2018 Abarth 500 Owner handbook (in English)

DIMENSIONS
Dimensions are expressed in mm and refer to the vehicle equipped with its standard-supplied tyres. Height is measured with
vehicle unladen.
LUGGAGE COMPARTMENT VOLUMEUnladen capacity (V.D.A. standards) = 185 dm
3
AB C D EFG I
3660 770 2300 590 1490
1415/1409(*)1627
1408/1402(*)
(*) With 205/40 R17 tyres
116AB0A0292C
135

WEIGHTS
(For markets where provided)
Weights (kg)
595 – 135 HP 595C – 135 HP 595 – 145 HP 595C – 145 HP
Unladen weight (with all fluids, fuel tank filled to 90% and
without optional equipment)1035 10751035(*)
/1045(**)1075(*)
/1085(**)
Payload including the driver 390 355
390(*) /380(**)355(*) /345(**)
Maximum permitted loads(***)
– front axle 830 830 830 830
– rear axle 640 640 640 640
– total 1425 1430 1425 1430
Towable loads
– braked trailer––––
– trailer without brakes––––
Maximum load on roof 50 – 50 –
Maximum load on tow hitch (trailer with brakes)––––
(*) Version with manual transmission
(**) Version with robotised sequential transmission
(***) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permitted loads.
136
TECHNICAL DATA

Weights (kg)
595 – 160 HP 595C – 160 HP595/695 –
163 HP595C/695C –
163 HP
Unladen weight (with all fluids, fuel tank filled to 90% and
without optional equipment)1035(*)
/1045(**)1075(*)
/1085(**)1035(*)
/1045(**)1075(*)
/1085(**)
Payload including the driver
390(*) /380(**)355(*) /345(**)390
365(*) /355(**)
Maximum permitted loads(***)
– front axle 830 830 830 830
– rear axle 640 640 640 640
– total 1425 14301425
(*)
/1435(**)1440
Towable loads
– braked trailer––––
– trailer without brakes––––
Maximum load on roof 50 – 50 –
Maximum load on tow hitch (trailer with brakes)––––
(*) Version with manual transmission
(**) Version with robotised sequential transmission
(***) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permitted loads.
137

Weights (kg)
595/695 –
165 HP595C/695C –
165 HP595/695 –
180 HP595C/695C –
180 HP
Unladen weight (with all fluids, fuel tank filled to 90% and
without optional equipment)1035(*)
/1045(**)1075(*)
/1085(**)1045(*)
/1055(**)1090
Payload including the driver 390
365
(*) /355(**)380 350
Maximum permitted loads
(***)
– front axle 830 830 830 830
– rear axle 640 640 640 640
– total1425
(*)
/1435(**)14401425(*)
/1435(**)1440
Towable loads
– braked trailer––––
– trailer without brakes––––
Maximum load on roof 50 – 50 –
Maximum load on tow hitch (trailer with brakes)––––
(*) Version with manual transmission
(**) Version with robotised sequential transmission
(***) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permitted loads.
138
TECHNICAL DATA

REFUELLING
Version 1.4 TB PETROL ABARTH
Recommended fuels and original
lubricants
Fuel tank (litres) 35
Unleaded petrol with R.O.N. no lower than 95
(EN228 specifications)
Fuel tank reserve (litres) 5
Engine cooling system (litres) 5.15Mixture of distilled water and 50%
PARAFLU
UPliquid (*)
Engine sump (litres) 2.75
SELENIA ABARTH 10W50
Engine sump and filter (litres) 2.90
Transmission/differential casing (litres) 1.55TUTELA TRANSMISSION GEARFORCE
Hydraulic brake circuit (kg) 0.55TUTELA TOP 4
orTOP 4/S
Windscreen and rear window washer fluid
reservoir (litres)2.5Mixture of water andPETRONAS
DURANCE SC35
(*) When the vehicle is used in particularly harsh weather conditions, we recommend using a mixture of 60% PARAFLUUPand 40% demineralised water.
139

FLUIDS AND LUBRICANTS
Your car is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of the
Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission
specifications. Lubricant quality is crucial for engine operation and duration.
If lubricants conforming to the specific request are not available, products that meet the indicated specifications can be used to
top up; in this case optimal performance of the engine is not guaranteed.
50)
PRODUCT SPECIFICATIONS
Use Features SpecificationOriginal fluids and
lubricantsApplications
Fully synthetic
lubricant for ultra
high performance
enginesSAE 10W–50 ACEA C39.55535-GH2SELENIA ABARTH
10W50
Contractual Technical
Reference No. 0101According to Scheduled
Servicing Plan
Lubricants and
greases for drive
transmissionSAE 75W grade synthetic
lubricant9.55550-MZ6TUTELA
TRANSMISSION
GEARFORCE
Contractual Technical
Reference N° F002.F10Manual gearbox and
differential
Fully synthetic lubricant
with dedicated additive.9.55550-SA1TUTELA CS SPEED
Contractual Technical
Reference N° F005.F98Robotised sequential
transmission hydraulic
activation system
Molybdenum disulphide
grease, for use at high
operating temperatures.
N.L.G.I. consistency 1-2.9.55580-GRAS IITUTELA ALL STAR
Contractual Technical
Reference N° F702.G07Wheel side constant
velocity joints
Grease for constant
velocity joints with low
friction coefficient. N.L.G.I.
consistency 0-1.9.55580-GRAS IITUTELA STAR 700
Contractual Technical
Reference N° F701.C07Differential-side constant
velocity joints
140
TECHNICAL DATA

Use Features SpecificationOriginal fluids and
lubricantsApplications
Brake fluidSynthetic fluid for brake
and clutch systems.
Exceeds specifications
F.M.V.S.S. no. 116 DOT 4,
ISO 4925 SAE J1704.9.55597 or MS.90039TUTELA TOP 4
Contractual Technical
Reference N° F001.A93
or
TUTELA TOP 4/S
Contractual Technical
Reference N° F005.F15Hydraulic brakes and
hydraulic clutch controls
Protective agent for
radiatorsRed protective with
antifreeze action, based on
inhibited monoethyl glycol
with organic formula.
Exceeds CUNA NC 956-
16, ASTM D 3306
specifications.9.55523 or MS.90032PARAFLU
UP
Contractual Technical
Reference N° F101.M01Cooling circuits proportions
of use: 50% water 50%
PARAFLUUP(*)
Windscreen/rear
window washer fluidMixture of alcohol and
surfactants Exceeds the
CUNA NC 956-11
specifications.9.55522 or MS.90043PETRONAS DURANCE
SC35
Contractual Technical
Reference N° F201.D02To be used diluted or
undiluted in windscreen
washer/wiper systems
(*) When the vehicle is used in particularly harsh weather conditions, we recommend using a mixture of 60% PARAFLUUPand 40% demineralised water.
WARNING
50)The use of products with different specifications than those indicated below could cause damage to the engine not covered by the
warranty.
141

PERFORMANCE
Version Acceleration from 0–100 km/h (s) Maximum speed (km/h)
1.4 TB PETROL ABARTH 135 HP(*)7.9 205
1.4 TB PETROL ABARTH 145 HP
7.8
(**)/8(***)210
1.4 TB PETROL ABARTH 160 HP
7.3
(**)/7.4(***)216
1.4 TB PETROL ABARTH 163 HP
(*) (****)7.3(**)/7.4(***)218
1.4 TB PETROL ABARTH 165 HP
(****)7.3(**)/7.4(***)218
1.4 TB PETROL ABARTH 180 HP
(****)6.7(**)/6.9(***)225
(*) For markets, where provided
(**) Version with manual transmission
(***) Version with robotised sequential transmission
(****) Results obtained using 98 RON unleaded petrol
142
