2018 TOYOTA SIENNA Owners Manual (in English)

91-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
WARNING
Observe the following precautions.
Failing to do so may cause death or serious injury in the event of sudden
braking, sudden swerving or an accident.
■Wearing a seat belt
Read and follow the explanations and precautions under the “Seat belts”
headings in Section 1-1 of the “OWNER’S MANUAL”.
■ Child restraint lock func tion belt precaution
Read and follow the explanations and precautions under the “Seat belts”
headings in Section 1-1 of the “OWNER’S MANUAL”.
■ When installing a child restrain t system to the AUTO ACCESS SEAT
Read and follow the explanations and precautions under the “Installing child
restraints” headings in Section 1-1 of the “OWNER’S MANUAL”.
■ Seatback angle adjustment
Do not recline the seat more than necessary when the vehicle is in motion
to reduce the risk of sliding under the lap belt during a collision.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen or your neck may contact the shoul-
der belt.
NOTICE
■To prevent seat damage
Release the switch once the adjustment operation has been completed.
If you continue to press the switch once the operation has been completed,
a fault may occur.

101-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
Head restraint
Up
Pull the head restraint up.
Down
Push the head restraint down while
pressing the lock release button.
■Removing the head restraint
■ Installing the head restraint
Head restraint is provided for the AUTO ACCESS SEAT.
Lock
release
button
1
2
Pull the head restraint up while pressing
the lock release button.
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Lock release button
Lock release button

111-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
■Adjusting the height of the head restraint
Make sure that the head restraint is
adjusted so that the center of the head
restraint is closest to the top of your ears.
WARNING
■ Head restraint precautions
Observe the following precautions regarding the head restraint.
Failure to do so may result in death or serious injury.
● Use the head restraint designed for AUTO ACCESS SEAT.
● Adjust the head restraint to the correct position at all times.
● After adjusting the head restraint, push down on it and make sure it is
locked in position.
● Do not drive with the head restraint removed.

121-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
Armrests
Raise
Lower
■Wearing the seat belt
Wearing the seat belt is easier with the armrest raised.
Lower the armrests as far as they will go when rotating or rais-
ing/lowering the AUTO ACCESS SEAT.
1
2
WARNING
■When wearing the seat belt
Wear the seat belt correctly, passing it
underneath the armrest.
If the seat belt is caught on the armrest, it
may not be fully effective, which could
cause death or serious injury in the event
of a sudden braking, sudden swerving or
an accident.

131-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
Footrest
Raise
Lower
Lower the footrest as far as it will go when rotating or raising/
lowering the AUTO ACCESS SEAT.
1
2
WARNING
■When operati ng the footrest
Operate the footrest by holding the front edge.
You may be injured if your fingers get caught in the rotating parts.

141-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
Correct riding posture
Sit while keeping both knees
aligned and inside the AUTO
ACCESS SEAT.
Lower the armrests and keep
both arms inside the armrests
and inside the AUTO ACCESS
SEAT.
Lower the footrest and place
both feet on the footrest.
If you cannot place your feet on the
footrest, have someone help you,
so as not to get your feet caught
between the AUTO ACCESS
SEAT and the vehicle body.
Maintain the correct posture while sitting in the seat, as follows:
1
2
3

151-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
WARNING
■When sitting in the seat
● When the seat is being used by a person who is unable to bend his/her
knees or neck, or by a person that is unable to sit far back in the seat, be
careful as their head, feet etc. may hit the vehicle body, and rotation of the
AUTO ACCESS SEAT may become difficult while the seat is occupied.
● Do not stand on the footrest.
Doing so may damage the footrest or cause you to fall from the footrest,
which may cause an injury.
■ When operating
When operating the AUTO ACCESS
SEAT, make sure that the occupant’s
head, arms and legs do not hit the door
opening.
Collision between door opening and
head
Caught between door opening and
AUTO ACCESS SEAT
Collision between door opening and
legs
1
2
3

161-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
Wireless remote control
Indicator light
Seat raise switch
Seat lower switch
Approximately 3.3 ft. (1 m) from
the AUTO ACCESS SEAT
The wireless remote control can be used to rotate and raise or
lower the AUTO ACCESS SEAT.
1
2
3
Effective range
