2017 Peugeot Partner Tepee Owner's Manual

87
Partner2VP_en_Chap04_Ergonomie_ed02-2016Partner2VP_en_Chap04_Ergonomie_ed02-2016
Adjusting the angle of the seat backrest
- Operate the control and adjust the
angle.
Placing the seat backrest in the
table position
-

Lower the head restraint fully
.
-

Operate the control to fold the seat
back onto the seat cushion. Returning the seat backrest to the
sitting position
-


Release the seat backrest by
pullin

g the control, then return it to
its original position.
-
Ensure that it has correctly locked
into place.
Placing the seat in the fully folded
position
-

Place the seat in the table position.
-


Pull the red strap, located behind
the seat, to release the feet of the
seat from their anchorage on the
floor

.
-

T
ilt the entire seat forwards.
Row 2 seat adjustmentsReturning the seat to its original
position
-
Unfold the entire seat.
Before folding the seat, ensure
that:
-


in row 3, no passenger's
foot is at one of the seat
anchorages on the floor

,
-

the seat is locked securely on
the floor

,
-

the seat belt is available for
the passenger

.
EASE OF USE and COMFORT
4
Seats

88
Partner2VP_en_Chap04_Ergonomie_ed02-2016Partner2VP_en_Chap04_Ergonomie_ed02-2016
Row 3 seat adjustments
Placing the seat backrest in the
table position
-
Lower the head restraint fully
.
-

Operate the control to fold the seat
backrest onto the seat cushion.
Returning the seat backrest to the
sitting position
-


Release the seat backrest by
pullin

g the control, then return it to
its original position.
-

Check that it has correctly locked in
place. Returning the seat to its original
position
-


Push the red control.
-


Unfold the entire seat.
Placing the seat in the fully folded
position
-


Place the seat in the table position.
-


Raise the bar fitted with a red
strap, located behind the seat, to
release feet of the seat from their
anchorage on the floor

.
-

T
ilt the entire seat forwards.Ensure that:
-

the seat is locked securely on
the floor

,
-

the seat belt is available for
the passenger

.
Seats

89
Partner2VP_en_Chap04_Ergonomie_ed02-2016Partner2VP_en_Chap04_Ergonomie_ed02-2016
Entering, exiting from Row 3
Entering
-
Place the row 2 seat in the table
position.
Exiting
-


Lower the head restraint fully
.
-

Operate the yellow control, located
on the back of the row 2 seat
backrest.
-


Fold the seat backrest to the table
position. Ensure that the centre seat belt is
stowed correctly in its housing in
the headlining.
-


T
ilt it to the fully folded position to
allow access. -

Pull the red strap to place the seat
in the fully folded position.
-
T ilt the entire seat forwards.
-
Exit via the side door
.
Before folding it back, ensure that
the feet of the passenger in row 3
are not obstructing the row 2 seat
anchoring points.
EASE OF USE and COMFORT
4
Seats

90
Partner2VP_en_Chap04_Ergonomie_ed02-2016Partner2VP_en_Chap04_Ergonomie_ed02-2016
Removing a seat
-
If necessary
, move the front seats
forward.
-

Lower the head restraint.
-


Place the seat in the fully folded
position.
-


T
ilt the entire seat forwards then
lift it. Refitting the seat
The label on the seat indicates the
position in which it must be installed.
-

Place the hooks of the front feet
between the two bars.
-


Fold back the seat to fix the rear
anchoring points.
-


Operate the control to raise the
seat back to its initial position.
-


Raise the head restraint. Ensure that no object or foot of a
passenger seated in the rear is
obstructing the anchorage points
or preventing correct locking of
the seat.
Operating the Row 2 seats
Seats

91
Partner2VP_en_Chap04_Ergonomie_ed02-2016Partner2VP_en_Chap04_Ergonomie_ed02-2016
Operating the Row 3 seats
Removing the seat
-
Lower the head restraint.
-


Place the seat in the fully folded
position.
-


T
ilt the entire seat forwards.
-

On each side, take hold of the
uprights of the folded seat, tilting it
forward slightly

, and lift it. Refitting the seat
The label on the seat indicates the
position in which it must be installed.
-

Place the hooks of the front feet
between the two bars.
-


Ensure that no object or foot is
obstructing the rear anchorage
points and that the seat belt is
positioned correctly and available
for use.
-


Fold back the seat to fix its rear
anchoring feet.
-


Operate the control to raise the
seat back to its initial position.
-


Raise the head restraint.
Good practice
Following the various operations:
-
do not remove a head restraint
without stowing it; secure it inside
the vehicle,
-


ensure that the passengers can
always access the seat belts and
fasten them easily

,
-

passengers must never take
their seat without adjusting and
fastening their seat belt.
-


a passenger seated in row 3 must
ensure that he does not obstruct
the row 2 seat anchorage points,
-


a passenger seated in row 3 must
not have the seat in front of them in
row 2 in the folded position; this is
in case the seat could tip towards
the passenger unexpectedly and
injure them.
Do not place hard or heavy objects on
the seat backs forming a table, they
could become dangerous projectiles in
the event or sharp braking or impact.
EASE OF USE and COMFORT
4
Seats

92
Partner2VP_en_Chap04_Ergonomie_ed02-2016Partner2VP_en_Chap04_Ergonomie_ed02-2016
MODULARITY AND DIFFERENT SEAT CONFIGURATIONS
5 seat layouts
Seats

93
Partner2VP_en_Chap04_Ergonomie_ed02-2016Partner2VP_en_Chap04_Ergonomie_ed02-2016
7 seat layouts
The various operations
must be carried out while
stationary.
EASE OF USE and COMFORT
4
Seats

94
Partner2VP_en_Chap04_Ergonomie_ed02-2016Partner2VP_en_Chap04_Ergonomie_ed02-2016
FRONT FITTINGS
1. Lower glove box
This may or may not be fitted with a lid.
Upper storage compartment
This is located on the dashboard,
behind the steering wheel.
A recess makes lifting of the lid easier
when opening. Guide it to its rest
position.
To close, guide the lid then press the
centre gently.
Any liquid which could spill risks
causing an electrical short circuit and
therefore a potential fire.
3. Side storage compartment
4. Bag hook
Only hang flexible bags which are not
too heavy on this hook.
2. Storage pocket and bottle
holder (1.5 L)
Practical information
