Page 249 of 289
Side Lights/Daytime Running Lights (DRL)
These are LEDs. For the replacement, contact the your
authorized dealer.
Low/High Beam Bi-Halogen Headlights
To change the bulb, proceed as follows:
1. Turn the steering wheel completely.
2. Open the protective flap by rotating the screw.3. Remove protective cover from headlamp assembly.
1 — Direction Indicator Bulb Protective Flap
2 — Headlamp Bulb Protective Flap
Protective Cover
7
MAINTAINING YOUR VEHICLE 247
Page 250 of 289
4. Remove the electric connector (1) and then rotate thebulb holder (2) clockwise and remove it.
5. Extract the bulb and replace it.
6. Refit the new bulb, making sure that it is locked correctly, and reconnect the electrical connector.
7. Reinstall protective cover in the headlamp assembly and close the protective flap.Low/High Beam HID & LED Headlights
For the replacement, contact the your authorized dealer.
Direction Indicators
Front:
1. Turn the steering wheel completely.
2. Open the protective flap by rotating the screw.
1 — Electrical Connector
2 — Bulb Holder
1 — Direction Indicator Bulb Protective Flap
2 — Headlamp Bulb Protective Flap
248 MAINTAINING YOUR VEHICLE
Page 251 of 289
3. Remove protective cover from headlamp assembly.
4. Rotate the bulb holder counterclockwise and removeit.
5. Rotate the bulb assembly counter clockwise to re- move from bulb holder.
6. Install the new bulb, making sure that it is locked in correctly, and reinstall into headlamp assembly.
7. Reinstall protective cover in the headlamp assembly and close the protective flap. Side:
1. Adjust the lens in the point shown in to compress the
retaining clip, then pull the cluster outwards.
2. Turn the bulb holder counterclockwise, remove the bulb and replace it.
3. Install the bulb holder in the lens and turn it clock- wise.
4. Install the cluster making sure that the internal clip clicks into position.
Protective Cover
1 — Lens
2 — Bulb Holder
7
MAINTAINING YOUR VEHICLE 249
Page 252 of 289
Front Side Marker
To change the bulb, proceed as follows:
1. Turn the front wheels to gain access and then removethe fastener from the inner wheel liner. 2. Fold back wheel liner door to access bulb housing.
Fastener Location
Bulb Housing Location
250 MAINTAINING YOUR VEHICLE
Page 253 of 289
3. Remove bulb from bulb housing then remove andreplace bulb and reinstall.
Rear Light Clusters
These contain the bulbs for the side lights, direction
indicators and brake lights.
Direction Indicators
To change the bulb, proceed as follows:
1. Remove the protective cap (one for each side) on theside cover of the luggage compartment.
Front Side Marker Bulb
First Protective Cap
7
MAINTAINING YOUR VEHICLE 251
Page 254 of 289
2. Remove the second protective cap insert a handinside the opening.
3. Rotate clockwise to remove the bulb holder remove the bulb from the bulb holder.
4.
Install the bulb by pressing it into bulb holder then turn
install the bulb holder and turn it counterclockwise.
5. Install the previously removed protective caps.
Tail Lights/Brake Lights
These are LEDs. For the replacement, contact the your
local dealer.
Reversing Light
WARNING!
The reversing light are located close to the exhaust
pipes; take the utmost care not to get burnt during
the bulb replacement.
To replace the reversing lights turn the bulb holder
counterclockwise, remove the bulb and replace it.
Second Protective Cap
1 — Reverse Light Location
2 — Reverse Light Location
252 MAINTAINING YOUR VEHICLE
Page 255 of 289
Third Brake Lights
These are LEDs. For the replacement, contact your local
dealer.
License Plate Lights
To replace the bulbs proceed as follows:
1. Position the lens in the point shown laterally tocompress the retaining clip, then pull the license
plate light cluster out.
Reversing Light Bulb Holder
License Plate Lamp Removal
7
MAINTAINING YOUR VEHICLE 253
Page 256 of 289
2. Turn bulb holder (1) counterclockwise, remove bulb(2) and replace it.
Roof Light
To change the bulb, proceed as follows:
1. Remove roof light working at the points indicated bythe arrows. 2. Open protective flap (2) and replace bulb (1), releas-
ing it from the side contacts. Make sure that the new
bulb is correctly secured between the contacts.
1 — Bulb Holder
2 — Bulb
Roof Light
254 MAINTAINING YOUR VEHICLE
