2017 VOLKSWAGEN CC key

Symbol When the ignition is
switched off
When the ignition is
switched on
/ Fog lights and low beams
switched off.
Headlights off, daytime run-
ning lights (DRL) on.
!54/ Orientation lighting may be
switched on.
Automatic headlight control
active; DRL on.
 Low beams switched off.
The DRL may stay on. The
length of time they stay on
depends on the vehicle
battery charge.
Low beams switched on.
Fog lights switched off.
The DRL may stay on for
some time.
Headlights and fog lights
switched on.

Fog lights
The indicator light in the headlight switch or the instrument cluster
shows that the fog lights are switched on.
To switch on the fog lights : first turn the light switch to
position , then pull the light switch out to the first detent.
To switch off the fog lights, push the switch back in from the first
detent. To then turn off the headlights, turn the switch to position /.
Acoustic warning when lights are not switched off
In the following situation, a warning chime will sound if you take the
key out of the ignition and open the driver door. This is to remind you
that lights are still on.
Light switch in position  if the vehicle has no orientation lighting
⇒  Coming home and Leaving home feature (orientation lighting).

Button Function
s
Door contact switch - center position.
Interior lights go on automatically when the vehicle is un-
locked, a door is opened, or the vehicle key is removed
from the ignition.
The lights go out about 20 seconds after you close the
doors. They also go out when you lock the vehicle or switch
on the ignition.
*
Reading light on or off.


Glove and luggage compartment lights
The glove and luggage compartments may have lights that come on
automatically when they are opened and go off when they are closed.
Background lighting
When the ignition and headlights are switched on, the background
lighting in the roof console lights up.
There may also be lighting in the footwells and on the inside door trim
and door handle recesses.
The interior and reading lights go out when you lock the vehicle
or a few minutes after you remove the vehicle key from the ignition.
This helps to prevent unnecessary drain on the vehicle battery.

Turn the adjusting knob to the L position.
Adjust the left outside mirror. The right (passenger) outside mirror
will automatically adjust at the same time.
If needed, correct the position of the right mirror by turning the ad-
justing knob to the R position.
Auto-dimming outside mirror on the driver side
Some models are equipped with an auto-dimming outside mirror,
which is controlled together with the auto-dimming inside mirror ⇒ 
Inside mirror.
Memory for front passenger side mirror (when backing up)
On vehicles equipped with memory seats ⇒ page 136, Memory seats,
the passenger side mirror settings for backing up can be stored as
follows:
Choose the remote control vehicle key that will be used with the
settings about to be made.
Unlock the vehicle with that remote control vehicle key.
Set the electronic parking brake.
Switch on the ignition.
Activate the function Mirror down in the Settings - Convenience
menu.
Turn the adjusting knob for the side mirrors to the R position.
Shift the transmission into Reverse (R).
Adjust the passenger outside mirror for a clear view of the curb, for
example.
The adjusted mirror position is automatically stored and assigned
to the vehicle key used to unlock the vehicle. The preselected posi-
tion will be recalled when the key assigned to that mirror adjustment
position is used again.
Recalling passenger side mirror settings
Turn the adjusting knob for the side mirrors to the R position.
Shift the transmission into reverse gear with the ignition switched
on.
The mirror moves back to the regular position when the vehicle
moves forward faster than about 10 mph (15 km/h) or the adjusting
knob is turned to the O or L position.

Folding the rear seat backrest forward and back into place

Fig. 100 Rear seat backrest: Release button 1; red mark 2; emergen-
cy key in lock 3.

Fig. 101 In the luggage compartment: Release lever for the left 1 and
right 2 sections of the rear seat backrest.

If the pass-through is equipped with a lock, use the emergency key
⇒  Vehicle key set to unlock the luggage compartment pass-through.
Pull the release lever ⇒ fig. 102 and fold the pass-through cover all
the way forward.
Open the luggage compartment lid.
Slide long objects from the luggage compartment through the pass-
through.
Secure objects with the safety belt.
Close the luggage compartment lid.
Closing the pass-through
Fold the pass-through cover back until it engages securely. The red
marking on the luggage compartment side ⇒ fig. 103 (1) should not
be visible.
Close the luggage compartment lid.
If the pass-through is equipped with a lock, use the emergency key
⇒  Vehicle key set to lock the luggage compartment pass-through.
If necessary, fold the center armrest up.
The pass-through can also be opened from the luggage com-
partment. Press the release lever (1) down and push the cover for-
ward.
Tie-downs

Fig. 104 In the luggage compartment: Tie-downs.

(2) Strap indicating the location of the storage compartment handle
(3) MDI (MEDIA-IN) jack in the pull-down storage compartment
Opening and closing the glove compartment
If necessary, unlock the glove compartment with the emergency key
⇒  Vehicle key set. It is locked when the key slot is vertical.
To open, pull the handle ⇒ fig. 124.
To close, push the lid up.
Opening and closing the storage compartment for the Owner's
Manual or MDI (MEDIA-IN) jack
Depending on equipment, the storage compartment at the top of the
glove compartment is designed to hold either the Owner's Manual or
the MDI (MEDIA-IN) jack.
The Owner's Manual compartment or MDI (MEDIA-IN) jack is located
in a storage compartment at the top, which can be pulled down to
open ⇒ fig. 125 (3).
The strap (2) indicates the handle for opening the storage compart-
ment.
If the vehicle is not equipped with the MDI (MEDIA-IN) jack, always
keep the Owner's Manual in this storage compartment. To stow the
Owner's Manual, place it in the slot with the binding facing the inside
of the glove compartment door.
Holders
Depending on the model, there may be holders for a pen and a note-
pad in the glove compartment.
Cooling the glove compartment
There is an air vent (1) in the back of the glove compartment. Cool air
can be directed into the glove compartment if the air conditioner is on.
Open or close the air vent by turning it.

Vehicle key positions in the ignition switch

Fig. 133 In the ignition switch: Vehicle key positions.

WARNING
Improper use of vehicle keys can result in serious personal in-
jury.
Always take the key with you when you leave the vehicle. The
engine can be started and vehicle systems such as the power
windows can be operated, leading to serious personal injury.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
with the remote control vehicle key. This could result in people
being trapped in the vehicle in an emergency. For example, de-
pending on the time of year, people trapped in the vehicle can
be exposed to very high or very low temperatures.
Heat buildup in the passenger and luggage compartment of a
parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures, particularly in
summer. Temperatures can quickly reach levels that can cause
unconsciousness and death, particularly to small children.
Never remove the key from the ignition switch while the vehi-
cle is moving or rolling to a stop. The steering wheel will lock
and you will not be able to steer or control the vehicle.
Leaving the key in the ignition for a long time when the engine is
not running will drain the vehicle battery.
Leaving the selector lever for a long period of time in any position
other than Park (P) when the ignition is switched off can drain the
vehicle battery.
On automatic transmission vehicles, the vehicle key can be
removed from the ignition switch only when the transmission is in
Park (P). You may have to press the release button on the transmis-
sion selector lever to put the lever into Park (P).
