When a device does not work, you must check the electri-
cal circuit inside the fuse for a break/melt.
Also, please be aware that when using power outlets for
extended periods of time with the vehicle off may result in
vehicle battery discharge.Fuse Location
The fuses are grouped into four controllers located in the
engine compartment.
Underhood Fuses
The Power Distribution Center is located in the engine
compartment near the battery. This center contains car-
tridge fuses, mini-fuses, micro-fuses, circuit breakers and
relays. A label that identifies each component is printed on
the inside of the cover.
Blade Fuses
1 — Electrical Circuit
2 — Blade Fuse With Good Electrical Circuit
3 — Blade Fuse With Bad Electrical Circuit
Power Distribution Center
7
IN CASE OF EMERGENCY 399

CavityCartridge Fuse Blade FuseDescription
F06 –15 Amp Blue Low Temp Active Pump
F07 –25 Amp Clear Ignition Coil/Fuel Injector
F08 –25 Amp Clear Amplifier / ANC
F09 ––Not Used
F10 –15 Amp Blue High Temp Aux Pump &
HV Electric Coolant Htr Enable
F11 –15 Amp Blue ELCM / FTIV
F12 –5 Amp Tan Battery Sensor (IBS)
F13 ––Not Used
F14A –10 Amp Red Media Hub 1, 2, 3
F14B – Pwr Lumbar Switch
F15 40 Amp Green –Power Locks
F16 –20 Amp Yellow ECM
F17 ––Not Used
F18 40 Amp Green –CBC Feed #4 (Exterior
Lights #1)
F19 ––Not Used
F20 –10 Amp RedLow Temp Passive Pump
F21 20 Amp Blue –PIM - Park PAWL Motor
400 IN CASE OF EMERGENCY

CavityCartridge Fuse Blade FuseDescription
F22 ––Not Used
F23 ––Not used
F24 –20 Amp Yellow RR Wiper
F25A –10 Amp Red Handsfree (Lt & Rt Rear
Door Release Module)
F25B – Active Grill Shutter
F26 40 Amp Green –Front HVAC Blower Motor
F27 25 Amp Clear –RR Slide Door Module
F28A –10 Amp Red Diagnostic Port
F28B – USB + AUX (UCI) Port (IP)
/ Video USB Port
F29 ––Not Used
F30A –10 Amp Red ECM / PIM
F30B – Not Used
F31 –10 Amp Red 3, 4 way Valves
F32 20 Amp Blue –ECM
F33 30 Amp Pink –Power Liftgate Module
F34 25 Amp Clear –Rear Door Control
Module - Lt
F35 25 Amp Clear –Sunroof Control Module
7
IN CASE OF EMERGENCY 401

CavityCartridge Fuse Blade FuseDescription
F36 ––Not Used
F37 40 Amp Green –CBC Feed #4 (Exterior
Lighting / PCM #2)
F38 ––Not Used
F39 25 Amp Clear –Rear HVAC Blower Motor
F40 20 Amp Blue –Trans Oil Pump
F41 ––Not Used
F42 ––Not Used
F43 –20 Amp Yellow Fuel Pump Motor
F44 30 Amp Pink –CBC Feed #1 (Interior
Lights)
F45 30 Amp Pink –Power Inverter
F46 30 Amp Pink –Driver Door Module
F47 30 Amp Pink –Passenger Door Module
F48 40 Amp Green –EBCM Motor
F49 25 Amp Clear –Rear Sliding Door
Module - Lt
F50 25 Amp Clear –Rear Door Control
Module - Rt
F51 30 Amp Pink –Front Wiper
402 IN CASE OF EMERGENCY

CavityCartridge Fuse Blade FuseDescription
F52 ––Not Used
F53 ––Not Used
F54 40 Amp Green –ESP-ECU And Valves
F55A –15 Amp Blue RF Hub/KIN/ESL - BUX
Only
F55B – DVD / VRM
F56A –10 Amp Red OCM / ESL
F56B – ESC - Electric Stability
Control / ESP / EBCM
F57 –20 Amp Yellow PIM - Main Power Supply
F58 ––Not Used
F59 ––Not Used
F60 –20 Amp Yellow Rear Cargo APO
F61 ––Not Used
F62 –20 Amp Yellow PIM - Redundant Main
Power Supply
F63 ––Not Used
F64 ––Not Used
F65 ––Not Used
7
IN CASE OF EMERGENCY 403

CavityCartridge Fuse Blade FuseDescription
F66 –15 Amp Blue
Instrument Panel Cluster
(IPC)
F67 –10 Amp RedHALF / PTS / Drivers Assist
System Module (DASM)
F68 ––Not Used
F69A –15 Amp Blue BPCM
F69B – BPCM (Redundant)
F70 –5 Amp Tan EAC
F71 –20 Amp Yellow Horn
F72 ––Not Used
F73 30 Amp Pink –Rear Defroster (EBL)
F74 ––Not Used
F75 –5 Amp Tan
Overhead Console / Rear ICS
F76 –20 Amp Yellow Uconnect/DCSD/
Telematics
F77A –10 Amp Red Rear Entertainment / Me-
dia Hub
F77B – Sunroof / Rain Snsr /
ECM / Pass WDO Sw En- able / EC Mirror / PIM
404 IN CASE OF EMERGENCY

CavityCartridge Fuse Blade FuseDescription
F78A –15 Amp Blue TCM / E-Shifter
F78B – Instrument Cluster
F79A –10 Amp Red ICS / Frt & Rr HVAC /
EPB Sw / SCCM
F79B – Not Used
F80 –5 Amp Tan OBCM
F81 –5 Amp Tan APM
F82 ––Not Used
F83 30 Amp Pink –Trans Oil Pump 1 - Protect
For
F84 ––Not Used
F85 –20 Amp Yellow Cigar Lighter
F86 ––Not Used
F87 ––Not Used
F88 –20 Amp Yellow Front Heated Seats
F89 –20 Amp Yellow Rear Heated Seats
F90 –5 Amp Tan EBCM - ECU
F91 –15 Amp Blue Front Ventilated Seats/
Heated Steering Wheel
F92A ––Not Used
7
IN CASE OF EMERGENCY 405

CavityCartridge Fuse Blade FuseDescription
F92B ––Not Used
F93 ––Not Used
F94 40 Amp Green –ESP - Motor Pump
F95A –10 Amp Red USB Charge Only Port
F95B – Selectable Fuse Location
F96 –10 Amp RedOccupant Restraint Con-
troller (ORC) (Airbag)
F97 –10 Amp RedOccupant Restraint Con-
troller (ORC) (Airbag)
F98 ––Not Used
F99 ––Not Used
F100A –10 Amp Red QVPM / AHLM
F100B – Rr Camera / LBSS / RBSS
/ CVPM / Humidity Snsr / In Car Temp Snsr
TIRE SERVICE KIT — IF EQUIPPED
Your vehicle may be equipped with a Tire Service Kit.
Small punctures up to 1/4 inch (6 mm) in the tire tread can
be sealed with Tire Service Kit. Foreign objects (e.g., screws
or nails) should not be removed from the tire. Tire Service Kit can be used in outside temperatures down to approxi-
mately -4°F (-20°C). This kit will provide a temporary tire
seal, allowing you to drive your vehicle up to 100 miles
(160 km) with a maximum speed of 50 mph (80 km/h).
