2017 TOYOTA LAND CRUISER Owners Manual

LC200_OM_OM60P24U_(U)
3775-1. Using the air conditioning system and defogger
5
Interior features
To turn on the individual mode, perform any of the following proce-
dures:
●Press “4-ZONE” on the op tion control screen.
● Adjust the passenger’s side temperature setting.
● Change the rear air conditioning setting
The indicator comes on when the individual mode is on.
To return to the simultaneous mode, press “4-ZONE”.
In the simultaneous mode, only or on the driver’s side can
be used to adjust the temperature for all seats.
Adjusting the temperature for driver and passenger seats sepa-
rately (Individual mode)

3785-1. Using the air conditioning system and defogger
LC200_OM_OM60P24U_(U)
Press on the control
screen to display the rear air con-
ditioning control screen.
Adjust the temperature set-
ting (left-hand rear seat)
Adjust the fan speed setting
Adjust the temperature set-
ting (right-hand rear seat)
Select to set automatic mode
Turn the fan off
■Using the automatic modePress “REAR AUTO”.
The air conditioning system will operate, and air outlets and speed will\
be set automatically.
Press “ ∧” to increase the temperature and “ ∨” to decrease the
temperature.
Air outlets for the right-hand and left-hand may be set separately
depending on the temperature setting.
■
Adjusting the temperature setting
Press “ ∧” (increase) “ ∨” or (decrease).
Operating the switch will enter the individual mode. ( →P. 377)
■
Adjusting the fan speed setting
Press (increase) or (decrease).
The fan speed is shown on the display. (7 levels)
Press “REAR OFF” to turn the fan off.
■
Turning the rear air conditioning system off
Press “REAR OFF”.
Changing the rear seat settings
1
2
3
4
5
1
2

LC200_OM_OM60P24U_(U)
3795-1. Using the air conditioning system and defogger
5
Interior features
■Switching between outside air and recirculated air modes
Press .
The mode switches between (recirculated air mode) and
(outside air mode) modes each time the button is pressed.
■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
Set the outside/recirculated air mode button to outside air mode if the
recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.
To return to the previous mode, press again when the wind-
shield is defogged.
Other functions

3805-1. Using the air conditioning system and defogger
LC200_OM_OM60P24U_(U)■
Defogging the rear window and
outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Press .
Press the switch again to turn the defogger off.
■
Micro dust and pollen filter
Press on the control screen.
Press .
Outside air mode switches to recirculated air mode. Pollen is removed
from the air and the air flows to the upper part of the body.
Usually the system will turn off automatically approximately 1 to 3 min-
utes.
To stop the operation, press again.
■
Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the wind-
shield and wiper blades.
Press on the control screen.
Press .
Press again to turn the de-icer off.
1
2
1
2

LC200_OM_OM60P24U_(U)
3815-1. Using the air conditioning system and defogger
5
Interior features
■Location of air outlets
The air outlets and air volume
changes according to the
selected air flow mode.
■Adjusting the position of and opening and closing the air out-
lets
Direct air flow to the left or right, up or down.
Turn the knob to open or close the vent.
Air outlets
Front outletsRear outlets
1
2

3825-1. Using the air conditioning system and defogger
LC200_OM_OM60P24U_(U)
■Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed.
■ Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Turning “A/C” on will dehumidify the air from the outlets and defog the wind-
shield effectively.
● If you turn “A/C” off, the windows may fog up more easily.
● The windows may fog up if the recirculated air mode is used.
■ Outside/recirculated air mode
●When driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to the recirculated air mode. This is effec-
tive in preventing outside air from entering the vehicle interior. During
cooling operation, setting the recirculated air mode will also cool the vehicle
interior effectively.
● Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.
■ When outside air temperature is low
The dehumidification function may not operate even when “A/C” is pressed.
■ When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on
● In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.
● Recirculated air mode is selected as a default mode when the engine switch
is turned to IGNITION ON mode.
● It is possible to switch to outside air mode at any time by pressing
.
■ Micro dust and pollen filter
●In order to prevent the windows from fogging up when the outside air is cold,
the following may occur.
• Outside air mode does not switch to recirculated air mode.
• The dehumidification function operates.
• The operation cancels after approximately 1 minute.
● In rainy weather, the windows may fog up. Press .
● In extremely humid weather, the windows may fog up.
● The pollens are filtered out even if the micro dust and pollen filter is turned
off.

LC200_OM_OM60P24U_(U)
3835-1. Using the air conditioning system and defogger
5
Interior features
■Ventilation and air conditioning odors
●To let fresh air in, set the air conditioning system to the outside air m\
ode.
● During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.
● To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic
mode.
■ The rear window defogger and windshield wiper de-icer (if equipped)
can be operated when
The engine switch is in IGNITION ON mode.
■ When the windshield wiper de-icer (if equipped) is on
The windshield wiper de-icer will automatically turn off after approximately 15
minutes.
■ Using the voice command system
Air conditioning system can be operated using voice commands. For details,
refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
■ While the cool box is on (if equipped)
The front air conditioning system cannot be turned off.
■ Air conditioning filter
→P. 477
■ Customization
Settings (e.g. A/C automatic mode switch operation) can be changed.
(Customizable features: →P. 574)

3845-1. Using the air conditioning system and defogger
LC200_OM_OM60P24U_(U)
WARNING
■To prevent the windshield from fogging up
● Do not use during cool air operation in extremely humid
weather. The difference between the temperature of the outside air and
that of the windshield can cause the outer surface of the windshield to fog
up, blocking your vision.
■ To prevent burns
● Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.
● Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on. (vehicles with wind-
shield wiper de-icer)
NOTICE
■To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is not running.
● Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.
