2017 VOLKSWAGEN CC key

Starter button

Fig. 134 In the center console: Starter button for the Keyless Access
locking and starting system.

The engine switches off automatically.
Engine restart feature
If no authorized remote control vehicle key is identified in the passen-
ger compartment after the engine has been switched off, the engine
can be restarted within about 5 seconds. A related message is shown
in the instrument cluster display.
After the 5 seconds have passed, the engine can no longer be started
without an authorized vehicle key in the passenger compartment.
WARNING
Unintended vehicle movement can cause serious personal inju-
ry.
Do not depress the brake or clutch pedals when switching on
the ignition, as the engine could otherwise start immediately.
WARNING
Improper use of vehicle keys can result in serious personal in-
jury.
Always take the key with you when you leave the vehicle.
Children or unauthorized persons may use it to lock the vehi-
cle, start the engine, and operate vehicle systems such as the
power windows, leading to serious personal injury.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
using the remote control vehicle key. This could result in peo-
ple being trapped in the vehicle in an emergency. For example,
depending on the time of year, people trapped in the vehicle
can be exposed to very high or very low temperatures.
Heat buildup in the passenger and luggage compartment of a
parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures, particularly in
summer. Temperatures can quickly reach levels that can cause
unconsciousness and death, particularly to small children.
If the ignition is switched on or the engine is running and the driv-
er door is opened, a chime sounds. The chime is also a reminder to

WARNING
Never leave the vehicle unattended while the engine is running.
The vehicle could move suddenly, especially when the vehicle
is in gear, resulting in accidents and personal injury.
WARNING
“Starting fluids” can explode and can cause a “run-away” vehi-
cle condition.
Never use starting assist fluids.
NOTICE
You can damage the starter or the engine if you try to start the
engine when the vehicle is still moving, or if you try to restart the
engine right after switching it off.
Avoid high engine speeds, full throttle acceleration, and heavy
engine loads when the engine is cold.
Do not try to start the engine by pushing or towing the vehicle.
Unburned fuel can get into the catalytic converter and damage it.
The steering column may also be locked.
Do not let your vehicle warm up while standing; instead, start
driving right away after making sure that you have good visibility
through all windows. This will help the engine reach operating tem-
perature faster and keep down emissions.
If the remote control vehicle key battery is weak or dead, the
starter button will not start the engine. In this case, start the engine by
inserting the vehicle key in the ignition switch ⇒ Vehicle key positions
in the ignition switch.
Major consumers of electricity are temporarily switched off when
the engine is being started.
After starting a cold engine, there may be increased operating
noises for a few seconds. This is normal and harmless.

WARNING
Never stop the engine before the vehicle has come to a com-
plete stop. You can lose control of the vehicle, crash, and be
seriously injured.
The airbags and safety belt pretensioners will not work when
the ignition is switched off.
The brake booster does not work when the engine is not run-
ning. More brake pedal pressure will be needed to stop the ve-
hicle.
The power steering system does not work when the engine is
not running, and you will need more force to steer the vehicle.
When the key is removed from the ignition switch, the steer-
ing will lock and you will not be able to steer the vehicle.
NOTICE
If the vehicle has been driven hard for a long time, the engine
could overheat when it is stopped. To reduce the risk of engine
damage, let the engine idle in Neutral for about 2 minutes before
you switch off the ignition.
If the ignition is switched on or the engine is running and the driv-
er door is opened, a chime sounds. The chime is also a reminder to
switch off the engine and turn off the ignition before leaving and lock-
ing the vehicle from the outside.
On vehicles with automatic transmissions, the vehicle key can
only be removed from the ignition when the transmission is in Park
(P).
After the engine has been switched off, the radiator fan in the
engine compartment may keep running for several minutes, or may
start running after the vehicle has been parked for a while, even if the
ignition is switched off and the vehicle key has been removed. The
radiator fan shuts off automatically when the engine has cooled down
enough.

Flashes Possible cause Proper response
D
Steering system stiff. Turn the steering wheel back
and forth.
Steering column not
locked/unlocked.
Switch the ignition off and
then switch it on again. Heed
any messages shown in the
instrument cluster display, if
applicable.
On vehicles with Keyless Ac-
cess ,press the starter button
briefly twice in a row without
depressing the brake or
clutch pedal.
Do not drive any farther if
the steering column remains
locked after you switch on the
ignition. Contact your author-
ized Volkswagen dealer or an
authorized Volkswagen Ser-
vice Facility for assistance.

When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.

WARNING
Parking improperly can cause serious personal injury.
Never remove the key from the ignition switch while the vehi-
cle is moving or rolling to a stop. The steering wheel will lock
and you will not be able to steer or control the vehicle.
Never park the vehicle where the hot exhaust system or cata-
lytic converter could ignite flammable materials, such as brush,
leaves, dry grass, spilled fuel, etc.
Always apply the electronic parking brake when parking your
vehicle.
Improper use of the electronic parking brake can seriously
injure you and your passengers.
Never use the parking brake to slow down the vehicle when it
is moving, except in an emergency. The stopping distance is
much longer because only the rear wheels are braked. Always
use the foot brake to stop the vehicle.
Never activate the throttle manually from the engine com-
partment when the engine is running and the automatic trans-
mission is in gear. The vehicle will start to move as soon as the
engine speed increases even if the parking brake is on.
Never leave children or anyone who cannot help themselves
behind in the vehicle. They could switch off the parking brake
and move the gear selector lever or gear shift, which could
cause the vehicle to start moving. This can lead to a crash and
serious personal injuries.
Always take the key with you when you leave the vehicle. The
engine can be started and vehicle systems such as the power
windows can be operated, leading to serious personal injury.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
with the remote control vehicle key, trapping passengers in the
vehicle in an emergency. For example, depending on the time
of year, people trapped in the vehicle can be exposed to very
high or very low temperatures.

In order to Operation
view camera dis-
play (if equipped): OR: Tap the function key Z or 26# on the dis-
play.

The indicator light in the button  ⇒ fig. 157 comes on and stays on
as long as the feature is active.
A chime sounds to tell you that the system is on. If the chime does
not sound, PDC is not working. Have the system inspected by an
authorized Volkswagen dealer or an authorized Volkswagen Service
Facility.
Special considerations when using Park Distance Control
In some cases, the Park Distance Control interprets water and ice
on the sensors as an obstacle.
If the distance remains the same, the warning tone volume de-
creases after a few seconds. If a continuous tone sounds, its volume
remains the same.
If the vehicle moves away from the obstacle, the beeping sound
stops automatically. The beep turns on again automatically if the ve-
hicle approaches the obstacle again.
For vehicles with automatic transmissions, there is no beeping
when the transmission is in Park (P) and the electronic parking brake
is engaged.
The volume of the audible signals can be adjusted by an author-
ized Volkswagen dealer or an authorized Volkswagen Service Facili-
ty.
Muting the Park Distance Control volume
You can mute the PDC beeping signals by tapping the  function
key on the Radio or Navigation system screen (if applicable). Tap the
function key again to reactivate the acoustic signals.
Switching Park Distance Control back on after it was switched off re-
activates the volume. System malfunction warning signals cannot be
switched off.
If you manually deactivate the display, PDC remains on and the
sound is reactivated.

WARNING
Unintended vehicle movement during maintenance work can
cause serious personal injuries.
Never work under the vehicle unless you have safely secured
the vehicle from moving. If you must work under the vehicle
with the wheels on the ground, always make sure that the vehi-
cle is on level ground, that all 4 wheels are chocked to keep
them from moving, and that the key is not in the ignition.
If you must work under a vehicle raised on a floor jack, al-
ways make sure that the vehicle is safely supported on safety
stands intended for that purpose that are strong enough to
support the weight of the vehicle. The jack supplied with the
vehicle is not strong enough for this purpose and can collapse
causing serious personal injury.
