2017 TOYOTA PRIUS PRIME display

734
PRIUS PRIME_OM_OM47A88U_(U)
9-2. Customization
Settings that can be changed using the multi-information display
Settings that can be changed using the navigation system
Settings that can be changed by your Toyota dealer
Definition of symbols: O = Available, – = Not available
■Hybrid system ( →P. 8 5 )
■Instrument cluster ( →P. 180)
Customizable features
1
2
3
FunctionDefault
settingCustomized setting
Vehicle Proximity Notification
System (volume of sound)Level 1Level 2––OLevel 3
123
FunctionDefault settingCustomized setting
Sensor sensitivity for darken-
ing the brightness of the
instrument cluster depending
on the outside brightness
Standard-2 to 2––O
Sensor sensitivity for returning
the brightness of the instru-
ment cluster to the original
level depending on the outside
brightness
Standard-2 to 2––O
123

PRIUS PRIME_OM_OM47A88U_(U)
7359-2. Customization
9
Vehicle specifications
■HUD (Head-up display)* (→ P. 238)
*: If equipped
■
Door lock ( →P. 267, 690)
■Smart key system and wireless remote control ( →P. 268, 278)
FunctionDefault
settingCustomized setting
Route guidance*OnOffO––
123
FunctionDefault settingCustomized setting
Automatic door lockingShift position linkedSpeed linked–OO
Off–OO
Automatic door unlockingShift position linkedDriver’s door linked–OO
Off–OO
Unlocking using a mechanical
key
Driver’s door unlocked in
first step, all
doors
unlocked in
second step
All doors
unlocked in first step
––O
123
FunctionDefault settingCustomized setting
Operation signal (buzzer) 5Off
–OO
1 to 7
Operation signal (emergency
flashers) On
Off – O O
Time elapsed before the auto-
matic door lock function is
activated if a door is not
opened after being unlocked
60 seconds
Off
–OO30 seconds
120 seconds
Open door reminder buzzer
(when locking the vehicle)OnOff––O
123

PRIUS PRIME_OM_OM47A88U_(U)
7419-2. Customization
9
Vehicle specifications
■Seat belt reminder (→P. 658)
■Vehicle customization
●When the Speed linked door locking function and the Shift position linked
door locking function are both on, the door lock operates as follows.
• When shifting the shift position to any position other than P, all the doors
will be locked.
• If the vehicle is started with all the doors locked, the Speed linked door locking function would not operate.
• If the vehicle is started with any door unlocked, the Speed linked door
locking function will operate.
● When the smart key system is off, Smart door unlocking cannot be custom-
ized.
● When the doors remain closed after unlocking the doors and the automatic
door lock function is activated, the signals will be generated in accordance
with the operation signal (buzzer) and the operation signal (emergency
flashers) settings.
■ In the following situati ons, customize mode in which the settings can be
changed through the mu lti-information display will automatically be
turned off.
● The power switch is turned off.
● The vehicle begins to move while the customize mode screen is displayed.
FunctionDefault
settingCustomized setting
Vehicle speed linked seat belt
reminder buzzerOnOff––O
WARNING
■Cautions during customization
As the hybrid system needs to be oper ating during customization, ensure
that the vehicle is parked in a place with adequate ventilation. In a closed
area such as a garage, exhaust gases including harmful carbon monoxide
(CO) may collect and enter the vehicle. This may lead to death or a serious
health hazard.
NOTICE
■ During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is oper-
ating while customizing features.
123

764What to do if... (Troubleshooting)
PRIUS PRIME_OM_OM47A88U_(U)
●The seat belt reminder light is flashing
Are the driver and all the passengers wearing the seat belts? (→P. 658)
●The parking brake indicator is on
Is the parking brake released? ( →P. 337)
Depending on the situation, other types of warning buzzer may also sound.
( →P. 653, 663)
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display. ( →P. 663)
●When a warning light turns on or a warning message is displayed, refer to \
P. 653, 663.
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed

768Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Cargo capacity ......................... 321
Catch protection function ....... 301
CD player
*
Chains....................................... 483
Charging ................................... 102Charging cable...................... 107
Charging equipment ............. 102
Charging indicator................. 106
Charging messages .............. 175
Charging precautions............ 143
Charging procedure .............. 136
Charging time may increase .............................. 126
Charging timer function......... 147
High voltage components ....... 90
Information related to charging display ................. 130
Opening and closing the charging port lid .................. 103
Power sources
precautions ......................... 124
Power sources that can be used.................................... 122
Safety functions ............ 132, 141
When normal charging cannot be carried out.......... 170
Charging cable......................... 107
CCID (Charging Circuit Interrupting Device) ............ 107
If the charging cable
cannot be unlocked ............ 120
Indicator................................. 109
Maintenance ......................... 112
Safety functions .................... 108
Charging port ........................... 102 Opening and closing ............. 103
Smart lid & connector
locking system ..... ............... 113
If the charging port lid does
not open ............................. 116 Child restraint system............... 58
Fixed with a LATCH
system .......... ..................... ... 70
Fixed with a seat belt .............. 64
Front passenger occupant classification syst em ............ 50
Points to remember ................ 58
Riding with children ................ 57
Types of child restraint system installation method ............... 60
Using an anchor bracket......... 73
Child safety ................................ 57 12-volt battery precautions ... 588
Airbag precautions.................. 40
Back door precautions .......... 275
Charging precautions ........... 131
Child restraint system ............. 58
How your child should wear the seat belt ................. 32
Installing child restraints ......... 60
Power window lock switch .... 300
Power window precautions ... 302
Rear door child-protectors .... 270
Removed key battery
precautions......................... 629
Riding with children ................ 57
Seat belt extender precautions........................... 34
Seat belt precautions .............. 69
Seat heater precautions ....... 513
Child-protectors ...................... 270
Cleaning ........................... 556, 561 Aluminum wheels ................. 557
Camera sensor ..................... 365
Exterior ................................. 556
Interior .................................. 561
Radar sensor ........................ 364
Seat belts.............................. 564
Water-repellent coating ........ 557

769Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Clock ......................................... 180Adjustment ............................ 185
Coat hooks ............................... 540
Combination meter .................. 180 Clock adjustment .................. 185
Main display .......................... 196
Multi-information display ....... 205
Warning lights and
indicators ............................ 188
Condenser ................................ 586
Console box ............................. 519
Consumption screen ....... 250, 256
Coolant ..................................... 584 Capacity ................................ 714
Checking ............................... 584
Preparing and checking before winter....................... 482
Cooling system ........................ 584 Engine overheating ............... 700
Hybrid system overheating ... 702
Cruise control .......................... 391 Dynamic radar cruise control with full-speed range .......... 391
Cup holders.............................. 520
Curtain shield airbags ............... 36
Customizable features ............ 732
Daytime running light system .................................... 341
Deck board ............................... 523
Defogger Outside rear view
mirrors ........................ 491, 502
Rear window ................. 491, 502
Windshield .................... 491, 501 Dimension ................................ 708
Dinghy towing.......................... 323
Display
BSM (Blind Spot Monitor) ..... 408
Drive information .................. 207
Dynamic radar cruise control with full-speed range .......... 391
Energy monitor ..... 208, 247, 253
Head-up display.................... 238
Intelligent Clearance Sonar.................................. 435
Intuitive parking assist .......... 421
LDA (Lane Departure Alert with steering control) .......... 385
Main display.......................... 196
Multi-information display ....... 205
Pre-collision warning ............ 369
S-APGS (Simple Advanced Parking Guidance
System) .............................. 446
Warning messages ............... 663
Do-it-yourself maintenance .... 574
Door courtesy lights ............... 515 Location ................................ 515
Wattage ................................ 717
Doors ................................ 267, 273 Automatic door locking
and unlocking system......... 270
Back door ............................. 273
Door glasses......................... 300
Door lock .............................. 267
Open door warning buzzer ... 655
Open door warning light ....... 655
Outside rear view mirrors ..... 298
Rear door child-protectors .... 270
Side doors ............................ 267
Side windows........................ 300
D
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

770Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Drive information ..................... 207
Drive-Start Control .................. 308
Driver’s seat belt reminder light......................................... 656
Driving ...................................... 306
Break-in tips .......................... 309
Correct posture ....................... 28
Driving in the rain .................. 307
Driving mode select switch ... 406
Plug-in hybrid vehicle driving tips ........................................ 97
Procedures ........................... 306
Winter drive tips .................... 482
Dynamic radar cruise control
with full-speed range ............ 391
ECB (Electronically Controlled Brake System) .... 476
Eco drive mode ........................ 406
EDR (Event data recorder) ........ 11
Electric motor (traction motor) ....................... 78
Location .................................. 78
Specification ......................... 711
Electric Power Steering (EPS)....................................... 477
Function ................................ 477
Warning light ......................... 654
Electronic key .......................... 262
Battery-saving function ......... 280
If the electronic key does not operate properly ........... 690
Replacing the battery ............ 627
Electronically Controlled Brake System (ECB) ............. 476 Emergency, in case of
If a warning buzzer sounds... 653
If a warning light turns on ..... 653
If a warning message is displayed ............................ 663
If the 12-volt battery is discharged.......................... 694
If the electronic key does
not operate properly ........... 690
If the hybrid system will not start .............................. 688
If you have a flat tire ............. 671
If you lose your keys ..... 263, 266
If you think something is wrong .............................. 652
If your vehicle becomes stuck ................................... 705
If your vehicle has to be stopped in an emergency ... 645
If your vehicle needs to be
towed.................................. 646
If your vehicle overheats....... 700
Emergency flashers ................ 644
Emergency tire puncture
repair kit ................................. 671
Energy monitor ........ 208, 247, 253
Engine Accessory mode ................... 326
Compartment ........................ 580
Engine switch ....................... 324
Exhaust gas precautions ........ 56
Hood ..................................... 577
How to start the hybrid system .......... ...................... 324
Identification number ............ 710
If the hybrid system will not start .............................. 688
If your vehicle has to be stopped in an emergency ... 645
Ignition switch (power switch) .................... 324
Overheating .......................... 700
Power switch ........................ 324
E

772Alphabetical index
PRIUS PRIME_OM_OM47A88U_(U)
Hands-free system (for cellular phone)
*
Head restraints ........................ 291
Head-up display ....................... 238
Headlights ................................ 338
Automatic High Beam system ......... ....................... 343
Headlight aim ................ 633, 758
Light switch ........................... 338
Replacing light bulbs............. 640
Heated steering wheel............. 514
Heaters
Automatic air conditioning system .... 488, 498
Heated steering wheel .......... 514
Outside rear view mirrors ........................ 491, 502
Seat heaters ......................... 513
High coolant temperature
warning light .......................... 655
High mounted stoplight Replacing .............................. 640
High-voltage components ........ 90
Hill-start assist control............ 477
Hood ......................................... 577
Hooks Coat hooks............................ 540
Grocery bag hook ................. 524
Retaining hooks (floor mat)..... 26
Horn .......................................... 294
HV mode ..................................... 79 Hybrid battery
(traction battery) ..................... 90
Air intake vent ......................... 91
Charging ............................... 102
Location .................................. 90
Specification ......................... 711
Status indicator ..................... 104
Hybrid battery (traction battery)
air intake vent .......................... 91
Hybrid system............................ 78 Brake Override System ........ 308
Consumption
screen ................ 218, 250, 256
Drive-Start Control ................ 308
Emergency shut off system .... 91
Energy monitor ..... 208, 247, 253
High voltage components ....... 90
Hybrid System Indicator ....... 210
If the hybrid system will not start .............................. 688
Overheating .......................... 700
Plug-in hybrid system precautions........................... 90
Plug-in hybrid vehicle driving tips........................................ 97
Power switch ........................ 324
Regenerative braking ............. 86
Starting the hybrid system .... 324
Vehicle proximity notification system................ 85
Hybrid System Indicator ......... 210
Hybrid transmission................ 330
H
