2019 LEXUS RX350 Owners Manual

696 8-2. Steps to take in an emergency
RX350/RX350L_U WARNING ■
When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the surrounding
area is clear to avoid striking other vehicl es, objects or people. The vehicle may also
lunge forward or lunge back suddenly as it becomes free. Use extreme caution. ■
When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may cause an acci-
dent resulting in deat h or serious injury.
NOTICE ■
To avoid damage to the tran smission and other components●
Avoid spinning the front wheels and depre ssing the accelerator pedal more than nec-
essary. ●
If the vehicle remains stuck even after th ese procedures are performed, the vehicle
may require towing to be freed. ●
When a warning message for the automatic transmission fluid temperature is dis-
played while attempting to free a stuck vehicle, immediately remove your foot from
the accelerator pedal and wait until the warning message disappears. Otherwise, the
transmission may become damaged. (  P. 662)

697
9Vehicle specifications
RX350/RX350L_U 9-1. Specifications
Maintenance data
(fuel, oil level, etc.) ..................698
Fuel information.......................... 706
Tire information .......................... 709
9-2. Customization
Customizable features ............ 722
9-3. Initialization
Items to initialize ......................... 735

698
RX350/RX350L_U 9-1. Specifications
* 1
:RX350
* 2
:RX350L
* 3
:Unladen vehicle
* 4
: Vehicles with towing package
* 5
: For GGL25L-BWZGBA models* 9
* 6
: Except for GGL25L-BWZGBA models* 9
* 7
: Vehicles with separate seat
* 8
: Vehicles with bench seat
* 9
: The model code is indicated on the Certification Label. (  P. 699)Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 192.5 in. (4890 mm)
* 1
196.9 in. (5000 mm)
* 2
Overall width 74.6 in. (1895 mm)
Overall height
* 3
67.7 in. (1720 mm)
Wheelbase 109.8 in. (2790 mm)
Tread Front 64.4 in. (1635 mm)
* 1
64.5 in. (1640 mm)
* 2
Rear 64.0 in. (1625 mm)
* 1
64.1 in. (1630 mm)
* 2
Vehicle capacity weight
(Occupants + luggage) 1050 lb. (480 kg)
* 1, 5
920 lb. (420 kg)
* 1, 6
1140 lb. (520 kg)
* 2, 7
1235 lb. (560 kg)
* 2, 8
Trailer Weight Rating
* 4
(Trailer weight + cargo weight) 3500 lb. (1585 kg)

6999-1. Specifications
9
Vehicle specifications
RX350/RX350L_U ■
Vehicle identification number
The vehicle identification number (VIN) is the legal identifier for your vehicle.
This is the primary identification number fo r your Lexus. It is used in register-
ing the ownership of your vehicle.
This number is stamped on the top
left of the instrument panel.
This number is also on the Certifica-
tion Label.
On some models, this number is also
stamped under the right-hand front
seat.Vehicle identification

700 9-1. Specifications
RX350/RX350L_U ■
Engine number
The engine number is stamped on
the engine block as shown.
* : The engine oil capacity is a reference quantity to be used when changing the engine
oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.Engine Model 3.5 L 6-cylinder (2GR-FKS)
Type 6-cylinder V type, 4-cycle, gasoline
Bore and stroke 3.70  3.27 in. (94.0  83.0 mm)
Displacement 210.9 cu. in. (3456 cm 3
)
Valve clearance (engine cold) Automatic adjustment
Drive belt tension Automatic adjustment
Fuel Fuel type Unleaded gasoline only
Octane Rating 87 (Research Octane Number 91) or higher
Fuel tank capacity (Reference) 19.2 gal. (72.5 L, 15.9 Imp. gal.)
Lubrication system Oil capacity
(Drain and refill - reference
* )
With filter 
Vehicles with towing package
5.8 qt. (5.5 L, 4.8 Imp. qt.) 
Vehicles without towing package
5.7 qt. (5.4 L, 4.8 Imp. qt.)
Without filter 5.6 qt. (5.3 L, 4.7 Imp. qt.)

7019-1. Specifications
9
Vehicle specifications
RX350/RX350L_U ■
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20
at the next oil change.
Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allows cold
startability. Oils with a lower value be fore the W allow for easier starting of
the engine in cold weather.
• The 20 in 0W-20 indicates the viscos ity characteristic of the oil when the
oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the ve hicle is operated at high speeds, or
under extreme lo ad conditions.
How to read oil container label:
The International Lubricant Specifi-
cation Advisory Committee
(ILSAC) Certification Mark is added
to some oil containers to help you
select the oil you should use. Outside temperature

702 9-1. Specifications
RX350/RX350L_U * : The coolant capacity is a reference quantity.
If replacement is necessary, contact your Lexus dealer.Cooling system Capacity
* 
RX350 (Vehicles with out towing package)
9.5 qt. (9.0 L, 7.9 Imp. qt.) 
RX350 (Vehicles with towing package)
10.5 qt. (9.9 L, 8.7 Imp. qt.) 
RX350L
13.1 qt. (12.4 L, 11 Imp. qt.)
Coolant type Use either of the following:
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based
non-silicate, non-amine, non-nitrite, and non-
borate coolant with long-life hybrid organic
acid technology
Do not use plain water alone.
Ignition system (spark plug) Make DENSO FK20HBR8
Gap 0.03 in. (0.8 mm)
NOTICE ■
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.
Electrical system Battery
Open voltage at 68  F (20  C): 12.6 V or higher: Fully charged
12.2 — 12.4 V: Half charged
12.0 V or lower: Discharged
(Turn the engine switch off and turn on the head-
lights for 20 to 30 seconds.)
Charging rates 5 A max.

7039-1. Specifications
9
Vehicle specifications
RX350/RX350L_U * : The fluid capacity is a reference quantity.
If replacement is necessary, contact your Lexus dealer.
Your Lexus vehicle is filled with “Toyot a Genuine Differential Gear Oil” at the
factory.
Use Lexus approved “Toyota Ge nuine Differential Gear O il” or an equivalent of
matching quality to satisfy the above specification. Please contact your Lexus
dealer for further details.
Your Lexus vehicle is filled with “Toyot a Genuine Differential Gear Oil” at the
factory.
Use Lexus approved “Toyota Ge nuine Differential Gear O il” or an equivalent of
matching quality to satisfy the above specification. Please contact your Lexus
dealer for further details.Automatic transmission Fluid capacity
* 7.2 qt. (6.8 L, 6.0 Imp. qt.)
Fluid type Toyota Genuine ATF WS
NOTICE ■
Transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration
in shift quality, locking up of your transm ission accompanied by vibration, and ulti-
mately damage the transmission of your vehicle.
Transfer (AWD models) Oil capacity 0.8 qt. (0.8 L, 0.7 Imp. qt.)
Oil type and viscosity Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent
Rear differential (AWD models) Oil capacity 0.5 qt. (0.5 L, 0.4 Imp. qt.)
Oil type and viscosity Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent
