2017 TOYOTA TUNDRA Owners Manual

5139-1. Specifications
9
Vehicle specifications
Double Cab models
Model code*1EngineDriving
systemBed type
Vehicle capacity weight
(Occupants + luggage)
UPK51L-CRTSKA 1UR-FE
engine 2WD
Standard
1435 lb. (650 kg)
UPK56L-CRTSKA 4WD
1330 lb. (600 kg)
USK51L-CRTSKA 3UR-FE engine
2WD
1610 lb. (730 kg)
1545 lb. (700 kg)*2
1425 lb. (645 kg)*3
USK51L-CRTLKA
1575 lb. (710 kg)
1510 lb. (680 kg)*2
1395 lb. (630 kg)*3
USK51L-CRTSGA 3UR-FBE engine
1610 lb. (730 kg)
1545 lb. (700 kg)*2
1425 lb. (645 kg)*3
USK51L-CRTLGA
1575 lb. (710 kg)
1510 lb. (680 kg)*2
1395 lb. (630 kg)*3
USK52L-CHTSKA 3UR-FE
engine
Long
1580 lb. (715 kg)
1515 lb. (685 kg)*2
1400 lb. (635 kg)*3
USK52L-CHTSGA3UR-FBE
engine
1580 lb. (715 kg)
1515 lb. (685 kg)*2
1400 lb. (635 kg)*3
USK56L-CRTSKA
3UR-FE engine 4WD Standard
1500 lb. (680 kg)
1435 lb. (650 kg)*2
1320 lb. (595 kg)*3
USK56L-CRTLKA
1485 lb. (670 kg)
1420 lb. (640 kg)*2
1305 lb. (590 kg)*3

5149-1. Specifications
*1: The model code is indicated on the Certification Label. (→P. 519)
*2: Vehicles with towing package
*3: Vehicles with towing package and large fuel tank
Model code*1EngineDriving
systemBed type
Vehicle capacity
weight
(Occupants + luggage)
USK57L-CHTSKA 3UR-FE
engine
4WDLong
1475 lb. (665 kg)
1410 lb. (635 kg)*2
1295 lb. (585 kg)*3
USK56L-CRTSGA
3UR-FBE engine Standard
1500 lb. (680 kg)
1435 lb. (650 kg)*2
1320 lb. (595 kg)*3
USK56L-CRTLGA
1485 lb. (670 kg)
1420 lb. (640 kg)*2
1305 lb. (590 kg)*3
USK57L-CHTSGA
Long
1475 lb. (665 kg)
1410 lb. (635 kg)*2
1295 lb. (585 kg)*3

5159-1. Specifications
9
Vehicle specifications
CrewMax models
Model code*1EngineDriving
systemBed type
Vehicle capacity weight
(Occupants + luggage)
UPK51L-PSTSKA 1UR-FE engine 2WD
Short
1390 lb. (630 kg)
1355 lb. (610 kg)*2
UPK56L-PSTSKA 4WD1280 lb. (580 kg)
1245 lb. (560 kg)*2
USK51L-PSTSKA
3UR-FE engine 2WD
1545 lb. (700 kg)
1510 lb. (680 kg)*2
1480 lb. (670 kg)*3
1360 lb. (615 kg)*4
1445 lb. (655 kg)*5
1325 lb. (600 kg)*6
USK51L-PSTLKA
1515 lb. (685 kg)
1480 lb. (670 kg)*2
1450 lb. (655 kg)*3
1335 lb. (605 kg)*4
1415 lb. (640 kg)*5
1300 lb. (585 kg)*6
USK51L-PSTZKA
1505 lb. (680 kg)
1470 lb. (665 kg)*2
1440 lb. (650 kg)*3
1320 lb. (595 kg)*4
1400 lb. (635 kg)*5
1285 lb. (580 kg)*6

5169-1. Specifications
USK51L-PSTSGA3UR-FBE engine 2WD
Short
1545 lb. (700 kg)
1510 lb. (680 kg)*2
1480 lb. (670 kg)*3
1360 lb. (615 kg)*4
1445 lb. (655 kg)*5
1325 lb. (600 kg)*6
USK51L-PSTLGA
1515 lb. (685 kg)
1480 lb. (670 kg)*2
1450 lb. (655 kg)*3
1335 lb. (605 kg)*4
1415 lb. (640 kg)*5
1300 lb. (585 kg)*6
USK51L-PSTZGA
1505 lb. (680 kg)
1470 lb. (665 kg)*2
1440 lb. (650 kg)*3
1320 lb. (595 kg)*4
1400 lb. (635 kg)*5
1285 lb. (580 kg)*6
Model code*1EngineDriving
systemBed type
Vehicle capacity weight
(Occupants + luggage)

5179-1. Specifications
9
Vehicle specifications
USK56L-PSTSKA3UR-FE engine 4WD
Short
1450 lb. (655 kg)
1415 lb. (640 kg)*2
1385 lb. (625 kg)*3
1270 lb. (575 kg)*4
1350 lb. (610 kg)*5
1230 lb. (555 kg)*6
USK56L-PSTLKA
1405 lb. (635 kg)
1370 lb. (620 kg)*2
1340 lb. (605 kg)*3
1225 lb. (555 kg)*4
1305 lb. (590 kg)*5
1190 lb. (535 kg)*6
USK56L-PSTZKA
1410 lb. (635 kg)
1370 lb. (620 kg)*2
1340 lb. (605 kg)*3
1225 lb. (555 kg)*4
1305 lb. (590 kg)*5
1190 lb. (535 kg)*6
Model code*1EngineDriving
systemBed type
Vehicle capacity weight
(Occupants + luggage)

5189-1. Specifications
*1: The model code is indicated on the Certification Label. (→P. 519)
*2: Vehicles with electric moon roof
*3: Vehicles with towing package
*4: Vehicles with towing package and large fuel tank
*5: Vehicles with towing package and electric moon roof
*6: Vehicles with towing package, electric moon roof and large fuel tank
USK56L-PSTSGA
3UR-FBE engine 4WD
Short
1450 lb. (655 kg)
1415 lb. (640 kg)*2
1385 lb. (625 kg)*3
1270 lb. (575 kg)*4
1350 lb. (610 kg)*5
1230 lb. (555 kg)*6
USK56L-PSTLGA
1405 lb. (635 kg)
1370 lb. (620 kg)*2
1340 lb. (605 kg)*3
1225 lb. (555 kg)*4
1305 lb. (590 kg)*5
1190 lb. (535 kg)*6
USK56L-PSTZGA
1410 lb. (635 kg)
1370 lb. (620 kg)*2
1340 lb. (605 kg)*3
1225 lb. (555 kg)*4
1305 lb. (590 kg)*5
1190 lb. (535 kg)*6
Model code*1EngineDriving
systemBed type
Vehicle capacity weight
(Occupants + luggage)

5199-1. Specifications
9
Vehicle specifications
■Vehicle identification number
The vehicle identification number (VIN) is the legal identifier for
your vehicle. This is the primary identification number for your Toy-
ota. It is used in registeri ng the ownership of your vehicle.
This number is stamped on the
top left of the instrument panel.
This number is also on the Cer-
tification Label.
■Engine number
The engine number is stampe d on the engine block as shown.
Vehicle identification
1UR-FE engine3UR-FE and 3UR-FBE
engines

5209-1. Specifications
Engine
Model1UR-FE, 3UR-FE, 3UR-FBE
Ty p e8-cylinder V-type, 4-cycle, gasoline
Bore and stroke
1UR-FE engine
3.70 × 3.27 in. (94.0 × 83.0 mm)
3UR-FE and 3UR-FBE engines
3.70 × 4.02 in. (94.0 × 102.0 mm)
Displacement
1UR-FE engine
281.2 cu.in. (4608 cm
3)
3UR-FE and 3UR-FBE engines
345.6 cu.in. (5663 cm
3)
Drive belt tensionAutomatic adjustment
Valve clearance
(engine cold)Automatic adjustment
Fuel
EngineModel1UR-FE and 3UR-FE
engines3UR-FBE engine
Ty p eGasoline engineFlex-fuel engine
Fuel typeUnleaded gasoline only
Unleaded gasoline,
E85, or a blend of the two fuels
Octane rating
(Unleaded gasoline)87 (Research Octane Number 91) or higher
Ethanol percentage
(E85)—85% or less
Fuel tank capacity
(Reference)
Standard fuel tank: 26.4 gal. (100.0 L, 22.0 Imp.gal.)
Large fuel tank: 38.0 gal. (144.0 L, 31.7 Imp.gal.)
