2017 DODGE DURANGO ESP

Special Care
•If you drive on salted or dusty roads or if you drive near
the ocean, hose off the undercarriage at least once a
month.
• It is important that the drain holes in the lower edges of
the doors, rocker panels, and trunk be kept clear and
open.
• If you detect any stone chips or scratches in the paint,
touch them up immediately. The cost of such repairs is
considered the responsibility of the owner.
• If your vehicle is damaged due to a collision or similar
cause that destroys the paint and protective coating,
have your vehicle repaired as soon as possible. The cost
of such repairs is considered the responsibility of the
owner.
• If you carry special cargo such as chemicals, fertilizers,
de-icer salt, etc., be sure that such materials are well
packaged and sealed.
• If a lot of driving is done on gravel roads, consider mud
or stone shields behind each wheel.
• Use MOPAR Touch Up Paint on scratches as soon as
possible. Your authorized dealer has touch up paint to
match the color of your vehicle.
Wheel And Wheel Trim Care
• All wheels and wheel trim, especially aluminum and
chrome plated wheels, should be cleaned regularly with
a mild soap and water to prevent corrosion.
• To remove heavy soil and/or excessive brake dust, use
MOPAR Wheel Cleaner.
NOTE: If your vehicle is equipped with Dark Vapor or
Black Satin Chrome wheels DO NOT USE wheel cleaners,
abrasives or polishing compounds. They will permanently
damage this finish and such damage is not covered by the
New Vehicle Limited Warranty. USE ONLY MILD SOAP
AND WATER WITH A SOFT CLOTH. Used on a regular
basis this is all that is required to maintain this finish.
CAUTION!
Do not use scouring pads, steel wool, a bristle brush, or
metal polishes. Do not use oven cleaner. These prod-
ucts may damage the wheel’s protective finish. Avoid
automatic car washes that use acidic solutions or harsh
brushes that may damage the wheel’s protective finish.
Only MOPAR Wheel Cleaner or equivalent is recom-
mended.
530 MAINTAINING YOUR VEHICLE

Stain Repel Fabric Cleaning Procedure —
If Equipped
Stain Repel seats may be cleaned in the following manner:
•Remove as much of the stain as possible by blotting with
a clean, dry towel.
• Blot any remaining stain with a clean, damp towel.
• For tough stains, apply MOPAR Total Clean, or a mild
soap solution to a clean, damp cloth and remove stain.
Use a fresh, damp towel to remove soap residue.
• For grease stains, apply MOPAR Multi-Purpose Cleaner
to a clean, damp cloth and remove stain. Use a fresh,
damp towel to remove soap residue.
• Do not use any harsh solvents or any other form of
protectants on Stain Repel products.
Interior Care
Use MOPAR Total Clean to clean fabric upholstery and
carpeting.
Use MOPAR Total Clean to clean vinyl upholstery.
MOPAR Total Clean is specifically recommended for
leather upholstery. Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt can
act as an abrasive and damage the leather upholstery and
should be removed promptly with a damp cloth. Stubborn
soils can be removed easily with a soft cloth and MOPAR
Total Clean. Care should be taken to avoid soaking your
leather upholstery with any liquid. Please do not use
polishes, oils, cleaning fluids, solvents, detergents, or
ammonia-based cleaners to clean your leather upholstery.
Application of a leather conditioner is not required to
maintain the original condition.
WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in closed
areas they may cause respiratory harm.
CAUTION!
Direct contact of air fresheners, insect repellents, sun-
tan lotions, or hand sanitizers to the plastic, painted, or
decorated surfaces of the interior may cause permanent
damage. Wipe away immediately.
7
MAINTAINING YOUR VEHICLE 531

Power Distribution Center
The Power Distribution Center is located in the engine
compartment. This center contains cartridge fuses, micro
fuses, relays, and circuit breakers. A description of each
fuse and component may be stamped on the inside cover,
otherwise the cavity number of each fuse is stamped on the
inside cover that corresponds to the following chart.
CavityCartridge Fuse Micro Fuse Description
F03 60 Amp Yellow –Radiator Fan
F05 40 Amp Green –Compressor for Air Suspension - If Equipped
F06 40 Amp Green –Anti-lock Brakes/Electronic Stability Control
Pump
F07 30 Amp Pink –Starter Solenoid
F09 30 Amp Pink –Diesel Fuel Heater (Diesel engine only) /
Brake Vacuum Pump
F10 40 Amp Green –Body Controller / Exterior Lighting #2
F11 30 Amp Pink –Trailer Tow Electric Brake - If Equipped
Power Distribution Center
534 MAINTAINING YOUR VEHICLE

Customer Assistance For The Hearing Or Speech
Impaired (TDD/TTY)
To assist customers who have hearing difficulties, the manu-
facturer has installed special TDD (Telecommunication De-
vices for the Deaf) equipment at its customer center. Any
hearing or speech impaired customer, who has access to a
TDD or a conventional teletypewriter (TTY) in the United
States, can communicate with the manufacturer by dialing
1-800-380-CHRY.
Canadian residents with hearing difficulties that require
assistance can use the special needs relay service offered by
Bell Canada. For TTY teletypewriter users, dial 711 and for
Voice callers, dial 1-800-855-0511 to connect with a Bell
Relay Service operator.
Service Contract
You may have purchased a service contract for a vehicle to
help protect you from the high cost of unexpected repairs
after the manufacturer’s New Vehicle Limited Warranty
expires. The manufacturer stands behind only the manu-
facturer’s service contracts. If you purchased a manufac-
turer’s service contract, you will receive Plan Provisions
and an Owner Identification Card in the mail within three
weeks of the vehicle delivery date. If you have any
questions about the service contract, call the manufactur-
er’s Service Contract National Customer Hotline at 1-800-
521-9922 (Canadian residents, call (800) 465-2001 English /
(800) 387-9983 French).
The manufacturer will not stand behind any service con-
tract that is not the manufacturer’s service contract. It is not
responsible for any service contract other than the manu-
facturer’s service contract. If you purchased a service
contract that is not a manufacturer’s service contract, and
you require service after the manufacturer’s New Vehicle
Limited Warranty expires, please refer to the contract
documents, and contact the person listed in those docu-
ments.
560 IF YOU NEED CONSUMER ASSISTANCE

Traction Grades
The Traction grades, from highest to lowest, are AA, A, B,
and C. These grades represent the tire’s ability to stop on
wet pavement, as measured under controlled conditions on
specified government test surfaces of asphalt and concrete.
A tire marked C may have poor traction performance.
WARNING!
The traction grade assigned to this tire is based on
straight-ahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or peak
traction characteristics.
Temperature Grades
The temperature grades are A (the highest), B, and C,
representing the tire’s resistance to the generation of heat
and its ability to dissipate heat, when tested under con-
trolled conditions on a specified indoor laboratory test
wheel. Sustained high temperature can cause the material
of the tire to degenerate and reduce tire life, and excessive
temperature can lead to sudden tire failure. The grade C
corresponds to a level of performance, which all passenger
vehicle tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A represent higher
levels of performance on the laboratory test wheel, than the
minimum required by law.
WARNING!
The temperature grade for this tire is established for a
tire that is properly inflated and not overloaded. Ex-
cessive speed, under-inflation, or excessive loading,
either separately or in combination, can cause heat
buildup and possible tire failure.
564 IF YOU NEED CONSUMER ASSISTANCE

About Your Brakes........................ .406
Adaptive Cruise Control (ACC) (Cruise Control) . . . .153
Adding Engine Coolant (Antifreeze) .............522
Adding Fuel ............................. .449
Additives, Fuel ........................... .446
Adjust Forward ............................110,111
Rearward ...........................110,111
Air Bag Air Bag Operation .........................53
Air Bag Warning Light .....................60
Driver Knee Air Bag .......................54
Enhanced Accident Response ..............60, 499
Event Data Recorder (EDR) .................499
If A Deployment Occurs ....................59
Knee Impact Bolsters .......................54
Maintaining Your Air Bag System ..............62
Redundant Air Bag Warning Light .............61
Side Air Bags ............................55
Transporting Pets .........................83
Air Bag Light ....................... .60, 86, 238
Air Bag Maintenance .........................62
Air Cleaner, Engine (Engine Air Cleaner Filter) ......511
Air Conditioner Maintenance ..................512
Air Conditioning Filter ...................351, 513 Air Conditioning, Operating Tips
............350, 352
Air Conditioning, Rear Zone ..................343
Air Conditioning Refrigerant ...............512, 513
Air Conditioning System ..................346, 512
Air Pressure, Tires ......................... .428
Alarm Arm The System ..........................16
Disarm The System ........................17
Alarm, Panic ...............................20
Alarm (Security Alarm) ....................16, 240
Alarm System (Security Alarm) .................16
All Wheel Drive (AWD) ..................... .395
Alterations/Modifications, Vehicle ................8
Antifreeze (Engine Coolant) ................521, 545
Disposal .............................. .523
Anti-Lock Brake System (ABS) .................407
Anti-Lock Warning Light .....................250
Appearance Care .......................... .528
Arming
System (Security Alarm) ................16
Assist, Hill Start .......................... .409
Auto Down Power Windows ...................34
Automatic Headlights ...................... .136
Automatic High Beams ..................... .136
Automatic Temperature Control (ATC) ...........346
Automatic Transmission ..................388, 528
566 INDEX

Jump Starting.......................... .488
Oil .............................. .508, 545
Oil Filler Cap .......................... .510
Oil Filter ...............................511
Oil Selection .....................509, 545, 547
Overheating ........................... .474
Starting .............................. .379
Engine Oil Viscosity ........................ .510
Engine Oil Viscosity Chart ....................510
Enhanced Accident Response Feature ..........60, 499
Entry System, Illuminated .....................18
Ethanol ................................. .446
Exhaust Gas Caution .....................85, 448
Exhaust System ........................ .85, 519
Exterior Lights ......................... .88, 540
Filters Air Cleaner .............................511
Air Conditioning .....................351, 513
Engine Oil .............................511
Engine Oil Disposal ...................... .510
Flashers ................................ .474
Hazard Warning ........................ .474
Turn Signal ....................88, 254, 543, 544
Flooded Engine Starting ..................... .382Fluid Capacities
........................... .545
Fluid Leaks ...............................88
Fluid Level Checks Automatic Transmission ....................528
Brake ................................ .525
Engine Oil ............................ .508
Fluids .................................. .549
Fluids, Lubricants And Genuine Parts ............547
Fog Lights .............................. .544
Fog Light Service .......................... .544
Folding Rear Seat ......................... .123
Forward Collision Warning ....................174
Four-Way Hazard Flasher .....................474
Freeing A Stuck Vehicle ..................... .491
Fr
ont Axle (Differential) ..................... .526
Fuel ................................... .444
Adding .............................. .449
Additives ............................. .446
Clean Air ............................. .445
Economy Mode ......................... .387
Ethanol .............................. .446
Gasoline .............................. .444
Light ................................ .250
Materials Added ........................ .446
Methanol ............................. .446
570 INDEX
