2019 LEXUS LS500 Owners Manual

4016-3. Do-it-yourself maintenance
LS500_OM_(U)_1810 6
Maintenance and care 1 Turn the engine switch off.
2 Open the fuse box cover. 
Engine compartment: type A fuse
box Remove the service cover (  P.375) and
push the tabs in and lift the lid off.

Engine compartment: type B fuse
box Remove the engine compartment cover
(  P.374) and push the ta bs in and lift the
lid off. 
Driver’s side instrument panel Push the tab in and remove the lid.
Make sure to push the tab in during
removal or installation.

Passenger’s side instrument panel Push the tab in and remove the lid.
Make sure to push the tab in during
removal or installation.

Trunk Remove the luggage mat. (  P.340)
Push the tab in and lift the lid off.Checking and replacing
fuses If any of the electrical components
do not operate, a fuse may have
blown. If this happens, check and
replace the fuses as necessary.
Checking and replacing fuses

402 6-3. Do-it-yourself maintenance
LS500_OM_(U)_1810 3 Remove the fuse with the pullout
tool.
Only type A fuse can be removed
using the pullout tool.
4 Check if the fuse is blown.Type A and B:
Replace the blown fuse with a new fuse of
an appropriate amperage rating. The
amperage rating can be found on the fuse
box lid.
Type C and D:
Contact your Lexus dealer. 
Type A
Normal fuse
Blown fuse 
Type B
Normal fuse
Blown fuse 
Type C
Normal fuse
Blown fuse A
B
A
B
A
B

4036-3. Do-it-yourself maintenance
LS500_OM_(U)_1810 6
Maintenance and care 
Type D
Normal fuse
Blown fuse ■
After a fuse is replaced●
When installing the lid, make sure that the
tab is installed securely.●
If the lights do not turn on even after the
fuse has been replaced, a bulb may need
replacement.●
If the replaced fuse blows again, have the
vehicle inspected by your Lexus dealer.■
If there is an overload in a circuit
The fuses are designed to blow, protecting
the wiring harness from damage.
WARNING■
To prevent system breakdowns and
vehicle fire
Observe the following precautions.
Failure to do so may cause damage to
the vehicle, and possibly a fire or injury.
●
Never use a fuse of a higher amperage
rating than that indicated, or use any
other object in place of a fuse.
●
Always use a genuine Lexus fuse or
equivalent.
Never replace a fuse with a wire, even
as a temporary fix.
●
Do not modify the fuses or fuse boxes. A
B NOTICE■
Before replacing fuses
Have the cause of electrical overload
determined and repaired by your Lexus
dealer as soon as possible.

404 6-3. Do-it-yourself maintenance
LS500_OM_(U)_1810 ■
LED Lights
The lights consist of a number of LEDs. If
any of the LEDs burn out, take your vehicle
to your Lexus dealer to have the light
replaced. ■
Condensation build-up on the inside of
the lens
Temporary condensation build-up on the
inside of the headlight lens does not indi-
cate a malfunction. Contact your Lexus
dealer for more information in the following
situations: ●
Large drops of water ha ve built up on the
inside of the lens.●
Water has built up inside the headlight.Light bulbs If any lights burn out, have it
replaced by your Lexus dealer.

405
LS500_OM_(U)_1810 7 7
When trouble arises When trouble arises .
7-1. Essential information
Emergency flashers.................. 406
If your vehicle has to be stopped in
an emergency .......................... 406
If the vehicle is trapped in rising
water............................................ 407
7-2. Steps to take in an emergency
If your vehicle needs to be towed
........................................................ 409
If you think something is wrong
......................................................... 413
Fuel pump shut off system ...... 414
If a warning light turns on or a
warning buzzer sounds ........ 415
If a warning message is displayed
........................................................ 425
If you have a flat tire.................. 429
If the engine wi ll not start ....... 430
If you lose your keys ................. 432
If the fuel filler door cannot be
opened........................................ 432
If the electronic key does not
operate properly .................... 433
If the vehicle battery is discharged
........................................................ 435
If your vehicle overheats ........ 440
If the vehicle becomes stuck
........................................................ 443

406 7-1. Essential information
LS500_OM_(U)_1810 7-1.Essential information
Press the switch to flash all of the turn
signal lights. To turn them off, press the switch once
again.
■
Emergency flashers●
If the emergency flashers are used for a
long time while the engine is not running,
the battery may discharge.●
If any of the SRS airbags deploy (inflate)
or in the event of a strong rear impact, the
emergency flashers will turn on automati-
cally.
The emergency flashers will turn off auto-
matically after operating for approxi-
mately 20 minutes. To manually turn the
emergency flashers off, press the switch
twice.
(The emergency flashers may not turn on
automatically depending on the force of
the impact and conditions of the colli-
sion.) 1 Steadily step on the brake pedal
with both feet and firmly depress it. Do not pump the brake pedal repeatedly
as this will increase the effort required to
slow the vehicle.
2 Shift the shift position to N. 
If the shift position is shifted to N
3 After slowing down, stop the vehi-
cle in a safe place by the road.
4 Stop the engine. 
If the shift position cannot be shifted
to N
3 Keep depressing the brake pedal
with both feet to reduce vehicle
speed as much as possible.
4 To stop the engine, press and hold
the engine switch for 2 consecutive Emergency flashers The emergency flashers are used to
warn other drivers when the vehicle
has to be stopped on the road due
to a breakdown, etc.
Operating instructions If your vehicle has to be
stopped in an emergency Only in an emergency, such as if it
becomes impossible to stop the
vehicle in the normal way, stop the
vehicle using the following proce-
dure:
Stopping the vehicle

4077-1. Essential information
LS500_OM_(U)_1810 7
When trouble arises seconds or more, or press it briefly
3 times or more in succession.
5 Stop the vehicle in a safe place by
the road.  Remove the seat belt first.
 If the door can be opened, open the
door and exit the vehicle.
 If the door can not be opened, open
the window using the power window
switch and exit the vehicle through
the window.
 If the window can not be opened
using the power window switch,
remain calm, wait until the water
level inside the vehicle rises to the
point that the water pressure inside
of the vehicle equals the water pres-
sure outside of the vehicle, and then
open the door and exit the vehicle.WARNING■
If the engine has to be turned off while
driving
Power assist for the steering wheel will
be lost, making th e steering wheel
heavier to turn. Decelerate as much as
possible before turning off the engine. If the vehicle is trapped in
rising water In the event the vehicle is sub-
merged in water, remain calm and
perform the following.

408 7-1. Essential information
LS500_OM_(U)_1810 WARNING■
Using an emergency hammer *
for
emergency escape
The rear window of this vehicle can be
shattered by an emergency hammer *

used for emergency escape, however,
since the windshield, front side windows
and rear side windows are laminated
glass they can not be shatteredby an
emergency hammer *
.*
: Contact your Lexus dealer or after-
market accessory manufacturerfor
further information about an emer-
gency hammer.■
Escaping the vehicle from the window
There are cases where escaping the
vehicle from the window is not possible
due to seating position, passenger body
type, etc.
When using an emergency hammer,
consider your seat location and the size
of the window opening to ensure that the
opening is accessible and large enough
to escape.
