2017 VOLKSWAGEN CC key

WARNING
The engine compartment of any motor vehicle is a potentially
dangerous area and can cause serious personal injury.
Always use extreme caution when doing any work in the en-
gine compartment. Always follow commonly accepted safety
practices and use common sense. Never risk personal injury.
Never perform any work in the engine compartment unless
you know exactly how to carry out the job and have the correct
technical information and the correct tools.
If you are uncertain about what to do, have the work per-
formed by an authorized Volkswagen dealer, an authorized
Volkswagen Service Facility, or another qualified workshop.
Serious personal injury may result from improperly performed
work.
We strongly recommend that you always have HID – High In-
tensity Discharge (Xenon) headlights and H7 bulbs replaced by
a qualified technician. Serious personal injury may result from
improperly performed work.
Never open or close the engine hood if steam or coolant is
escaping. Hot steam or coolant can cause serious burns. Al-
ways wait until you no longer see or hear steam or coolant es-
caping from the engine.
Always let the engine cool down completely before carefully
opening the hood.
Hot parts of the engine and the exhaust system will burn skin
on contact.
When the engine has cooled down and you are ready to open
the hood:
– Firmly apply the parking brake and shift the transmission
into Park (P) (automatic) or Neutral (manual only).
– Take the vehicle key out of the ignition.
– On vehicles with Keyless Access, make sure that the re-
mote control vehicle key is out of range of the vehicle and
that the vehicle cannot be started by depressing the starter
button ⇒  Starter button.
– Always keep children and others away from the engine
compartment and never leave them unsupervised.

WARNING
Moving parts in the engine compartment can cause serious
personal injury on contact.
Never reach into the area around or touch the radiator fan.
Contact with the blades can cause serious personal injury. Al-
ways remember that the radiator fan is temperature-controlled
and can come on suddenly even when the engine has been
switched off for a while and the key has been removed from the
ignition.
If you have to perform a check or repair when the engine is
running, there are more risks from the rotating parts, such as
the drive belts, alternator, radiator fan, etc., and from the high-
voltage ignition system. Always use extreme care.
– Always make sure that jewelry, loose clothing and long hair
do not get caught in rotating engine parts. Before starting
any work remove your jewelry, take off your necktie, tie back
and cover your hair, and do not wear clothing that can hang
down and get caught in moving engine parts.
– Always use extreme caution if the accelerator pedal has to
be depressed to perform a check. The vehicle will start to
move even if the electronic parking brake is on.
Never leave any objects in the engine compartment, for ex-
ample cleaning rags and tools. Objects left behind can cause
malfunctions, engine damage, and even fires.

d Shift the transmission into Park (P) (automatic) or Neutral (manual
only) ⇒  Shifting.
d Stop the engine and remove the key from the ignition switch ⇒ 
Starting and stopping the engine.
d Let the engine cool down sufficiently.
d Keep children and others away from the vehicle.
d Make sure the vehicle cannot move unexpectedly.
WARNING
Disregarding the safety-related checklist may result in serious
injuries.
Always review and follow the checklist. Follow accepted safe-
ty practices and use common sense.
Opening or closing the engine compartment

Fig. 163 In the footwell on the driver side: Inside engine hood release
lever.

WARNING
Hot steam and hot engine coolant can cause serious burns.
Never open the hood if you see steam or coolant escaping
from the engine compartment. Always wait until you no longer
see or hear steam or coolant escaping from the engine.
Always let the engine cool down completely before carefully
opening the hood. Hot components will burn skin on contact.
When the engine has cooled down and you are ready to open
the hood:
– Apply the electronic parking brake and shift the transmis-
sion into Park (P) (automatic) or Neutral (manual only).
– Take the vehicle key out of the ignition.
– On vehicles with Keyless Access, make sure that the re-
mote control vehicle key is out of range of the vehicle and
that the vehicle cannot be started by depressing the starter
button
– Always keep children and others away from the engine
compartment and never leave them unsupervised.
The engine coolant system is under pressure when the en-
gine is hot. Never unscrew the coolant expansion tank cap
when the engine is hot. Hot coolant can spray out and cause
severe burns and other serious injuries.
– Turn the cap slowly and very carefully in a counterclock-
wise direction while applying light downward pressure on the
top of the cap.
– Always protect your face, hands, and arms from hot escap-
ing coolant or steam by covering the cap with a large, thick
rag.
Never spill fluids on the engine or exhaust system when re-
filling. Spilling fluids onto hot parts of the engine or exhaust
system can cause a fire. Under some conditions, the ethylene
glycol in engine coolant can catch fire.
NOTICE
Use distilled water only when adding coolant! All other types
of water contain chemical compounds that can cause extensive
corrosion damage to the engine. This can even lead to engine

Only use maintenance-free vehicle batteries meeting standards
TL 825 06 and VW 7 50 73. These standards must date from Au-
gust 2008 or later.
Disconnecting the vehicle battery
If the battery must be disconnected from the vehicle's electrical sys-
tem, note the following:
Switch off all electrical systems and devices and the ignition.
Unlock the vehicle before disconnecting the battery; otherwise the
alarm system will go off.
First disconnect the negative cable (-) and then the positive cable
(+) ⇒ .
Connecting the vehicle battery
Prior to reconnecting the battery, switch off all electrical systems
and devices and the ignition.
Connect the positive cable (+) first and then the negative cable (-)
⇒ .
After the battery is connected and the ignition is switched on, different
indicator lights may come on. They should go out after you drive a
short distance at 10–12 mph (15–20 km/h). If the indicator lights do
not go out, contact an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility and have the vehicle checked.
If the battery was disconnected for a long time, the next scheduled
service may not be correctly calculated and displayed ⇒ page 12,
Instrument cluster. The maximum permissible service and mainte-
nance intervals are shown in the ⇒ Booklet Warranty and Mainte-
nance.
Vehicles with Keyless Access
If the ignition will not start after reconnecting the vehicle battery, lock
the vehicle from the outside and unlock it again ⇒  Unlocking or lock-
ing the vehicle with Keyless Access, ⇒  Unlocking or locking the vehi-
cle with Keyless Access. Then try to start the ignition again. If the
ignition cannot be switched on, contact an authorized Volkswagen
dealer, an authorized Volkswagen Service Facility, or another quali-
fied workshop for assistance.

Declaration of Compliance, Telecommunications and Electronic
Systems
Radio Frequency Devices and Radiocommunication Equipment User
Manual Notice.
Radio-based equipment
Mobile Phone Package
Electronic immobilizer
HomeLink® Universal Transmitter
Remote control vehicle key
Tire Pressure Monitoring System
Keyless Access locking and starting system
Park Distance Control (PDC) system
These devices comply with:
FCC Part 15.19
These devices comply with Part 15 of the FCC Rules. Operation is
subject to the following 2 conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including inter-
ference that may cause undesired operation.
FCC Part 15.21
CAUTION:
Changes or modifications not expressly approved by the party re-
sponsible for compliance could void the user's authority to operate
the equipment.
These devices comply with RSS-210 of Industry Canada.
Operation is subject to the following 2 conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference, including interference
that may cause undesired operation of the device.
The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment.

Practical tips
Frequently asked questions (FAQ)
If you suspect a malfunction or vehicle damage, read and follow the
following advice before contacting an authorized Volkswagen dealer
or an authorized Volkswagen Service Facility. You may also find help-
ful information under “Special considerations” or “Checklist” in the
index.

Description Possible causes,
among others Possible remedy
Engine does not
start.
Vehicle battery dead. – Perform jump-start
– Charge vehicle battery
The wrong vehicle
key is used. Use a valid vehicle key
Fuel level too low. Refuel
Vehicle cannot be
locked or un-
locked using ve-
hicle key.
– Battery in the re-
mote control vehicle
key is dead.
– Too far away from
the vehicle (out of
range).
– Buttons have been
pressed too many
times.
– Replace the battery in
the remote control vehicle
key
– Move closer to vehicle.
– Synchronize vehicle key
– Lock or unlock vehicle
manually
Unusual noises.
Cold engine, braking
assist systems, elec-
tronic steering col-
umn lock.
Check the “Noises” entry
in the index.
Odd driving
behavior.
Assistance systems
activated.
Check the “Assistance
systems” entry in the in-
dex.

WARNING
Serious injuries can result if the emergency closing and open-
ing procedures are used carelessly.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
with the remote control vehicle key. This could result in people
being trapped in the vehicle in an emergency.
A closed vehicle can become very hot or very cold, depend-
ing on the season. Particularly in the summer, heat buildup in
the passenger and luggage compartment of a parked vehicle
can result in temperatures in the vehicle that are much higher
than the outside temperatures. Temperatures can quickly reach
levels that can cause unconsciousness and death, particularly
to small children.
WARNING
Careless opening and closing of the doors, the luggage com-
partment lid, and the power sunroof is dangerous and can
cause serious personal injury.
Open or close the doors, the luggage compartment lid, and
the power sunroof only when no one is in the way.
NOTICE
If the vehicle's battery fails or the power windows won't work,
the door windows are not lowered when the door is opened or
closed. Always close and open the door carefully to help prevent
damage to the window, the paint, or the rubber seal.
NOTICE
To help prevent vehicle damage, carefully remove and properly
reinstall parts after emergency locking or unlocking.
