IN AN EMERGENCY
A punctured tyre or a burnt-out bulb?
At times, a problem may interfere with
our journey.
The pages on emergencies can help
you to deal with critical situations
independently and with calm.
In an emergency we recommend that
you call the freephone number found in
the Warranty Booklet.
It is also possible to call the national or
international universal freephone
number to search for the nearest Fiat
Dealership.HAZARD WARNING LIGHTS.....152
BULB REPLACEMENT.........152
REPLACING FUSES..........158
CHANGING A WHEEL.........163
FIX&GO KIT................167
EMERGENCY STARTING.......170
FUEL CUT-OFF SYSTEM.......172
AUTOMATIC TRANSMISSION - LEVER
UNLOCK.................172
AUTOMATIC TRANSMISSION - KEY
REMOVAL.................173
DUAL CLUTCH AUTOMATIC
TRANSMISSION - LEVER
UNLOCK.................174
DUAL CLUTCH AUTOMATIC
TRANSMISSION - REMOVING THE
KEY.....................175
TOWING THE VEHICLE........176
151

HAZARD WARNING
LIGHTS
CONTROL
Press the button fig. 118 to switch the
lights on/off.
When the hazard warning lights are on,
the
andwarning lights flash.
IMPORTANT The use of hazard warning
lights is governed by the highway code
of the country you are driving in:
comply with legal requirements.
Emergency braking
In the event of emergency braking the
hazard warning lights switch on
automatically as well as warning lights
andin the instrument panel.
The lights switch off automatically when
emergency braking ceases.
BULB
REPLACEMENT
139) 140) 141) 142)
72)
GENERAL
INSTRUCTIONS
Before replacing a bulb check the
contacts for oxidation;
replace blown bulbs with others of
the same type and power;
after replacing a headlight bulb,
always check its alignment;
when a light is not working, check
that the corresponding fuse is intact
before replacing the bulb. For the
location of fuses, refer to the paragraph
“Replacing fuses” in this chapter.
IMPORTANT When the weather is cold
or damp or after heavy rain or washing,
the surface of headlights or rear lights
may steam up and/or form drops of
condensation on the inside. This is a
natural phenomenon due to the
difference in temperature and humidity
between the inside and the outside of
the glass which does not indicate a
fault and does not compromise the
normal operation of lighting devices.The mist disappears quickly when the
lights are turned on, starting from the
centre of the diffuser, extending
progressively towards the edges.
118F1B0632C
152
IN AN EMERGENCY

BULBS TYPES
The vehicle is equipped with the following bulbs
Glass bulbs (type A): they are press-fitted. Pull to extract.
Bayonet-type bulbs (type B): to remove them from their holder,
press the bulb and turn it anticlockwise, then extract it.
Tubular bulbs (type C): release them from their contacts to remove.
Halogen bulbs (type D): to remove the bulb, turn the connector to
the side and pull it out.
Halogen bulbs (type E): to remove the bulb, turn it anticlockwise.
153

Light bulbs Type Power Figure reference
Front side lights/Daytime running lights (DRL) LED – –
Rear side/brake light LED – –
Main beam/dipped beam headlights (halogen) H4 60/55W D
Main beam/dipped beam headlights (LED) LED – –
Front direction indicators WY21W 21W B
Rear direction indicators WY21W 21W B
Side direction indicators (on door mirror) WY5W 5W A
3rd stop LED – –
Number plate W5W 5W A
Fog
lights
IBMPHFO
H11 55W E
Rear fog light P21W 21W B
Reverse gear P21W 21W B
Front ceiling light C5W 5W A
Front roof lights (sun visors) C5W 5W A
Rear ceiling light (versions without sun roof) C5W 5W A
Rear roof lights (versions with sun roof) C5W 5W C
Boot ceiling lights W5W 5W A
154
IN AN EMERGENCY
Fog
lights
-&%
-&%


o o

REPLACING AN
EXTERNAL BULB
Main beam/dipped beam headlights
(halogen)
To replace the bulb, proceed as follows:
working from inside the engine
compartment, remove the rubber cap A
fig. 119, using the dedicated tab;
press
the
electric
connector
B
fig.
120
downwards
to
release
the

bulb
and
bulb
holder
assembly
from

the
housing;
pull
out
the
bulb
holder
outwards;
disconnect
the
electrical
connector
B

and
replace
the
bulb
C.
then
insert
the
bulb
and
bulb
holder

assembly
in
its
housing
and
press
it

until
you
hear
it
lock.
Make
sure
it
is

locked
correctly;
refit
the
rubber
cap
A.
IMPORTANT
Only
replace
the
bulb

when
the
engine
is
off.
Also
ensure
that

the
engine
is
cold,
to
prevent
the
risk
of

burns.
LED
main
beam/dipped
beam

headlights

GPH
MJHIUT
For
replacing
these
bulbs,
contact
a

Fiat
Dealership.
Side
lights/daytime
running
lights

(DRL)
The
side
lights/daytime
running
lights
(DRL)
are
LED-type.
To
replace
them,

contact
a
Fiat
Dealership.
Front direction indicators
To replace the bulbs, proceed as
follows:
steer the car wheels completely
inwards;
undo screws A fig. 121 using the
screwdriver provided and remove
inspection flap B;
identify the direction indicator bulb;
119F1B0146C
120F1B0710
121F1B0147
122F1B0253C
155

turn
the
bulb
and
bulb
holder

assembly
anticlockwise
and
then

remove
it
sliding
it
outwards;
replace
the
bayonet-fitted
bulb
A

fig.
122;
finally,
refit
the
inspection
flap
B
fig.
121,
fully
tightening
fixing
screws
A.
Fog
lights
IBMPHFO

To
replace
the
bulbs,
proceed
as

follows:
steer
the
car
wheels
completely

inwards;
undo
screws
A
fig.

121
using
the

screwdriver
provided
and
remove

inspection
flap
B;
identify
the
fog
light;
turn
the
bulb
and
bulb
holder

assembly
anticlockwise
and
then

remove
it
sliding
it
outwards;
disconnect the electrical connector;
replace the bulb-bulb holder
assembly B fig. 122;
reconnect the electrical connector to
the new bulb-bulb holder; then insert it
making sure it is locked correctly;
insert the assembly by turning it
clockwise and locking it correctly;
finally, refit the inspection flap B
fig. 121, fully tightening fixing screws A.Side turn light
IMPORTANT The procedure is
described by way of example only. It is
advisable to contact a Fiat Dealership
for bulb replacement.
To replace the bulb, proceed as follows:
remove the cap B fig. 123 from the
door mirror very carefully (use a suitable
tool to prevent damaging the painted
parts) around the mirror frame (as
shown in the figure);
remove the lens A and then remove
the bulb C pulling it from the respective
bulb holder.
fit the new bulb, making sure it is
correctly locked;
refit the bulb holder on lens A;
refit cap B on the door mirror
correctly, ensuring that it locks correctly.Rear bulb position
1. Tail lights/Brake lights
2. Direction indicator
3. Rear fog light (left light) - Reversing
light (right light)
Tail lights
The tail lights are LED-type. For
replacing these bulbs, contact a Fiat
Dealership.
Brake lights
The brake lights are LED-type. For
replacing these bulbs, contact a Fiat
Dealership.
123F1B0149C
124F1B0696
156
IN AN EMERGENCY

Rear fog lights, reversing light, rear
direction indicators
To replace the bulbs, proceed as
follows:
open the tailgate;
using the tool A fig. 125 provided
(located in the on-board document
pouch), undo the two screws A
fig. 126, then release the light cluster
from the respective pin fasteners pulling
it carefully;
disconnect the connector B, then
undo the two screws C;
release the tabs shown by the arrows
and extract the bulb holder assembly D
fig. 127;
identify the bulb to be replaced
(1 Direction indicator - 2 Rear fog light
or Reversing light);
all bulbs are "bayonet-fitted"; to
replace them, press slightly and turn at
the same time: anticlockwise to extract;
clockwise to insert;
reposition the bulb holder assembly
D correctly in the headlight body;
proceed until you hear the tabs click;
fasten the two screws C fig. 126 and
reconnect the connector B;
refit the lens by screwing the two
screws A completely;
close the tailgate.
3
rdbrake lights
The 3rdbrake lights are LED-based. To
replace them, contact a Fiat Dealership.
Number plate lights
To replace the bulbs, proceed as
follows:
using the screwdriver provided,
remove the lenses A fig. 128 working in
the point shown;
turn the bulb holder B
fig. 129 anticlockwise, extract the bulb
C and replace it.
finally, refit the lenses.
125F1B0022C
126F1B0723
127F1B0724
128F1B0669
157

NOTE Before removing the lens unit,
put a protection (e.g. cloth) on the tip of
the screwdriver, in order not to damage
the lens itself.
WARNING
139)Before replacing the bulb, wait for the
exhaust ducts to cool down: DANGER OF
SCALDING!
140)Modifications or repairs to the electric
system that are not carried out properly or
do not take the system technical
specifications into account can cause
malfunctions leading to the risk of fire.
141)Halogen bulbs contain pressurised
gas, in the case of breakage they may
burst causing glass fragments to be
projected outwards.142)Only replace the light bulbs when the
engine is off and in a position that does not
interfere with traffic and lets you safely
replace them (see the description in the
“Replacement” paragraph). Also ensure
that the engine is cold, to prevent the risk
of burns.
IMPORTANT
72)Halogen bulbs must be handled
holding the metallic part only. Touching the
transparent part of the bulb with your
fingers may reduce the intensity of the
emitted light and even reduce the lifespan
of the bulb. In the event of accidental
contact, wipe the bulb with a cloth
moistened with alcohol and let the bulb dry.
REPLACING FUSES
INTRODUCTION
143) 144) 145) 146)
73) 74)
Fuses protect the electrical system:
they intervene (blow) in the event of a
failure or improper action on the
system.
Fuse extracting pliers
To replace a fuse, use the pliers hooked
to the side of the engine compartment
fuse box cover (see fig. 130 ).
The pliers have two different ends,
specifically designed to remove the
different types of fuses present in the
vehicle.
To take out the pliers, grab them from
the upper tabs, press and pull upwards.
After being used, the pliers should be
positioned properly in their housing,
grabbing them from the upper tabs,
pressing and pushing them until a click
is heard.
129F1B0154C
158
IN AN EMERGENCY
