Page 17 of 64
171-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
■Operating conditions
●The effective range of the wireless remote control changes in accordance
with surroundings.
● Interference from other radio wave s may cause the AUTO ACCESS SEAT
to stop moving temporarily even when pressing the wireless remote control
switches. In this event, do the following:
• Stand in a different place and press the switch. Press the switch once again after moving. The AUTO ACCESS SEAT will
not operate if you hold the switch down while changing position.
• Operate the seat raise/lower switch (→P. 34)
■ Battery
●The lifespan of the battery is about 6 months, but this may change in accor-
dance with usage.
● If the battery is discharged, the AUTO ACCESS SEAT may not operate
even if the wireless remote control is operated or the indicator light will stop
flashing. In these events, replace the battery with a new one. ( →P. 40)
■ When riding in an aircraft
When bringing a wireless remote control onto an aircraft, make sure you do\
not press any buttons on the wireless remote control while inside the aircraft
cabin. If you are carrying the wireless remote control in your bag etc., ensure
that the buttons are not likely to be pressed accidentally. Pressing a button
may cause the wireless remote control to emit radio waves that could inter-
fere with the operation of the aircraft.
Page 18 of 64
181-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)■
Conditions affecting operation
If you use the wireless remote control to operate the AUTO ACCESS SEAT at
the same time as doing any of the following, the AUTO ACCESS SEAT may
not operate properly:
●Operating the AUTO ACCESS SEAT using another wireless remote control
● Operating the AUTO ACCESS SEAT using the seat raise/lower switch
● Using the smart key system
● Unlocking and locking the doors using the wireless remote control
■ When replacing either the transmitter or the receiver of the wireless
remote control
It is necessary to replace both the transmitter and the receiver. Contact your
Toyota dealer.
■ Certification for the wi reless remote control
U.S.A.
FCC ID: HYQ12BDF
FCC ID: HYQ13BDH
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Canada
NOTE:
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.
Page 19 of 64
191-1. AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
WARNING
■Wireless remote control precautions
Observe the following precautions to reduce the risk of injury.
● Operate the AUTO ACCESS SEAT from a position from which you can
see the occupant of the seat.
● Make sure that the occupant’s head, arms and legs will not get caught
between the seat and the body of the vehicle.
● Steady the AUTO ACCESS SEAT and the occupant with your hand while
operating.
NOTICE
■To prevent wireless remote control damage
● Observe the following:
• Do not expose the wireless remote control to high temperatures by
placing it in direct sunlight.
• Do not disassemble the wireless remote control.
• Do not drop the wireless remote control, subject it to strong shocks or bend it.
• Do not get the wireless remote control wet.
● Do not wipe the wireless remote control with thinner, gasoline or benzene.
The surface of it may be damaged.
When cleaning the wireless remote control, wipe it using a wrung cloth
soaked in water or lukewarm water.
● Do not attach metallic or magnetic materials to the wireless remote control
or place the wireless remote control close to such materials.
● Do not attach metallic window tinting or other metallic objects such as non-
genuine antenna to the windows.
● Do not attach accessories to the wireless remote control. These could get
caught in the AUTO ACCESS SEAT during operation.
Page 20 of 64
201-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
Before operating the AUTO ACCESS SEAT
Park the vehicle on a flat surface and leave the engine running.
Shift the shift lever to P and set
the parking brake.
Check that there are no people or items of luggage around the
AUTO ACCESS SEAT, and that there are no people around the
vehicle.
Open the right-hand sliding door fully.
The AUTO ACCESS SEAT (right-hand second seat) can be
rotated, raised and lowered electrically to help the seat occupant
easily enter and exit the vehicle.
Have all operations carried out by an assistant.
1
2
3
4
Page 21 of 64
211-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
Manual seat
Fold the front passenger seat-
back while pulling the seatback
angle adjustment lever.
Power seat
Fold the front passenger seat-
back by moving the seatback
angle adjustment switch for-
ward.
Unfasten the seat belt on the AUTO ACCESS SEAT.
Adjust the armrest and foot
restraint on the AUTO ACCESS
SEAT to the downmost posi-
tion.
5
5
6
7
Page 22 of 64
221-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
■Beep sounds
The beep makes the following sounds in response to operating procedures
and conditions.
BeepOperation/Condition
Once
(normal
operation)
When the wireless remote control switches or the seat
raise/lower switch is pressed and the AUTO ACCESS
SEAT operates.
When the seat raise switch is pressed and the AUTO
ACCESS SEAT has finished stowing.
Tw i c e
(malfunction)
When the seat lower switch is pressed while the right-hand
sliding door is closed.
When the seat lower switch is pressed while the seat belt
of the AUTO ACCESS SEAT is still buckled.
When the right-hand sliding door is shut before the AUTO
ACCESS SEAT has been properly stowed.
If the AUTO ACCESS SEAT hits an obstacle while rotating,
or operation is otherwise obstructed.
ContinuouslyWhen the AUTO ACCESS SEAT is operated while the shift
lever is not in P.
WARNING
■ Before operating the AUTO ACCESS SEAT
When the seat is being used by a person who is unable to bend his/her
knees or neck, or by a person that is unable to sit far back in the seat, be
careful as their head, feet etc. may hit the vehicle body, and rotation of the
AUTO ACCESS SEAT may become difficult while the seat is occupied.
Page 23 of 64
231-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
1
AUTO ACCESS SEAT
WARNING
■When operating the AUTO ACCESS SEAT
● Check the surroundings for safety, making sure that there are no pedestri-
ans, bicycles, etc.
Failure to do so may result in an accident.
● Do not allow children to play in or operate the AUTO ACCESS SEAT, as it
may be damaged.
●Do not operate while parked on an
incline or on uneven ground. The occu-
pant may fall from the seat or from their
wheelchair, or you may be hit by the
wheelchair while putting it away, possi-
bly causing an injury.
Park the vehicle on a flat surface.
Shift the shift lever to P.
Set the parking brake securely.
● Operate the AUTO ACCESS SEAT
while being careful of the occupant’s
head, feet and hands.
Injury may result if they hit the vehicle
body.
1
2
3
Page 24 of 64
241-2. Operating the AUTO ACCESS SEAT
SIENNA_AAS_OM08023U_(U)
WARNING
■When operating the AUTO ACCESS SEAT
● Make sure that the seat belt is unbuckled.
There is a risk that the occupant of the AUTO ACCESS SEAT could be
injured.
● Do not stand on the footrest.
Doing so may damage the footrest, or cause the occupant to fall from the
footrest, possibly causing injury.
● Make sure to use the armrests and that they are lowered as far as possi-
ble.
If the armrests are not used, the occupants may lose stability and could fall
from the seat, possibly causing an injury.
●Do not place luggage or hands and feet
underneath or around the AUTO
ACCESS SEAT.
Hands and feet could get caught, possi-
bly resulting in an injury.
