 
Rear
The door pockets can be opened and
closed. WARNING
Front door pockets: Keep the door pockets closed while driving.
Injuries may result in the event of an accident or sudden braking.
Bottle holders

534 6-4. Using the storage features
RX350/RX350L_U ●
When storing a bottle, close the cap. ●
The bottle may not be stored depending on its size or shape.
Press in the button. NOTICE
Do not place open bottle, glass or paper cups containing liquid in the bottle holders.
Otherwise, contained liquid may be spilled. Glass cups may break if used in the bottle
holders.
Coin box
WARNING
Keep the coin box closed while driving.
Injuries may result in the event of an accident or sudden braking.

5356-4. Using the storage features
6
Interior features
RX350/RX350L_U Auxiliary boxes 
Type A 
Type B
Press in the lid. Lift the lid. 
Type C (if equipped)
Pull up the lever to release the lock, and
lift the lid. WARNING
Type A: Do not store items he avier than 0.44 lb. (200 g).
Doing so may cause the auxiliary box to open and the items inside may fall out, result-
ing in an accident.
