2017 VOLKSWAGEN CC key

The buttons 1 , 2 , and 3 on the keypad in the sun visor can operate
up to 3 separate devices (for example, a gate and garage door,
house alarm or lighting system).

Please carry out each step only in the order specified:
1. For first time programming only: Press and hold the two
outer HomeLink buttons 1 and 3 at the same time for about 20
seconds, releasing only when the HomeLink indicator light
above button 2 begins to flash.
This step deletes any old settings. Do not perform this step
when programming the additional HomeLink buttons.
2. Position the hand-held transmitter for your remote control de-
vice 1-3 inches (25-75 mm) away from the HomeLink keypad
on the driver side sun visor, keeping the HomeLink indicator
light in view, as shown ⇒ fig. 41.
3. Using both hands, simultaneously press and hold both the
HomeLink button you want to program ( 1 , 2 , or 3 ) and the
hand-held transmitter button, as shown ⇒ fig. 42. Do not re-
lease the buttons until the HomeLink indicator light flash-
es slowly and then rapidly. When the indicator light flashes
rapidly, release both buttons. The rapid flashing indicates suc-
cessful programming.
4.
Press and hold the programmed HomeLink button and watch
the indicator light.
If the indicator light comes on and does not flash, programming
is complete and your garage door opener or other device
should activate when the HomeLink button is pressed and re-
leased.
If the indicator light blinks rapidly for 2 seconds and then stays
on, proceed with the following programming instructions for a
rolling code device. A second person may make the following
steps quicker and easier. Please use a ladder or other device.
Do not stand on your vehicle to perform the next steps ⇒  in
Operating the HomeLink® Universal Transmitter

Please carry out each step only in the order specified:
5.
At the garage door opener receiver (overhead unit) in the gar-
age, locate the “learn” or “training” button. The name and color
of the button may vary by manufacturer. This button is usually
located near the hanging antenna wire attachment point on the
unit. If you cannot locate the “training” button, refer to the gar-
age door opener’s user manual.
6. Press and release the “training” button.
Once the button is pressed, you have 30 seconds to initi-
ate the next step.
7. Return to the vehicle. Firmly press and hold the programmed
HomeLink button for 2 seconds and release.
8. Repeat the “press/hold/release” sequence up to 3 times to
complete the programming process for that button.

Repeat the steps to program the other buttons for the HomeLink®
Universal Transmitter on the sun visor keypad to control other devic-
es.
Deleting programming for all buttons
Be sure to delete programming on all buttons on the sun visor keypad
before selling the vehicle or turning it over to people you do not know.
Complete the programming preparation steps described above.
Press and hold buttons 1 and 3 at the same time, for about 20
seconds.
When the indicator light above button 2 begins to flash, immediate-
ly release buttons 1 and 3 . This step deletes all old settings.
After programming
Test the garage door opener
Operating the HomeLink® Universal Transmitter

Memory buttons
Personal settings for the front seats and outside mirrors can be as-
signed to each memory button.
These settings can be assigned to individual remote control vehicle
keys. The settings are applied after unlocking the vehicle and opening
the driver door.
Storing driver seat settings and forward driving settings for
outside mirrors
Switch on the ignition.
Manual transmission: Shift the transmission to Neutral (N) and set
the electronic parking brake.
Automatic transmission: Shift the transmission to Park (P).
Adjust the driver seat and outside mirrors.
Press the 3%4 button for at least 1 second ⇒ fig. 57.
Press the desired memory button 1 , 2 , or 3 within 10 seconds. A
chime sounds to confirm that the setting has been stored.
Storing front passenger seat settings to the front passenger seat
memory buttons
Switch on the ignition.
Adjust the passenger seat.
Press the 3%4 button for at least 1 second ⇒ fig. 57.
Press the desired memory button 1 , 2 , or 3 within 10 seconds. A
chime sounds to confirm that the setting has been stored.
Storing passenger-side outside mirror settings for backing up
Set the electronic parking brake.
Switch on the ignition.
Shift the transmission to Neutral (N).
Briefly press the desired memory button 1 , 2 , or 3 on the outside
of the driver seat.
Shift the transmission into Reverse (R).
Adjust the passenger outside mirror to provide good visibility of the
curb, for example.
The adjusted mirror position is automatically stored and assigned
to the vehicle key used to unlock the vehicle. The preselected posi-

tion will be recalled when the key assigned to that mirror adjustment
position is used again.
The passenger-side outside mirror automatically adjusts back from
the position stored for backing up when the vehicle moves forward at
about 10 mph (15 km/h) or more or when the rotary knob is rotated
from R into a different position.
Recalling stored seat memory settings
Briefly press the appropriate memory button when the vehicle is not
moving, the ignition is switched off, and the vehicle door is open.
OR: If the ignition is switched on and the door is closed, press and
hold the appropriate memory button until the stored position is
reached.
Assigning driver seat and outside mirror settings to a vehicle
key
The memory function of all vehicle keys is disabled when the vehicle
is first delivered from the factory.
To enable vehicle key memory function:
Unlock the driver door.
Press and hold a memory button ⇒ fig. 57 until memory position is
reached.
Press and hold the unlock button 0 on the vehicle key and then
press the desired memory button at the same time within about
3 seconds. A chime sounds to confirm activation.
To disable vehicle key memory function:
Press and hold the 3%4 button.
Press and hold the unlock button 0 on the vehicle key and the de-
sired memory button at the same time within about 10 seconds. A
chime sounds to confirm deactivation.
Assigning settings to an additional vehicle key
Follow the instructions ⇒  Assigning driver seat and outside mirror
settings to a vehicle key to assign the driver seat and outside mirror
settings to the vehicle key.
Unlock the vehicle with the same vehicle key.
Adjust driver seat and outside mirrors.

Lock the vehicle with locking button 1 in the vehicle key to store
the settings.
Once the settings are stored, the driver seat and the outside mirrors
move to the stored positions whenever the vehicle is unlocked with
the 0 button on the vehicle key (or unlocked with the door handle
sensor on vehicles with Keyless Access) and the driver door is
opened. If 2 people use the vehicle, each of them should always use
the key in which his or her personal settings have been stored.
Initializing the memory seats
The memory system must be initialized by an authorized Volkswagen
dealer, an authorized Volkswagen Service Facility, or another quali-
fied workshop in certain situations, for instance, if a new driver seat is
installed.
Initializing clears all memories and assignments of the memory seats.
After that, memory buttons can be reprogrammed and assigned to a
vehicle key.
Open the driver door but do not enter the vehicle.
Adjust the seats from the outside.
Move the angle of the backrest forward as far as it will go.
Release the backrest adjustment switch and press it again until you
hear a chime sound.
Cancellation conditions when storing settings for the memory
buttons
When one of the following conditions is met, the storing process will
be cancelled:
The vehicle battery is weak or dead.
The 3%4 button is pressed again within about 10 seconds.
The seat position is readjusted within about 10 seconds after
pressing the 3%4 button.

WARNING
Not wearing a safety belt or wearing an improperly positioned
safety belt increases the risk of severe personal injury or death.
Safety belts offer optimum protection only when they are used
properly.
Properly worn safety belts are the single most effective
means of reducing the risk of serious injury and death in a col-
lision or other accident. For this reason, always wear your safe-
ty belt properly and make sure all passengers wear their safety
belts properly as well whenever the vehicle is moving.
The driver must always make sure that every person in the
vehicle is properly seated on a seat of his or her own, properly
fastens the safety belts belonging to that seat before the vehi-
cle starts to move, and keeps the belts properly fastened while
riding in the vehicle. This applies even when just driving
around town. Therefore, always wear your safety belts and
make sure that everybody in your vehicle is properly restrained.
Always secure children in the vehicle with a restraint system
appropriate for their age, weight and height ⇒  Child safety and
child restraints.
Always fasten safety belts correctly before driving off and
make sure that all passengers are properly restrained.
Never attach the safety belt to the buckle of another seat. At-
taching the safety belt to the wrong buckle will reduce safety
belt effectiveness and can cause serious personal injury.
Never let any objects or liquids get into the safety belt latch
and prevent it from working properly.
Never remove a safety belt while the vehicle is moving. Doing
so will increase your risk of being injured or killed.
Never strap more than one person, including small children,
into any single safety belt.
Never let children or babies ride sitting on your lap, and nev-
er place a safety belt over a child sitting on your lap.
Never wear belts over rigid or breakable objects in or on your
clothing, such as eyeglasses, pens, keys, etc., as these may
cause injury.

WARNING
Improperly positioned safety belts can cause serious personal
injury in an accident or a sudden braking maneuver.
Always make sure that all vehicle occupants are correctly re-
strained and stay in a correct seating position whenever the
vehicle is being used.
Safety belts offer optimum protection only when the seat
backrest is upright and belts are correctly positioned on the
body.
A loose-fitting safety belt can cause serious injuries by shift-
ing its position on your body from the strong bones to more
vulnerable soft tissue and cause serious injury.
The shoulder belt portion of the safety belt must be posi-
tioned over the middle of the occupant's shoulder and never
across the neck or throat.
The safety belt must lie flat and snug on the occupant's up-
per body.
Never wear the shoulder part of the safety belt under your
arm or otherwise out of position.
The lap portion of the safety belt must be positioned as low
as possible across the pelvis and never over the abdomen.
Make sure the belt lies flat and snug against the pelvis. Pull on
the safety belt to tighten if necessary.
Expectant mothers must always wear the lap portion of the
safety belt as low as possible across the pelvis and below the
rounding of the abdomen.
Do not twist the belt when attaching it. If you cannot untwist
a twisted safety belt, wear it anyway, but make sure the twisted
part is not in contact with your body. Have the problem correct-
ed right away by an authorized Volkswagen dealer or author-
ized Volkswagen Service Facility.
Never hold the safety belt away from your body with your
hand.
Never wear belts over rigid or breakable objects, such as
eyeglasses, pens or keys.
Never modify the position of the belt using comfort clips,
loops or similar devices.

Key to fig. 70:
(1) Vehicle safety belt buckle.
(2) Buckle tongue on the safety belt extender.
(3) Safety belt buckle on the safety belt extender.
(4) Safety belt buckle tongue on the factory-installed safety belt.
Key to fig. 71:
(A) Safety belt buckle on the safety belt extender.
(B) Distance between the safety belt buckle on the safety belt ex-
tender and the centerline of the person using the safety belt ex-
tender. The distance must be more than 6 inches (15 cm)!
(C) Centerline of the person using the safety belt extender.
Using a safety belt extender
Adjust both the seat and the head restraint properly ⇒ Adjusting the
seating position.
Insert the buckle tongue on the safety belt extender ⇒ fig. 70 (2)
into the vehicle belt buckle for the seat where the safety belt extender
is being used (1).
Fastening or unfastening the vehicle safety belt ⇒ Fastening and
unfastening safety belts.
Pull the belt to make sure that the tongues are securely locked in
the buckles.
Make sure that the safety belt is positioned properly ⇒ Safety belt
position.
Properly using safety belt extenders:
Use a safety belt extender only when the factory installed safety
belt is too short when worn properly by a person in proper seating
position.
Only use 1 safety belt extender per seat and vehicle safety belt.
Always remove the safety belt extender when it is not needed.
Never leave a safety belt extender attached to the vehicle safety
belt buckle when the extender is not needed and being used with the
safety belt. Otherwise, the airbag control module will receive an incor-
rect signal from the safety belt buckle and this will prevent the airbag
from working properly for a person who is not using the safety belt.
Leaving the extender attached to the safety belt buckle when the front
seat is occupied and the safety belt is not being used will signal the
airbag control unit during a collision that the front passenger seat is
