2017 VOLKSWAGEN CC key

WARNING
Accidents and severe personal injuries can result if you unlock,
open, or close the luggage compartment lid when someone is
in the way.
Only open or close the luggage compartment lid if no one is
in the way.
After closing the luggage compartment lid, always make sure
that it is properly closed and locked so that it cannot open sud-
denly when the vehicle is moving. The closed luggage com-
partment lid must be flush with the surrounding auto body
parts.
Always keep the luggage compartment lid closed while driv-
ing to help keep poisonous exhaust gas from being drawn into
the vehicle.
Never open the luggage compartment lid when a luggage
rack is installed and loaded. If, for example, there are bicycles
on a carrier on the luggage compartment lid, it is possible that
the lid will not be able to open automatically. An open luggage
compartment lid may fall on its own because of the additional
weight. If necessary, prop open the luggage compartment lid.
Remove the weight from the luggage rack first.
Close and lock the luggage compartment lid and all doors
when the vehicle is not in use. First, make sure that no one is
left inside the vehicle.
Never leave your vehicle unattended or let children play
around your vehicle, especially when the luggage compartment
lid is open. A child could crawl into the vehicle and pull the
luggage compartment lid shut, becoming trapped and unable to
get out. A closed vehicle can become very hot or very cold, de-
pending on the season. Particularly in the summer, heat
buildup in the passenger and luggage compartment of a parked
vehicle can result in temperatures in the vehicle that are much
higher than the outside temperatures. Temperatures can quick-
ly reach levels that can cause unconsciousness and death, par-
ticularly to small children.
Never leave children or anyone who cannot help themselves
behind in the vehicle. They may lock the vehicle with the vehi-
cle key or the power locking button and lock themselves in.

WARNING
If the luggage compartment lid is not closed properly, it may
open suddenly when the vehicle is moving and cause severe
injuries.
Stop immediately and close the luggage compartment lid.
Always make sure the luggage compartment lid is securely
latched after you close it.
Opening the luggage compartment lid

Fig. 33 A: In the remote control vehicle key: Button to unlock and
open the luggage compartment lid. B: In the driver door: Switch to
unlock and open the luggage compartment lid.

Fig. 34 Opening luggage compartment lid from the outside.

Unlocking and opening with the vehicle key
Press and hold the q button on the remote control vehicle key
⇒ fig. 33 A to unlatch and automatically open the luggage compart-
ment lid.
Unlocking and opening with the unlock switch in the driver door
Pull up the q switch on the driver door ⇒ fig. 33 B until the luggage
compartment lid opens automatically.
The switch in the driver door also works when the ignition is switched
off.
Unlocking and opening with the sensor-controlled luggage
compartment lid opener (Easy Open)
If your vehicle has Keyless Access, it may also be equipped with the
Easy Open feature. With Easy Open, the luggage compartment lid
can be opened with a motion sensor in the area below the rear
bumper ⇒ Sensor-controlled luggage compartment lid opener (Easy
Open).
Opening with the Volkswagen emblem
Unlock the vehicle or the luggage compartment lid, or open a door.
Using your thumb, press the top of the Volkswagen emblem
⇒ fig. 34 and move the top of the emblem down. The luggage com-
partment lid opens automatically.
WARNING
Improper or unsupervised unlocking or opening of the luggage
compartment lid can cause severe injuries. Never open the lug-
gage compartment lid when someone is in the way.
If a bicycle or luggage rack is installed on the luggage com-
partment lid, it may be hard to see that the luggage compart-
ment lid is unlatched. An unlatched luggage compartment lid
may open suddenly when the vehicle is moving.
At temperatures below +32 °F (0 °C), the luggage compartment
lid may not open automatically after you unlock it. It will be necessary
to lift it by hand.

The luggage compartment lid can also be locked manually with the
emergency key via the key switch in the driver door ⇒ Driver door
overview. When the luggage compartment lid has been locked manu-
ally with the emergency key, it cannot be opened using the q button
on the remote control vehicle key or the q switch inside the driver
door.
WARNING
Improper or unsupervised closing of the luggage compartment
lid can cause severe injuries. Never close the luggage com-
partment lid when someone is in the way.
Never leave your vehicle unattended or let children play
around your vehicle, especially with the luggage compartment
lid left open. A child could crawl into the vehicle and pull the
luggage compartment lid shut, becoming trapped and unable to
get out. A closed vehicle can become very hot or very cold de-
pending on the season. Temperatures can quickly reach levels
that can cause unconsciousness or death, particularly to small
children.
Make sure that the remote control vehicle key is not in the lug-
gage compartment before closing the luggage compartment lid.
Sensor-controlled luggage compartment lid opener (Easy Open)

Fig. 38 Keyless Access locking and starting system: Opening the
sensor-controlled luggage compartment lid (Easy Open), if equipped.

WARNING
Careless use of the Easy Open feature can cause falls and seri-
ous personal injury.
Always make sure you have firm footing when using the Easy
Open feature, and that the surface you are standing on is not
uneven or slippery.
Never use Easy Open feature unless you can use it safely.
CAUTION
If a valid vehicle key is within range of the luggage compart-
ment lid, the Easy Open feature can deploy unintentionally in
some cases and open the luggage compartment lid: for exam-
ple, when sweeping the ground or floor below the rear bumper,
if there is a strong stream of water or steam, or when carrying
out maintenance or repairs around the rear bumper. If the lug-
gage compartment lid opens unintentionally, it can injure any-
one or damage anything in its way.
Never leave a valid vehicle key within range of the luggage
compartment lid unattended.
Always turn off the Easy Open feature through the
Volkswagen Information System ⇒  Volkswagen Information
System in the following situations:
– Before carrying out any maintenance or repairs on the ve-
hicle.
– Before washing the vehicle.
– Before mounting a bicycle rack or connecting a trailer hitch
to the vehicle.

For one-touch closing: Pull the switch for the window up briefly as
far as it goes.
Stopping automatic movement: Pull/press the switch again.
Reactivating the one-touch feature
If the vehicle battery is disconnected or dead and the windows are not
completely closed, the one-touch feature will not work and must be
reactivated:
Switch on the ignition.
Close all windows and doors.
Pull up the switch for the respective window and hold it for at least
2 seconds in this position.
Release the switch, pull up and hold again. The one-touch feature
is now reactivated.
The one-touch feature can be reactivated for one or more windows at
the same time.
Convenience closing
The convenience closing feature lets you close the windows and the
power sunroof as follows:
On vehicles with Keyless Access, using the door handle sensors ⇒ 
Power locking and closing system.
From inside the vehicle, pull up and hold the switch for the driver
window until all windows and the sunroof are closed ⇒ Power locking
and closing system.
Convenience closing first closes the windows and then the power
sunroof. All turn signals blink once to confirm that the windows and
power sunroof are closed.

WARNING
Improper use of power windows can result in serious personal
injury.
Never let anyone get in the way of a power window when
closing it.
When locking the vehicle from the outside, make sure that no
one, especially children, remains in the vehicle. The windows
will not open in case of an emergency.
Always take the key with you when you leave the vehicle. You
can still use the power windows for several minutes after the
ignition is switched off as long as the driver or front passenger
door has not been opened.
Always use the safety switch when children are in the back
seat to disable the rear power windows and keep them from be-
ing opened and closed.
NOTICE
The windows must go down slightly when you unlock the vehi-
cle. Otherwise the windows and seals could be damaged when
opening the doors.
If the power windows malfunction, the one-touch feature, as well
as pinch protection may not work properly. See an authorized
Volkswagen dealer or authorized Volkswagen Service Facility right
away.
Power window pinch protection

resistance or there is something in the way, the power sunroof opens
again immediately.
Check why the power sunroof did not close.
Try to close the power sunroof again by pulling the h switch brief-
ly.
If the power sunroof still cannot close, the power sunroof will stop
where the resistance is located. The power sunroof will close the next
time without pinch protection.
Closing the power sunroof without pinch protection
Within 5 seconds after the pinch protection was triggered, pull the
switch ⇒ fig. 40 until the power sunroof closes completely.
The power sunroof will now close without pinch protection!
If the power sunroof still will not close, please see an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility.
WARNING
Careless or unsupervised use of the sunroof can cause serious
injuries.
Always make sure that no one is in the way of the power sun-
roof when it is closing.
Always take all vehicle keys with you when leaving the vehi-
cle.
Never leave children or persons requiring assistance unat-
tended in the vehicle, especially if they have access to the ve-
hicle key. Unsupervised use of the remote control vehicle key
can lock the vehicle, start the engine, switch on the ignition and
operate the sunroof.
The sunroof can still be opened or closed for a short period
after the ignition has been switched off, as long as the driver or
passenger door is not opened.
