17
Some warning/indicator lights illuminate for a few seconds in order to check themselves
when the ignition switch is turned ON.
Main W aR ninG an D inDicato R LiGH ts
Warning lights
Refer to your Owner’s Manual for countermeasures when each warning light comes on.
If necessary, consult your authorized SUBARU dealer.
Seatbelt warning
Remind the driver to fasten
seatbelt.
Front passenger’s seatbelt warning
Remind the front passenger to
fasten seatbelt. Location: next to
overhead console.
Oil pressure warning
The engine oil pressure is too
low.
Engine low oil level warning
The engine oil level decreases to
the lower limit.
All-wheel drive warning (CVT models)
Tires of different diameter fitted/
air pressure excessively low.
SRS airbag system warning
SRS airbag system and/
or seatbelt pretensioners
malfunction.
Power steering warning
The electric power steering
system malfunction.
AT OIL TEMP warning (CVT models)
Transmission fluid temperature
is too hot./Transmission control
system malfunction.
Brake system warning
Electronic parking brake system malfunction/Brake fluid level/EBD System
malfunction (Anti-lock brake system warning light illuminates simultaneously).
Malfunction indicator (Check Engine)
Engine/Emission control system
malfunction.
Charge warning
Charging system malfunction.
Low fuel warning
Fuel tank is nearly empty. Refill
fuel immediately.
High beam assist warning
The high beam assist function
malfunction.
18
Automatic headlight beam leveler warning
Automatic headlight beam leveler malfunction.
Access key warning
The access key is not inside the vehicle. For other situations, refer to your
Owner’s Manual.
ABS warning
Anti-lock Brake System malfunction/EBD System malfunction.
(Brake System warning light illuminates simultaneously).
Windshield washer fluid warning
The fluid level in the windshield washer fluid tank decreases to the lower limit.
BSD/RCTA warning
Blind Spot Detection/Rear Cross Traffic Alert (BSD/RCTA) malfunction.
Vehicle Dynamics Control warning/Vehicle Dynamics Control operation indicator
Warning : Vehicle Dynamics Control system malfunction.
Indicator : Flashes during activation of the skid suppression function and the
traction control function.
Icy road surface warning screen
When the outside temperature becomes 3°C (37°F) or less, the icy road surface
warning screen interrupts to inform the driver that the road surface may be
frozen.
RAB warning
Reverse Automatic Braking System malfunctions.
u Some functions are available on certain models.
u For detailed operating and safety information, please refer to your Own\
er’s Manual.
19
indicator lights
The following indicators show the current status of your car. Refer to your Owner’s Manual
for more information.
Turn signal
indicatorHeadlight
indicatorHigh beam
indicator
Front fog light
indicatorSecurity
indicatorDoor open
indicator
BSD/RCTA OFF
indicatorCruise control
indicatorCruise control
set indicator
Hill Holder indicatorHill descent control indicator
High beam assist indicator
Steering responsive fog lights
OFF indicator
Front passenger’s frontal
airbag ON/OFF indicator
Sonar audible alarm OFF
indicator
Pre-Collision Braking System
OFF indicator
Electronic parking brake
indicator
Vehicle Dynamics Control OFF
indicator
RAB OFF indicator
Lane Departure Warning OFF
indicator
