2017 INFINITI QX60 HYBRID Owner's Manual

10TUNE/FOLDER AUDIOknob
Bass, treble, balance and fade can also be
adjusted by pushing this button and turning
the knob to select the item to adjust.
11Radio memory buttons Up to six preferred stations can be regis-
tered in the preset list for each band.
Steering Wheel Switch for Audio
Control
The audio system can be operated using the
controls on the steering wheel.
1.
Tuning switch/ENTER button
2.
(back) switch
3. SOURCE switch
4. Volume control switch
SOURCE switch
With the ignition switch in the ACC or ON posi-
tion, push the SOURCE switch to turn the audio
system on. Push the SOURCE switch to change the mode.
Volume control switch
Push the volume control switch to increase or
decrease the volume.
Tuning switch/ENTER
button
While the display is showing a map (if so
equipped) , status, or audio screen, tilt the Tuning
switch upward or downward to select a station,
track, or folder. For most audio sources, tilting the
switch up/down for more than 1.5 seconds pro-
vides a different function than tilting up/down for
less than 1.5 seconds.
AM and FM
● Tilt up/down for less than 1.5 seconds to
increase or decrease the preset station.
● Tilt up/down for more than 1.5 seconds to
seek up or down to the next station.
XM ● Tilt up/down for less than 1.5 seconds to
increase or decrease the preset channel.
● Tilt up/down for more than 1.5 seconds to
fast tune the channels.
LHA3170
4-72Monitor, climate, audio, phone and voice recognition systems

iPod®● Tilt up/down for less than 1.5 seconds to
increase or decrease the track number.
CD ● Tilt up/down for less than 1.5 seconds to
increase or decrease the track number.
● Tilt up/down for more than 1.5 seconds to
increase or decrease the folder number (if
playing compressed audio files) .
DVD (if so equipped) ● Tilt up/down for less than 1.5 seconds to
increase or decrease the track number.
● Tilt up/down for more than 1.5 seconds to
increase or decrease the title number.
USB ● Tilt up/down for less than 1.5 seconds to
increase or decrease the track number.
● Tilt up/down for more than 1.5 seconds to
increase or decrease the folder number.
Bluetooth® Audio ● Tilt up/down for less than 1.5 seconds to
increase or decrease the track number.
● Tilt up/down for more than 1.5 seconds to
increase or decrease the folder number.(back) switch
Press the
(back) switch to return to the
previous screen or cancel the current selection.
NOTE:
You are unable to operate the display of the
Infiniti InTouch
TMusing the buttons on the
steering switch whenever the meter shows
the setting display.
ANTENNA
The vehicle is equipped with a shark fin antenna
and an antenna pattern is printed inside the rear
window.
CAUTION
● Do not place metalized film near the
rear window glass or attach any metal
parts to it. This may cause poor recep-
tion or noise.
● When cleaning the inside of the rear
window, be careful not to scratch or
damage the rear window antenna.
Lightly wipe along the antenna with a
dampened soft cloth.
AUDIO MAIN OPERATION
Turning audio system on/off
The ignition switch must be in the ACC or ON
position to turn on the audio system. Push the
VOL/ON•OFF knob to turn on the last audio
source which was playing immediately before the
system was turned off. To turn off the audio
system, push the VOL/ON•OFFknob again.
Displaying Audio screen
Push theAUDIObutton on the control panel to
display the current audio screen.
Selecting audio source
1. Turn on the audio source menu screen by touching the “Source” key on the upper left
corner of the audio screen.
2. Select an item from the audio source menu screen.
● Pushing the RADIO,DISC,MEDIA or
SOURCE button on the steering switch can
also change the audio source. For additional
information, refer to “Names and functions of
audio control buttons” in this section.
Monitor, climate, audio, phone and voice recognition systems4-73

●If the audio system has been turned off while
one of the audio sources was playing, turn-
ing the audio system back on will play the
audio source that was playing when the sys-
tem was turned off.
● The audio source can also be changed with
the source bar on top of the audio screen.
Audio source bar
The audio source can be changed with the
source bar on top of the audio screen. The
source bar display can be turned on/off.
Turning source bar on/off
You can select whether the source bar on top of
the audio screens is displayed or not.1. Touch the “Source” key on the upper left corner of the audio screen.
2. Touch the “Show Source Bar” key to turn the indicator on/off. Editing source bar
The audio sources to be displayed on the source
bar can be changed.
1. Touch the “Source” key on the upper left corner of the audio screen.
2. Touch the “Edit Source Bar” key.
3. Touch one of the keys on the source bar and then touch one of the audio sources from the
source list to register the audio source in the
source bar.
JVH1501M
4-74Monitor, climate, audio, phone and voice recognition systems

RADIO
How to view radio operation screen
The radio screen can be viewed and operated on
the display.
1“Control” key: Touch to display the control
screen. For additional information, refer to
“Radio controls” in this section.
2“Source” key: Touch to switch to the source
select screen. For additional information, re-
fer to “Selecting audio source” in this sec-
tion.
3HD Radio reception status indicator (for AM
and FM):
The icon is displayed when the HD Radio
digital signal is received. The icon flashes
when the radio is acquiring the digital signal
but the sound output is not yet in the HD
mode.
4Radio band indicator: The currently selected
radio band (AM, FM or SXM) is displayed.
5Reception information display: Reception in-
formation available at the time such as fre-
quency, station/channel name, etc. are dis-
played.
On the SXM screen, touch the area to dis-
play the category list.
6Radio mode indicator: The current radio
mode is displayed.
736 stations/channels can be registered in
the preset list.
For additional information, refer to “Preset-
ting” in this section.
JVH1502M
Monitor, climate, audio, phone and voice recognition systems4-75

NOTE:
HD Radio reception needs to be activated
to receive HD Radio broadcasts. This en-
ables you to receive radio broadcasts digi-
tally (where available) , providing a better
quality sound with clear reception. When
this feature is not activated or HD Radio
broadcasts are not available, you will re-
ceive analog radio (AM/FM broadcasts) .
Radio source control
There are 2 elements used in the preset list area
that are associated with radio source:
1The highlighted area can be shifted using the
center dial or slide switch.
2(With triangle) Indicator of current selected
preset station.
Radio operation
Radio activation and band selection
Push the RADIO button or select the preferred
radio band (AM, FM or SXM) from the audio
source list to turn on the radio. Each time the RADIO button is pushed, the radio band will
change. For additional information, refer to “Se-
lecting audio source” in this section.
NOTE:
When the stereo broadcast signal is weak,
the radio will automatically change from
stereo to monaural reception.
Seeking stations/channels
AM and FM radio
Push the SEEK•CAT•TRACK button to tune from
low to high or high to low frequencies and to stop
at the next broadcasting station.
SiriusXM Satellite Radio
Push the SEEK•CAT•TRACK button to tune to
the first channel of the next or previous category.
Scan tuning
To tune the stations/channels, touch the “Con-
trol” key on the display and touch the “Scan” key.
The stations will be turned from low to high
frequencies and stop at each broadcasting sta-
tion for 5 seconds. Touching the “Scan” key again
during this 5 second period will stop scan tuning
and the radio will remain tuned to that station.
Pushing the SCAN button can also scan tune.
JVH1503M
4-76Monitor, climate, audio, phone and voice recognition systems

Presetting
Up to 36 stations/channels can be registered for
AM, FM or SXM in the preset list.1. Select a radio band (AM, FM or SXM)
2. Tune to the station/channel you wish to store in the preset list.
3. Touch and hold one of the preset numbers in the preset list.
NOTE:
Only 1 to 6 can store using radio memory
buttons. Push and hold the desired station/channel
preset button (1 – 6) .
4. The information such as frequency (AM/FM) , channel number (SXM) , etc. will
be displayed on the preset list.
To change the preset station/channel, touch and
hold one of the preset numbers. You can select
whether to change the station/channel or to de-
lete the preset setting.
Alert notification (SXM only)
Favorite artists and songs can be registered to
receive an alert notice when a song of the regis-
tered conditions is on the radio. To tune to the respective channel, touch the “Listen to be con-
sistent” key. The alert can be ignored by touching
the “Cancel” key.
Satellite Radio:
● The satellite mode requires an active
SiriusXM Satellite Radio subscription. The
satellite service is available only to those at
least 18 and older in the 48 contiguous
United States.
● It may take some time to receive the activa-
tion signal after the initiation of the SiriusXM
Satellite Radio subscription. After receiving
the activation signal, an available channel list
will automatically be updated in the radio.
Switch the Ignition switch from LOCK to
ACC to update the SiriusXM channel list.
Radio controls
Touch the “Control” key on the AM, FM or SXM
screen to display the control screen.
The following items are available:
FM/AM
● “Station list” key
Touch to display the available station list.
While listening to FM radio, Auto Update is
not preformed. ●
“Scan” key
Touch to scan tune the stations. For addi-
tional information, refer to “Radio operation”
in this section.
● “HD Radio mode” key
When this item is turned on, the analog and
the digital reception switches automatically.
When this item is turned off, the reception is
fixed in the analog mode.
● “HD Radio Info” key
Touch to display the HD Radio Information
such as name of song, artist and album.
This item is available when “RDS-Info” key is
not active.
● “Tag” key (HD Radio Broadcasts only)
Touch to register the tag information for
ITunes® Tagging. If an iPod® is plugged in
after the registration, the tag information can
be stored in an iPod® and be used to pur-
chase the song via ITunes.
● “RDS-Info” key (FM only)
Touch to display the RDS information.
This item is available only when the “HD
Radio Info” key is not active.
Monitor, climate, audio, phone and voice recognition systems4-77

SXM● “Categories” key
Touch to display the categories list.
● “Direct Tune” key
Touch to display the keypad to enter the
frequency and directly tune to the channel.
● “Scan” key
Touch to scan tune the channels.
For additional information refer to, “Radio
operation” in this section.
● “Instant replay” key
Up to 30 minutes of the broadcast of the
channel that has been tuned in to can be
replayed.
Touch to select from “
”, “”,
“
”, “” and “”.
● “Tag” key
Touch to register the tag information for
iTunes® tagging. If an iPod® is plugged in
after the registration, the tag information can
be stored in an iPod® and be used to pur-
chase the song via ITunes®. ●
“Other” key — “Artist Alert History” key
Touch to set a favorite artists alert notifica-
tion. Up to 8 artists can be registered. While
a song of your favorite artists is playing,
touch the list and touch the “Add/Update”
key. To receive the alert notification, select
the “Notify Alert ON” key.
● “Other” key — “Song Alert History” key
Touch to set a favorite songs alert notifica-
tion. Up to 8 songs can be registered. While
a song of your favorite artists is playing,
touch the list and touch the “Add/Update”
key. To receive the alert notification, select
the “Notify Alert ON” key.
● “Other” key — “Customize Channel List” key
Touch to customize the channel list. Only
selected channels will be tuned in when you
seek or scan the channels. You can select
each item or touch the “Select/Deselect All”
key.
● “Other” key — “Artist Alert History” key
Touch to display the artist list for an alert
notice.
● “Other” key — “Song Alert History” key
Touch to display the song list for an alert
notice. ●
“Other” key — “Favorite Alert Settings” key
Touch to turn on/off the alert notice for the
registered favorite artists and songs.
● “Other” key — “Channel Locking Settings”
key
Touch to select or unselect the channel that
you wish to lock out. A passcode is required
to change the settings. The default pass-
code is 1234.
4-78Monitor, climate, audio, phone and voice recognition systems

COMPACT DISC (CD) PLAYERHow to view CD operation screen
1“Source” key
Touch to switch to the source list screen. For
additional information, refer to “Selecting au-
dio source” in this section.
2Track information
Track information such as the song title, art-
ist name, and album name is displayed.
3Audio source indicator
Indicates that CD is currently selected.
4Play time
The play time of the track is displayed.
5“Scan” key
Touch to play the first 10 seconds of the
tracks. Touch again to stop scanning.
6Track number
This indicates the current track number and
the total number of tracks.
7CD menu
CD menu items are displayed. Touch an icon
to display the list or to change the setting.
● “Track” key
● “Folder” key (for MP3, WMA, AAC)
● “Play Mode” key
8Play Mode indicator
This indicates the current play mode. Touch
to change the play mode.
9Folder number (for MP3, WMA, AAC)
This indicates the folder number when a CD
with compressed audio files is loaded.
JVH1504M
Monitor, climate, audio, phone and voice recognition systems4-79
