2016 VAUXHALL MOVANO_B Infotainment system

Phone137CD35 BT USB - Receiving calls
To accept the call, briefly press 7 (on
the steering column controls).
To reject the call: ● press and hold 8 (on the steering
column controls), or
● select Refuse in the display (by
turning and pressing the central
rotary knob)
When receiving a call, the caller
number may be shown on the
Infotainment system display screen. If
the number is stored in the system
memory, the name is displayed
instead. If the number cannot be
displayed, the message Unknown is
shown.
The handsfree phone system
ringtone is dependent upon the
phone model and mode (silent,
vibrate, etc.).Automatic call waiting
For safety reasons, the automatic call waiting function is set by default. It is
recommended that this feature
remains activated.When an incoming call arrives, a
message alerts the caller to the fact
that you are driving. The call starts
automatically and the length of the
call is shown on the Infotainment
system display screen. Pick up the
call only when it is safe to do so.
To deactivate automatic call waiting,
refer to (CD35 BT USB) "Activate/
deactivate automatic call waiting" in
the "Phone settings" section.
With automatic call waiting
deactivated, it is possible to reject the
call by selecting Refuse or by
pressing and holding 8. To place the
caller on hold, select Pause; the caller
is informed they are on hold via an
automatic message.
Temporarily override the automatic
call waiting feature by selecting
Resume or press 7 to receive the
call.
NAVI 50 - Receiving calls
To accept the call:
● Press Accept/Agree on the
display screen.
● Briefly press 7 (on the steering
column controls).To reject the call:
● Press Refuse/Reject on the
display screen.
● Press and hold 8 (on the steering
column controls).
When receiving a call, the caller
number may be shown on the
Infotainment system display screen. If the number is stored in the system
memory, the name is displayed
instead. If the number cannot be
displayed, the message Unknown/
Unknown number is shown.
NAVI 80 - Receiving calls
To accept the call:
● press Pick up on the display
screen
● briefly press 7 (on the steering
column controls)
To reject the call: ● press Reject on the display
screen
● press and hold 8 (on the steering
column controls)

138PhoneWhen receiving a call, the caller
number may be shown on the
Infotainment system display screen. If
the number is stored in the system
memory, the name is displayed
instead. If the number cannot be
displayed, the message No Caller ID
is shown.
Functions during a telephone call
R15 BT USB, R16 BT USB,
CD16 BT USB, CD18 BT USB -
Functions during a telephone call
In addition to volume control, various
functions are available during a call,
including:
● switch the call to the mobile phone
● access the keyboard
● end call
Turn and press OK to select and
confirm.
Switch the call from the handsfree
phone system to the mobile phone by selecting the mobile phone display
item. Some mobile phones maybecome disconnected from the
handsfree phone system during the
switch to this mode.
A number can also be entered on the numerical keyboard ( 3 122) e.g. to
control a voice server such as the
voicemail box. Select the #123
display item to access the numerical
keyboard. Refer to " Voicemail box"
for further information.
To end the call, depending on vehicle
configuration:
● briefly press 8
● press TEL
● select the } icon in the display
CD35 BT USB - Functions during a
telephone call
In addition to volume control, various
functions are available during a call,
including:
● Pause / Resume
● Handset
● Keyboard
● Hang upTo put the caller on hold, select
Pause ; the caller is informed they are
on hold via an automatic message.
Select Resume to resume the call.
Switch the call from the handsfree
phone system to the mobile phone by
selecting Handset. Some mobile
phones may become disconnected
from the handsfree phone system
during the switch to this mode.
A number can also be entered on the numerical keyboard ( 3 122) e.g. to
control a voice server such as the
voicemail box. Select the Keyboard
menu item to access the numerical
keyboard. Refer to " Voicemail box"
for further information.
To end the call: ● press 8, or
● select Hang up, then press the
central rotary knob

Phone139NAVI 50 - Functions during a
telephone call
In addition to volume control, various functions are available during a call,
including:
● }: End call
● n: Switch vehicle microphone off
● é: Switch vehicle microphone on
● m/m 3 : transfer conversation to
mobile phone
● J3: transfer conversation to
vehicle's microphone and
loudspeakers
● 7: Return to previous screen
(e.g. Navigation or Home page)
NAVI 80 - Functions during a
telephone call
In addition to volume control, various functions are available during a call,
including:
● Place call on hold: Press < (to
open pop-up menu) then select
On hold . Press Continue to
resume the call.● Transfer conversation to mobile
phone: Press < (to open pop-up
menu) then select Handset.
In some cases, the phone may be disconnect from the Infotainment
system during a call transfer.
● End call: Press End call.
● Return to previous menu: Press r.
Phone settings
CD35 BT USB - Phone settings
Press SETUP / TEXT and select the
Phone settings menu.Activate/deactivate automatic call
waiting
To activate or deactivate automatic
call waiting, access the Put on hold
menu, then select either Automatic
(the default setting) or Manual.
During automatic mode, a tone will
sound to indicate that a call is on hold.Change ringtones
The vehicle ringtone or phone
ringtone can be changed for incoming
calls. Access the Ring tone menu,
then select Vehicle or Phone .Notice
Depending on phone model, the
ringtone transfer function may not be
available.Restore default phone settings
To restore phone settings to their
default values, select Default
settings by turning and pressing the
rotary knob. Confirm modification with the display option when prompted.Display software version
To display the software version,
select Display software version by
turning and pressing the rotary knob.
NAVI 50 - Phone settings
Restore default phone settings
To access the settings menu at any time, press 7 followed by
ÿ SETTINGS on the display screen.
Select System followed by Factory
settings then Phone to restore phone
settings to their default values.
Confirm by pressing OK.Display software version
To access the settings menu at any
time, press 7 followed by
ÿ SETTINGS on the display screen.

140PhoneSelect System followed by System
version to display the software
version.
NAVI 80 - Phone settings
From the Home page, press MENU
then Phone followed by Settings on
the display screen.
Select from the following options on
the display:
● Manage devices :
Refer to (NAVI 80) "Pairing a
mobile phone" in the "Bluetooth
connection" section 3 127.
● Sound levels :
To set the handsfree phone
system call volume and the
ringtone.
● Voice mail :
Refer to (NAVI 80) "Voicemail
box" above.
● Turn Bluetooth on/off :
Refer to (NAVI 80) "Activating Bluetooth" in the "Bluetooth
connection" section 3 127.
● Automatically download phone
data :Press this option to tick the box
☑ alongside it.
When pairing and/or connecting
the mobile phone to the
Infotainment system, the contact
list and call lists in the mobile
phone can now be downloaded
to the handsfree phone system.
Data sharing must also be
authorised on your phone. Refer
to the operating instructions for
your mobile phone or consult
your network provider.
Mobile phones and CB radio
equipment
Installation instructions and
operating guidelines
The vehicle specific installation
instructions and the operating
guidelines of the mobile phone and
handsfree manufacturer must be
observed when installing and
operating a mobile telephone. Failure to do so could invalidate the vehicle
type approval (EU directive 95/54/
EC).Recommendations for fault-free
operation:
● professionally installed exterior antenna to obtain the maximum
range possible
● maximum transmission power 10 watts
● installation of the phone in a suitable spot, consider relevant
Note in the Owner's Manual
section Airbag system
Seek advice on predetermined
installation points for the external
antenna or equipment holder and
ways of using devices with a
transmission power exceeding
10 watts.
Use of a handsfree attachment
without external antenna with mobile
telephone standards GSM
900/1800/1900 and UMTS is only
permitted if the maximum
transmission power of the mobile
telephone is 2 watts for GSM 900 or
1 watt for the other types.

Phone141For reasons of safety, do not use the
phone while driving. Even use of a
handsfree set can be a distraction while driving.9 Warning
Operation of radio equipment and
mobile telephones which fail to
meet above mentioned mobile
telephone standards is only
permitted using an antenna
located outside of the vehicle.
Caution
Mobile telephones and radio
equipment may lead to
malfunctions in the vehicle
electronics when operated inside
the vehicle with no exterior
antenna, unless the above
mentioned regulations are
observed.

142IndexAAAC files ....................................... 55
ACC files....................................... 61
Activating Bluetooth function ......127
Activating the navigation system ..78
Activating voice recognition ........120
Adaptation volume km/h ...............39
Add a favourite destination ...........97
Adding contacts to the phonebook .............................. 131
AF (Alternative Frequency)........... 51
AGC Activated .............................. 36
AhaⓇ application .........................24
Applications .................................. 24
AST (Autostore list) ......................50
Audio CDs .................................... 55
Audio players ................................ 24
Audio settings ......................... 36, 56
Automatic call waiting .................131
Automatic Gain Control (AGC) .....36
Automatic phone connection ......124
Automatic station search ..............47
Automatic station storing ..............50
Automatic switch-off .....................24
Automatic zoom ............................ 78
Autostore lists ............................... 50
AUX input ..................................... 59
AUX input usage........................... 59
Avoid part of route ......................106
Avoid roadblocks ........................106B
Balance......................................... 36
Bass.............................................. 36
Battery replacement .....................78
Bluetooth .................................... 122
Bluetooth connection ............65, 127
Bluetooth device list ...................127
Bluetooth music ............................ 65
Browse map................................ 106
C Calculate alternative route ..........106
Call lists ...................................... 131
Call waiting ................................. 131
CD display .................................... 56
CD playback ................................. 56
CD player................................ 55, 56
CD-Text ........................................ 56
Change Home location .................78
Change passkey for Bluetooth connection ............................... 127
Change system language .......24, 40
Clock................................. 24, 40, 78
Compass ...................................... 78
Connecting an audio device .........65
Connection ................................. 124
Control elements overview .............6
Co-ordinates ........................... 78, 97
Country information ............106, 131

143DDAB .............................................. 54
Deactivating Bluetooth function ..127
Deactivating guidance ................106
Defining the priority phone .........124
Delete a favourite destination .......97
Delete device from Bluetooth device list ................................ 127
Destination.................................... 78 Destination input ..........................97
Dialling a telephone number .......131
Digital audio broadcasting ............54
Disable camera warnings ...........106
Disconnecting an audio device .....65
Disconnecting a phone ...............124
Display .......................................... 24
Display information .......................56
Displaying pictures .......................72
Display screen operation ......24, 122
Driving Eco2 ................................. 24
Driving economy ........................... 24
E Eco coaching ................................ 24
Edit Itinerary ............................... 106
Emergency call ........................... 131
Emergency number ....................131
Emergency phone numbers .......106
Enter an address ..........................97Entering a number manually ......131
External device authorisation .....127
F Fader ............................................ 36
Fast forward.................................. 56
Fast rewind ................................... 56
Favourite destinations ..................97
Favourites ..................................... 24
Media ........................................ 24
Navigation ................................. 24
Phone ........................................ 24
Services .................................... 24
Find on map................................ 106
FM station list ............................... 50
Functions during a telephone call 131
G
General information ...4, 55, 59,
61, 65, 74, 118, 122
GPS (Global Positioning System). 74
Guidance ................................... 106
Guided tours ................................. 78
H Handsfree phone system ...........131
HD Traffic ..................................... 78
Help! ................................... 106, 118
Home address .............................. 97
Home location............................... 78I
ID3 tags ........................................ 56
Image settings .............................. 24
Image viewer ................................ 78
I News service .............................. 51
Information on the display ............78
Infotainment controls ....................24
Infotainment system Switching on/off ......................... 24
Instrument panel controls ...............6
Intersection view ........................... 78
Ioniser ........................................... 24
iPod ........................................ 61, 62
I-Traffic service ............................. 51
J
Jack plug ...................................... 59
K Keyboards in the display ......78, 122
L
Lane images ................................. 78
Language ..................................... 24
Latitude, Longitude .......................97
Live services ................................. 78
Local search ................................. 97
Loudness ...................................... 36
Low volume sound enhancement. 36

144MMailbox ....................................... 131
Manual phone connection ..........124
Manual station search ..................47
Manual station storing ..................50
Maps ............................................. 74
Map screen ................................... 78
Menu screen ................................. 78
Minimise traffic delays ................106
MIX ............................................... 56
Mobile phones and CB radio equipment .............................. 140
Modes of operation .......................24
Motorway view .............................. 78
MP3 CDs ...................................... 55
MP3 files ....................................... 61
MP3 player ................................... 62
MP3 players.................................. 61
Multimedia .................................... 72
Multimedia settings .......................40
Musical atmosphere .....................36
Mute........................................ 24, 56
My TomTom LIVE......................... 78
N Navigation control .......................120
Navigation services ......................24Navigation system
Creating a TOMTOM
HOME™ account ......................74
Creating an account ..................74
GPS (Global Positioning
System) ..................................... 74
Installing the software ...............74
Maps ......................................... 74
Registering the Navigation
system ....................................... 74
SD card ..................................... 74
Software installation ..................74
TomTom HOME™ ....................74
Traffic info service .....................74
USB memory stick..................... 74
Navigation system preferences ....78
Navigation volume ........................78
Navigation warnings .....................78
News............................................. 51
O On-board computer ......................24
Operation .............................. 65, 131
Outside air quality .........................24
P
Pairing a mobile phone ...............127
Pairing an audio device ................65
Park Assist.................................... 24
Pause ........................................... 56
Phone ......................................... 122Phonebook................................. 131
Phone connection .......................124
Phone control ............................. 120
Phone controls............................ 122
Phone installation instructions ....140
Phone menu ............................... 131
Phone operating guidelines ........140
Phone settings ............................ 131
Photos .......................................... 72
Pictures......................................... 72
Planning preferences ...................78
Playing movies ............................. 72
Playing music via Bluetooth .........65
Playing saved audio files ..............62
POI categories .............................. 97
Points of interest ........................... 24
Points of Interest (POI) .................97
POIs........................................ 24, 97
Portable CD players .....................59
Prepare route in advance .............97
PTY (Program type)...................... 51
Q
Quick menu .................................. 78
R
Radio ............................................ 45
DAB ........................................... 54
Digital Audio Broadcasting ........54
Radio controls............................... 45
Radio data system (RDS) ............51
