Introduction
EAU10103
Welcome to the Yamaha world of motorcycling!
As the owner of the YZF-R1/YZF-R1M, you are benefiting from Yamaha’s vast experience and newest technology regarding
the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your YZF-R1/YZF-R1M. The Owner’s
Manual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard
yourself and others from trouble and injury.
In addition, the many tips given in this manual will help keep your motorcycle in the best possible condition. If you have any
further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first!
Yamaha continually seeks advancements in pr oduct design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your motorcycle and this
manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA10032
Please read this manual carefully and completely before operating this motorcycle.
BX4-9-E0.book 1 ページ ２０１６年１２月１日 木曜日 午後８時７分
Page 6 of 130
Important manual information
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
A WARNING indicates a hazardous situation wh
ich, if not avoided, could result in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid damage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICETIP
BX4-9-E0.book 1 ページ ２０１６年１２月１日 木曜日 午後８時７分
Page 7 of 130
Important manual information
EAU10201
YZF-R1/YZF-R1M
OWNER’S MANUAL
©2016 by Yamaha Motor Co., Ltd. 1st edition, November 2016 All rights reserved.
Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd.
is expressly prohibited. Printed in Japan.
BX4-9-E0.book 2 ページ ２０１６年１２月１日 木曜日 午後８時７分
Page 8 of 130
Table of contentsSafety information........................... 1-1
Description ....................................... 2-1
Left view ......................................... 2-1
Right view ....................................... 2-2
Controls and instruments................ 2-3
Special features ............................... 3-1
YRC (Yamaha Ride Control) .......... 3-1
Glossary ......................................... 3-3
YRC functions visual guide............. 3-4
Instrument and co ntrol functions... 4-1
Immobilizer system ..... .................... 4-1
Main switch/steering lock................ 4-2
Handlebar switches ........................ 4-3
Indicator lights and warning lights ............................................ 4-6
Display ............................................ 4-9
MENU screen ............................... 4-15
Clutch lever................................... 4-30
Shift pedal..... ............................ .... 4-30
Brake lever ................................... 4-31
Brake pedal .................................. 4-31
Brake system ..... ....................... .... 4-32
Fuel tank cap ................................ 4-33
Fuel............................................... 4-34
Fuel tank breather hose and overflow hose ............................ 4-36
Catalytic converter ........................ 4-36
Seats ............................................ 4-37 CCU (for equipped models) ......... 4-38
Document storage ........................ 4-39
Rear view mirrors ......................... 4-40
Adjusting the front fork ................. 4-40
Adjusting the shock absorber
assembly................................... 4-42
EXUP system ............................... 4-46
Auxiliary DC connector................. 4-46
Sidestand ..................................... 4-47
Ignition circuit cut- off system ........ 4-47
For your safety – pre-operation
checks .............................................. 5-1
Operation and important riding
points ................................................ 6-1
Starting the engine ......................... 6-1
Shifting ........................................... 6-2
Tips for reducing fuel consumption ............................... 6-3
Engine break-in .............................. 6-3
Parking ........................................... 6-4
Periodic maintenance and
adjustment ....................................... 7-1
Owner’s tool kit............................... 7-2
Periodic maintenance chart for the emission control system ............. 7-3
General maintenance and lubrication chart .......................... 7-5 Removing and installing cowlings
and panels .................................. 7-9
Checking the spark plugs ............ 7-12
Canister ....................................... 7-13
Engine oil and oil filt er cartridge... 7-13
Coolant ........................................ 7-16
Air filter element ........................... 7-18
Checking the engine idling speed............ ............................ 7-19
Checking the throttle grip free play ........................................... 7-19
Valve clearance ........................... 7-19
Tires ............................................. 7-20
Cast magnesium wheels.............. 7-22
Adjusting the clutch lever free play ........................................... 7-23
Checking the brake lever free
play ........................................... 7-24
Brake light switches ..................... 7-24
Checking the front and rear
brake pads................................ 7-25
Checking the brake fluid level ...... 7-25
Changing the brake fluid .............. 7-26
Drive chain slack.......................... 7-27
Cleaning and lubricating the
drive chain ................................ 7-28
Checking and lubricating the cables ....................................... 7-29
Checking and lubricating the throttle grip and cable ............... 7-29BX4-9-E0.book 1 ページ ２０１６年１２月１日 木曜日 午後８時７分
