2017 TOYOTA TUNDRA Owners Manual

3776-3. Using the storage features
6
Interior features
■Rear
Double Cab models with front separated type seats
Pull the lid down
Double Cab models with front bench type seat
Pull the lid down
CrewMax models
Pull the armrest down
CAUTION
■Items unsuitable for the cup holder
Do not place anything other than cups or beverage cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury. If possible, cover hot drinks to prevent
burns.

3786-3. Using the storage features
Front door
Rear door (CrewMax models)
Bottle holders
CAUTION
■Items unsuitable for the bottle holders
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
■Items that should not be st owed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.

3796-3. Using the storage features
6
Interior features
Ty p e A
Pull the strap
Ty p e B
Pull the lever up and fold down
the seatback
Push the knob and lift the lid
Auxiliary boxes (front bench type seat)
1
2

3806-3. Using the storage features
Ty p e C
Pull the lever up and fold down
the seatback
Push the knob and lift the lid
1
2

3816-3. Using the storage features
6
Interior features
■Using the storage box
Pull the lever up and raise the
rear seat cushion
Open the lidTurn the knob in the “OPEN”
direction
Lift the lid
Storage box (if equipped)
1
2
1
2

3826-3. Using the storage features
■Remove the storage box
Pull the lever up and raise the
rear seat cushion
Open the lid
Turn the knob in the “OPEN”
direction
Lift the lid
Remove the storage box Remove the lids
Turn the knobs counterclock-
wise
Remove the storage box
1
2
1
2
3
1
2
3
CAUTION
■To prevent damage to the storage box
Do not put heavy loads on the lids.

3836-3. Using the storage features
6
Interior features
Luggage compartment features
Deck hooks are provided for
securing loose items.
Deck hooks

3846-4. Using the other interior features
Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Open the cover
The light turns on when the cover
is opened.
Sun visors
1
2
3
Vanity mirrors (if equipped)
NOTICE
Do not leave the vanity lights on for extended periods while the engine is
stopped.
