2734-4. Refueling
4
Driving
RX350/RX350L_U After refueling, turn the fuel tank cap
until you hear a click. Once the cap
is released, it will turn slightly in the
opposite direction.
Close the fuel filler door, and press
the center of the rear edge of the
fuel filler door. When you lock the doors, the fuel filler
door will lock also. ■
Fuel filler door lock condition
The fuel filler door may not be locked even when the vehicle’ s doors are locked in the fol-
lowing conditions: ●
When operating the door lock button inside the vehicle●
When the automatic door lock ing system is operated ( P. 127)●
When the fuel filler door is closed after the vehicle’s doors are lockedClosing the fuel tank cap 1
2
WARNING ■
When replacing the fuel tank cap
Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle. Doing
so may cause a fire or other incident whic h may result in death or serious injury.
776
RX350/RX350L_U GAS STATION INFORMATION
Auxiliary catch lever Fuel filler door
P. 592 P. 271
Hood lock release lever Tire inflation pressure
P. 592 P. 704
Fuel tank capacity
(Reference) 19.2 gal. (72.5 L, 15.9 Imp. gal.)
Fuel type Unleaded gasoline only P. 700
Cold tire inflation
pressure P. 704
Engine oil capacity
(Drain and refill —
reference) With filter qt. (L, Imp. qt.)
Vehicles with towing package 5.8 (5.5, 4.8)
Vehicles without towing package 5.7 (5.4, 4.8)
Without filter 5.6 (5.3, 4.7)
Engine oil type “Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
P. 701
