2017 MITSUBISHI OUTLANDER III display

Adaptive Cruise Control System (ACC) (if so equipped) 5-116 Features and controls
5
If the display keeps showing the message, there is a possibility that the ACC has a mal-function. Contact your authorized Mitsubishi Motors dealer. When the ACC system
detects an abnormal-
ity in the system, the ACC system will beturned off, a buzzer will sound and a message will be displayed in the multi information dis- play. If the message remains after the opera-tion mode has been turned to the “OFF” position and then turned back to the “ON” position, contact your au
thorized Mitsubishi
Motors dealer.
N00581800059
After the ACC control has been canceled with the ACC turned on, the ACC control can beresumed by pushing up
and releasing the
“RES +” switch.
N00581900021
With the ACC turned on, the distance between your vehicle an
d a vehicle ahead can
be selected from thre
e levels by pushing the
ACC distance switch. Each time the ACC distance switch is pus
hed, the following dis-
tance will change fro
m “Long” to “Middle”,
to “Short”, and return to “Long” again.Everytime the ACC is turned to ON, the following distance is re
set to “Long”.
The following distance indicator shows the level of the following distance:“Long” “Middle”
To resume the control

NOTE
 When any of the following conditions are present, the ACC cont
rol cannot be resumed.
• When your vehicle speed is lower than approximately 6 mph (10 km/h) or higher than 110 mph (180 km/h). • When your vehicle is driven at speeds between approximately 6 mph (10 km/h)and 25 mph (40 km/h) and the ACC is not detecting a vehi
cle in front.
• When ASC is in the OFF position. • While ABS, ASC or TCL is activated.• When the selector lever
is in positions other
than

Forward Collision Mitigation System (FCM) (if so equipped)
Features and controls 5-117
5
“Short”
N00582000029
Press and hold the “ACC ON/OFF” switch while the operation mode is in the “ON” posi- tion. A buzzer will sound and the multi infor- mation display will show the following indicator. The conventional cruise
control is turned off
when the operation mode is tuned off. For operation of the cruise control, refer to“Cruise control” on page 5-102.
N00582100020
FCC ID:OAYARS3-B (for vehicles sold in the U.S.A) IC: 4135A-ARS3B (for vehicles sold in theCanada) This device complies
with Part 15 of FCC
Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two con-
ditions.  this device may not
cause harmful inter-
ference.  this device must ac
cept any interference
received, including interference that maycause undesired operation.
N00577300066
The Forward Collision Mitigation System(FCM) is designed to help reduce the risk of a collision with a vehicle or a pedestrian straight ahead of your vehicle. The FCM usesa sensor (A) to determine the distance and relative speed to a vehicle and a pedestrian in front. The FCM is not designed as an auto-matic driving system or as a collision avoid- ance system. When your vehicle is approaching a vehicleor a pedestrian strai
ght-ahead in your path
To activate conventional cruise control

NOTE
 The conventional crui
se control does not
sound or display the approach alarm, will notadjust your vehicle sp
eed, and does not con-
trol the distance betw
een your vehicle and a
vehicle in front.
General information

CAUTION Changes or modifica
tions not expressly
approved by the manufacturer for compli- ance could void the user’s authority to oper-ate the equipment.
Forward Collision Mitiga- tion System (FCM)
(if so
equipped)
BK0239700US.book 117 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Forward Collision Mitigation System (FCM) (if so equipped)
Features and controls 5-119
5
N00577400041
If the system judges that there is a risk of your vehicle colliding wi
th a vehicle or the
pedestrian in front, this function warns you of the potential hazard with
visual and audible
alarms.When this function is triggered, a buzzer sounds and, at the sa
me time, a “BRAKE”
message appears on the information screen of the multi-information display. The FCM will also prepare to provide quickbrake response and greater brake force when you apply the brakes. The forward collision
warning function oper-
ates when the following vehicle speed:  Against a vehicle: Approximately 10 mph (15 km/h) to 87 mph (140 km/h).  Against a pedestrian: Approximately 5 mph (7 km/h) to 40 mph (65 km/h).
N00577700073
When the FCM judges th
at a collision with
the vehicle or the pedest
rian straight-ahead is
imminent, the FCM will automatically applymoderate braking to warn the driver to apply the brakes immediately. If the FCM judges that the collision is highlyunavoidable, it will
automatically apply
emergency braking to reduce the severity of the collision and, if possible, to avoid the col- lision. When the FCM applies emergency braking, abuzzer sounds and a warn
ing message is dis-
played in the information screen of the multi- information display. The FCM braking function operates when the following vehicle speed:  Against a vehicle:
Approximately 3 mph
(5 km/h) to 50 mph (80 km/h) mph (5 km/h) to 40 mph (65 km/h)
Forward collision warning function

FCM braking function

WA R N I N G If the ASC is turned off, the FCM braking function will not operate. Refer to “Activestability control” on page 5-100. If the brake pedal is not depressed within 2 seconds after your vehicle has beenstopped by the FCM,
a warning buzzer
will sound and the brakes activated by the FCM will automatically be released.Apply the brakes as
necessary to keep
your vehicle stationary. The FCM will not activate and will not provide either warnin
g or braking in cer-
tain situations. Some of these include:• When the selector lever is in the “P”(PARK) or “R” (R
EVERSE) position.
• When an object other
than a vehicle or a
pedestrian is in front.• When the FCM has detected a problemin the system.• When a vehicle or a
pedestrian suddenly
cuts in front of your vehicle.
 The FCM may or may not detect a motor- cycle, bicycle or wall depending on the sit-uation. The FCM is not designed to detect these objects. The forward collision warning function and/or the FCM brakin
g function may not
activate in certain
situations. Some of
these include:• When a vehicle sudden
ly appears just in
front of your vehicle.• When a vehicle cuts
into your path at a
close distance.
BK0239700US.book 119 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Forward Collision Mitigation System (FCM) (if so equipped) 5-122 Features and controls
5
N00577800061
This switch is used to turn on or off the FCM and Ultrasonic misacc
eleration Mitigation
System, and also to select the distance which will trigger the forward collision warningfunction.
Every time the opera
tion mode is put in
“ON”, the FCM and Ultrasonic misaccelera- tion Mitigation System will automatically beturned on. To turn off the FCM and Ultrasonic misaccel- eration Mitigation System
, press and hold the
FCM and Ultrasonic misacceleration Mitiga- tion System switch.
The following message
and indicator will appear in the multi- information display.
To turn on the FCM and Ultrasonic misaccel- eration Mitigation Syst
em again, press and
hold the FCM and Ultrasonic misacceleration Mitigation System switch. The indicator will go off, and a curre
nt distance mode for
the forward collision warning will be shownin the multi-information display. The distance to the vehicle ahead which trig- gers the forward collision warnings can be selected from three levels, “FAR”, “MID- DLE” or “NEAR”.
FCM and Ultrasonic misaccel- eration Mitigation System ON/OFF switch

To turn on/off the FCM and Ultra- sonic misacceleration Mitigation System

NOTE
 When the FCM and Ultrasonic misaccelera- tion Mitigation System
ON/OFF switch is
held pressed to change the ON/OFF state ofthe FCM, the ON/OFF state of the Ultrasonic misacceleration Mitigation System is also changed at the same time.  The indicator is combined with the “Ultrasonic misacceleration Mitigation Sys- tem OFF” indicator.
To change forward collision warn- ing distance

BK0239700US.book 122 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Forward Collision Mitigation System (FCM) (if so equipped)
Features and controls 5-123
5
To change the distan
ce mode, push the FCM
and Ultrasonic misacc
eleration
Mitigation
System ON/OFF switch. Every time the switch is pushed, the
distance mode will be
switched. The selected distance mode isshown on the information screen of the multi- information display. When “FAR” is selected When “MIDDLE” is selected When “NEAR” is selected
N00593300035
When the FCM system determines that its performance has been degraded, the FCMwill become inoperative. This can occur when  Foreign objects, such as dirt, snow, ice, mist or dew condensation adhere to thewindshield of the sensor portion.  In adverse weather
conditions, such as
rain, snow, sand storms, etc. A front vehicle or an oncoming vehicle is splashing water, snow or dirt.
“DRIVER ASSISTANCE CAMERA BLOCKED” message will appear and the indicator will appear
on the information
screen of the multi-information display. When the sensor performance returns, the FCM functions will resume operation.If the message continue
s showing, there is a
possibility that the sensor has a malfunction. Contact an authorized Mitsubishi Motorsdealer for inspection of the sensor.
NOTE
 Actual distance which
triggers the forward
collision warnings will vary depending onyour vehicle speed a
nd the front vehicle
speed. The distance
will become longer
when the vehicle speeds are higher.  The distance which will trigger the FCM braking function cannot be adjusted.
When a problem is detected

NOTE
 The “DRIVER ASSISTANCE CAMERA BLOCKED” message
may temporarily
appear on the information screen when the sensor cannot detect a
vehicle, a pedestrian
or an object within range. This is not a mal- function. When a vehicle or an object comes within range, the FCM function will resumeand the message will go off.
BK0239700US.book 123 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Forward Collision Mitigation System (FCM) (if so equipped) 5-124 Features and controls
5
If the system becomes temporarily unavail- able for some reason, the following message may appear. The indicator will appear on the informa- tion screen of the mu
lti-information display
and the FCM will automa
tically be turned off.
If the message continues
showing, there is a
possibility that the FCM has a malfunction.Contact an authoriz
ed Mitsubishi Motors
dealer for inspection of the system.
If the system becomes temporarily unavail- able due to the high or low temperature of thesensor, the following
message will appear.
The indicator will appear on the informa- tion screen of the multi-information display and the FCM will automatically be turned off.After the temperature of
the sensor has been
in range, the system will automatically return to operation.If the message continues showing, there is a possibility that the
FCM has a malfunction.
Contact an authorized Mitsubishi Motors dealer for inspection of the sensor.
If the FCM detects a malfunction in the sys- tem, either of the following messages will appear, the indicator will appear on the information screen of the multi-information display and the FCM will automatically be turned off.If the message remains even after the opera- tion mode is put in “OFF” and then turned back to “ON”, please
contact your authorized
Mitsubishi Motors dealer.
 The “DRIVER ASSI
STANCE CAMERA
BLOCKED” message
may appear on the
information screen when driving on a non-busy road with a few vehicles and obstacles in front.NOTE
BK0239700US.book 124 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Ultrasonic misacceleration Miti
gation System (if so equipped) Features and controls 5-127
5
N00586500035
The Ultrasonic misacceleration Mitigation System operates to prev
ent sudden starts and mitigate
collision-caused damage by supp
ressing the
engine output for up to approxima
tely 5 seconds when the system
detects a vehicle or
obstacle up to approxima
tely 157 inches (4
m) in front of
and behind your vehicle and the accelerator pe
dal has been depressed too a
ggressively for safe operati
on. This system will only
operate when the
vehicle is at a stop or is moving forward
or backward at less than 6 mph (10 km/h).
The Ultrasonic misacceleration Mitigation System incorporat
es 8 ultrasonic sensors (A) on
the front and rear bumpers.
When the Ultrasonic misacceleration Mitigation System operates, th
e warning display will appear
on the information screen of th
e multi informa-
tion display, and a buzze
r will sound intermittently.
Ultrasonic misacceleration Mitigation System
(if so equipped)
BK0239700US.book 127 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Ultrasonic misacceleration Miti
gation System (if so equipped)
5
On vehicles equipped with the Fo
rward Collision Mitigation System (FCM), when th
e FCM system is turned on/off, the Ultrasonic m
isaccelera-
tion Mitigation System is also turned on/off simultaneously.
Situation
Operation display
Buzzer
When an obstacle is detected in
front of your vehicle with the
selector lever in the “D” (D
RIVE), “Ds” (DOWNSHIFT &
SPORTY DRIVING), “L” (LOW) or
in the sport mode, if the
accelerator pedal is depressed t
oo aggressively, the engine output
will be suppressed for up to
approximately 5 seconds.

*UMS: Ultrasonic misacceleration Mitigation System
Intermittent beeping
When an obstacle is de
tected behind your vehicle with the selec-
tor lever in “R” (REVERSE), if the accelerator pedal is depressed too aggressively, the engine out
put will be suppressed for up to
approximately 5 seconds.
WA R N I N G  Before using the Ultrasonic misaccelera- tion Mitigation System, read this entire section to fully understand the limitations of this system. Failure to follow instruc-tions could result in an accident.
 Do not rely solely on the Ultrasonic misac- celeration Mitigation Sy
stem. It is never a
substitute for your safe and careful driv- ing.WA R N I N G
BK0239700US.book 128 ページ ２０１６年６月１６日　木曜日　午前１０時５８分
