Page 25 of 64
251-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
NOTICE
■To prevent seat damage
● Before operating the AUTO ACCESS SEAT, make sure that there are no
luggage items or other obstacles around the moving parts of the seat.
The AUTO ACCESS SEAT may be damaged if it hits an obstacle.
● The load capacity of the AUTO ACCESS SEAT is 330 lb. (150 kg).
Do not overload the seat.
■ To prevent battery discharge
Use the AUTO ACCESS SEAT while the engine is running.
If the engine is started while the AUTO ACCESS SEAT is being used, the
AUTO ACCESS SEAT may stop during operation, and the seat will need to
be initialized for re-operation. ( →P. 47)
●Before operating the AUTO ACCESS
SEAT, make sure that the seat belt is
unbuckled and that the seat belt is not
tangled up with the seat.
If the AUTO ACCESS SEAT is operated
while the seat belt is tangled, the AUTO
ACCESS SEAT may be damaged.
Page 26 of 64
261-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
Moving the AUTO ACCESS SEAT outside
the vehicle
Park the vehicle on a flat surfac e and leave the engine running.
Shift the shift lever to P and set the parking brake.
Confirm the following: • The occupant is sitting correctly in the AUTO ACCESS SEAT. (→ P. 14)
• The seat belt is not caught up in the AUTO ACCESS SEAT.
• The occupant of the right-hand third seat is safe.
• The condition of the AUTO ACCESS SEAT ( →P. 2 0 )
Open the right-hand sliding door fully.
Fold the front pas senger seatback. ( →P. 2 1 )
Remove the wireless remote
control from the AUTO
ACCESS SEAT.
Press and hold the seat lower
switch on the wireless remote
control to rotate and lower the
AUTO ACCESS SEAT.
Operation can also be carried out
by the seat raise/lower switch.
( →P. 34)
1
2
3
4
5
6
7
Page 27 of 64
271-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
The beep will sound once,
and the AUTO ACCESS
SEAT will begin to move
automatically.
The indicator light on the wire-
less remote control will flash.
The AUTO ACCESS SEAT
will rotate while the seatback
reclines and while moving
towards the front of the vehi-
cle.
The AUTO ACCESS SEAT
will slide out of the vehicle
and will lower while the seat-
back raises.
Release the switch once the
seat has lowered fully and has
stopped automatically.
Return the wireless remote control to the AUTO ACCESS SEAT.
1
2
3
8
Page 28 of 64
281-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
■Operating conditions
Under the following conditions, the seat will not rotate or lower even if the
seat lower switch is pressed.
●The right-hand sliding door is not opened completely.
● The seat belt is caught up in the AUTO ACCESS SEAT.
● The shift lever is not in P.
■ Wireless remote control
●The AUTO ACCESS SEAT will operate when the seat lower switch has
been pressed and the beep has sounded once.
● The AUTO ACCESS SEAT will stop if the seat lower switch is released
during operation.
■ Jam protection function
If the operation of the AUTO ACCESS SEAT is interrupted by collision with an
obstacle etc., the beep will sound twice and the seat will retreat slightly and
then stop. If this happens, make sure that the hands, feet etc. of the occupant
will not hit the body of the vehicle, and operate the seat once again after
removing the obstacle.
■ Conditions which will halt operation
If another wireless remote control or the seat raise/lower switch are op\
erated
while the AUTO ACCESS SEAT is being operated by wireless remote control,
the AUTO ACCESS SEAT will stop operating.
Page 29 of 64
291-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
WARNING
■Before moving the AUTO ACCE SS SEAT outside the vehicle
● Check that the right-hand third seat occupant is safe.
NOTICE
■To prevent AUTO ACCESS SEAT damage
● Press and hold the wireless remote control switches, instead of pressing
them repeatedly.
● Wait for approximately 1 second before changing to another switch.
● Do not leave the AUTO ACCESS SEAT outside the vehicle.
The seat may deform, freeze or rust, especially if left out in the sun, \
rain or
cold.
●Do not try to close the right-hand sliding
door while operating the AUTO
ACCESS SEAT. Otherwise, the hands
or feet of the occupant may hit the door,
possibly causing injuries.
Page 30 of 64
301-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
Returning the AUTO ACCESS SEAT to the
vehicle
Park the vehicle on a flat surface and leave the engine running.
Shift the shift lever to P and set the parking brake.
Confirm the following: • The right-hand sliding door is fully open.
• The occupant is sitting correctly in the AUTO ACCESS SEAT. (→ P. 14)
• The occupant of the right-hand third seat is safe.
• The condition of the AUTO ACCESS SEAT ( →P. 2 0 )
Fold the front pas senger seatback. ( →P. 2 1 )
Remove the wireless remote control from the AUTO ACCESS
SEAT. ( →P. 26)
Press and hold the seat raise
switch on the wireless remote
control to rotate and raise the
AUTO ACCESS SEAT.
Operation can also be carried out
by pressing the seat raise/lower
switch. ( →P. 34)
1
2
3
4
5
6
Page 31 of 64
311-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
The beep will sound once,
and the AUTO ACCESS
SEAT will begin to move
automatically while the seat-
back reclines.
The indicator light on the wire-
less remote control will flash.
The AUTO ACCESS SEAT
will rotate while the seatback
raises and while moving
towards the rear of the vehi-
cle.
Once the seat has rotated fully,
the beep will sound once and
the seat will stop moving auto-
matically. Release the switch at
this time.
Return the wireless remote control to the AUTO ACCESS SEAT.
(→ P. 26)
Adjust the AUTO ACCESS SEAT as necessary ( →P. 8), and buckle
the seat belt before driving.
Close the right-hand sliding door.
■ Wireless remote control
●When the seat raise switch is pressed, the beep will sound once and the
AUTO ACCESS SEAT will begin to operate. The seat will not operate if the
switch is pressed repeatedly.
● The AUTO ACCESS SEAT will stop operating if the seat raise switch is
released during operation.
1
2
7
8
9
Page 32 of 64
321-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)■
Jam protection function
If the operation of the AUTO ACCESS SEAT is interrupted by collision with an
obstacle etc., the beep will sound twice and the seat will retreat slightly and
then stop. If this happens, make sure that the hands, feet etc. of the occupant
will not hit the body of the vehicle, and operate the seat once again after
removing the obstacle.
■ Conditions which will halt operation
If another wireless remote control or the seat raise/lower switch are op\
erated
while the AUTO ACCESS SEAT is being operated by wireless remote control,
the AUTO ACCESS SEAT will stop operating.
■ If the AUTO ACCESS SEAT h as not been stowed properly
The following operations cannot be carried out.
● Power sliding door function (right-hand sliding door only)
● Shifting
● Adjustment of the seat position and seatback angle of the AUTO ACCESS
SEAT
WARNING
■Before returning the AUTO ACCESS SEAT to the vehicle
● Check that the right-hand third seat occupant is safe.
Their feet etc. may get caught between the AUTO ACCESS SEAT and the
vehicle body, possibly causing an injury.
● Make sure that the right-hand sliding door is fully open. Otherwise, the
hands or feet of the occupant may hit the door when the AUTO ACCESS
SEAT is operated, possibly causing an injury.
